Four State QRP Group Cyclone 40 Instruction Manual page 7

RESISTORS
Next, install the resistors.
√
Ref Value
R24 330
R9 470
R3 680
R4 1.0k
R7 1.0k
R10 1.0k
R8 1.0M
R13 1.0M
R20 1.0M
R21 1.0M
R23 1.0M
R26 1.0M
R27 1.0M
R28 1.0M
R2 1.5k
R1 100k
R11 100k, 10t
R5 10k
R15 10k
R22 10k
R6 10k
R16 10k, 10t
R12 18k
R17 3.3k
R19 3.3k
R25 3.3k
R14 330k
R18 470k
Marking
Orange-Orange-Brown
Yellow-Red-Brown
Blue-Grey-Brown
Brown-Black-Red
Brown-Black-Red
Brown-Black-Red
Brown-Black-Green
Brown-Black-Green
Brown-Black-Green
Brown-Black-Green
Brown-Black-Green
Brown-Black-Green
Brown-Black-Green
Brown-Black-Green
Brown-Green-Red
Brown-Black-Yellow
104
Brown-Black-Orange
Brown-Black-Orange
Brown-Black-Orange
-
103
Brown-Grey-Orange
Orange-Orange-Red
Orange-Orange-Red
Orange-Orange-Red
Orange-Orange-Yellow
Yellow-Violet-Yellow
Description
1/4W
1/4W
1/4W
1/4W
1/4W
1/4W
1/4W
1/4W
1/4W
1/4W
1/4W
1/4W
1/4W
1/4W
1/4W
1/4W
Blue Pot
1/4W
1/4W
1/4W
Volume Control
Blue pot
1/4W
1/4W
1/4W
1/4W
1/4W
1/4W
