CROMMELINS™ POWER TROWELS
OPERATION & INSTRUCTION MANUAL
Thank you for your selection of a CROMMELINS™ Power Trowel.
This Operation Manual explains its use, installation, checking and maintenance.
We highly recommend that you retain this manual for ready reference regarding
proper handling of the CROMMELINS™ Power Trowel.
Spare Parts & Service
Phone: 1300 554 524
Freecall Fax: 1800 636 281
spareparts@crommelins.com.au
www.crommelins.com.au
WA Metro 9350 5588
East Coast 1300 650 659
WA Regional 1800 655 588
email@crommelins.com.au
1
Advertisement
Table of Contents
Summary of Contents for Crommelins CPT24S
- Page 1 CROMMELINS™ POWER TROWELS OPERATION & INSTRUCTION MANUAL Thank you for your selection of a CROMMELINS™ Power Trowel. This Operation Manual explains its use, installation, checking and maintenance. We highly recommend that you retain this manual for ready reference regarding proper handling of the CROMMELINS™ Power Trowel.
-
Page 2: Table Of Contents
Thank you very much for purchasing a CROMMELINS™ POWER TROWEL. This manual covers operation and maintenance of the CROMMELINS™ POWER TROWEL. This CROMMELINS™ POWER TROWEL can be used in the mining, construction, hire industries and general use. Please take a moment to familiarise yourself with the proper operation and maintenance procedures in order to maximise the safe and efficient use of this product. -
Page 3: Safety Precautions & Belt Setting
This manual contains important information on how to use the following power trowels models CPT24S, CPT34R, CPT34RD, CPT40R, CPT40RD and CPT46S properly and safely. Please read through this manual before you attempt to operate this product. SAFETY PRECAUTIONS Before operating this piece of equipment, the operator should read this manual. -
Page 4: Pre Start-Up Checking
PRE START-UP CHECKING • Consult engine manual for detailed starting information. • Check all bolts and screws for tightness. Loose bolts and screws may cause damage to the unit. • Make sure that all dirt, mud, etc., are thoroughly removed from areas such as cooling air inlet of engine, carburettor, and air cleaner. -
Page 5: Operation
OPERATION CAUTION! – Poisonous fumes. Start and operate only in a well-ventilated area. Be careful with hot components, mufflers and other engine parts are hot during operation. Do not touch them. STEP 1 – Adjust throttle lever to the desired speed. STEP 2 –... -
Page 6: Shutdown & Maintenance
SHUTDOWN – PETROL UNIT STEP 1 – Move throttle lever to low speed position quickly and run engine for 2-3 minutes at low speed. STEP 2 – Turn of the stop switch, the engine stops completely. STEP 3 – Close engine fuel cock. STEP 4 –... -
Page 7: Storage
MAINTENANCE CAUTION! FLAMMABLE LIQUID. When performing maintenance, stop engine and do not smoke in adjacent area. HIGH TEMPERATURE. Allow machine and engine to cool down before performing maintenance. Contact with hot components can cause serious injury. MOVING PARTS. Make sure engine is shutdown before maintenance. Contact with moving parts can cause serious injury. -
Page 8: Specifications Charts
POWER TROWEL SPECIFICATION CHART MODEL CPT24S CPT34R CPT34RD Weight (kg) 50kg 75kg 75kg Engine Make Subaru Subaru Subaru Engine 4.5hp EX13 6.0hp EX17 4.8hp DY23 Engine Features Fuel Type Petrol Petrol Diesel Fuel Tank 2.7L 3.6L 3.2L Noise Level db@7m 64.0... -
Page 9: Specifications Charts
POWER TROWEL SPECIFICATION CHART MODEL CPT40R CPT40RD CPT46S Weight (kg) 78kg 93kg 102kg Engine Make Subaru Subaru Subaru Engine 6.0hp EX17 4.8hp DY23 9.0hp EX27 Engine Features Fuel Type Petrol Diesel Petrol Fuel Tank 3.6L 3.2L 6.1L Noise Level db@7m 66.0 74.0 70.0... -
Page 10: Trouble Shooting
TROUBLE SHOOTING GUIDE If the power trowel malfunctions immediately shut the machine down. Following are some simple trouble shooting tips: PROBLEM CAUSE SOLUTION 1. Refill Fuel 1. No fuel in the engine Engine stops suddenly 2. Clean spark plug 2. Spark plug carbonised or does not run 3. -
Page 11: Power Trowel Diagram
POWER TROWEL PARTS DIAGRAM... -
Page 12: Power Trowel Parts List
POWER TROWEL PARTS LIST... -
Page 13: Power Trowel Reducer Diagram
POWER TROWEL REDUCER DIAGRAM... -
Page 14: Power Trowel Reducer Parts List
POWER TROWEL REDUCER PARTS LIST... -
Page 15: Power Trowel Spider Diagram
POWER TROWEL SPIDER DIAGRAM... -
Page 16: Power Trowel Spider Parts List
POWER TROWEL SPIDER PARTS LIST CPT70140SET 40” Blade Set (Qty 4) CPT70146SET 46” Blade Set (Qty 4)
