- Page 1 Instructions manual KNX weather station art. 01546 Installation manual...
- Page 2 Table of Contents...
- Page 3 GENERAL FEATURES AND FUNCTIONALITY from page 5 ETS PARAMETERS AND COMMUNICATION OBJECTS from page 6...
- Page 4 For all the details about the Well-contact Plus system, refer to the installer manual that can be downloaded from the Software Product Software Well-contact Plus section on the website www.vimar.com.
- Page 5 The KNX weather station 01546 can be integrated with the By-me home automation system via a dedicated configuration using the EasyTool Professional software.
- Page 6 KNX weather station ETS parameters and communication objects List of existing communication objects and standard settings Flag 1 ETS name Function Description Type Priority C R W T U Sends the command over the BUS when the "Night" Night control output Output 1 bit - Low...
- Page 7 Actual value Brightness 1 limit value: to read the actual limit value 2 bytes C R W - - Low brightness 1 Continues C = Communication; R = Read; W = Write; T = Transmission; U = Enable update VIMAR group...
- Page 8 KNX weather station ETS parameters and communication objects Continued Flag 1 ETS name Function Description Type Priority C R W T U Limit value Brightness 2 limit value: to set the setpoint of the limit Default value 2 bytes C R W T U - Low brightness 2...
- Page 9 Output B at 8 bits Output B at 8 bits of the logic output OR 5. 1 bytes C - Low Continues C = Communication; R = Read; W = Write; T = Transmission; U = Enable update VIMAR group...
- Page 10 KNX weather station ETS parameters and communication objects Continued Flag 1 ETS name Function Description Type Priority C R W T U Logic OR 6 Control output Logic output OR 6 at 1 bit. 1 bit - Low Logic OR 6 Output A at 8 bits Output A at 8 bits of the logic output OR 6.
-
Page 11: General Settings
Power up and station waits for the programm. set time delay before transmitting the [ 10 s ] control outputs. 1... 20 telegrams per second Maximum speed of the telegram [5 telegrams per second] VIMAR group... - Page 12 KNX weather station ETS parameters and communication objects Temperature Continued Available values Available values ETS text Comment ETS text Comment [ Default value ] [ Default value ] Do not send Send cyclically Limit value 2 Send with change Measured value [ off ] Send with change or cyclically...
- Page 13 31-Max. measured wind strength value. 32-Reset max. wind [ do not enable ] strength. Enables/disables communication Use error object object: 11- Wind sensor [ No ] error. Limit value 1 [ off ] Wind Continues VIMAR group...
- Page 14 KNX weather station ETS parameters and communication objects Limit value 1,2,3 When the above parameter Limit Value is selected as on it is necessary to set its characteristics and those of the Control output too. Available values ETS text Comment [ Default value ] Parameter Communication...
- Page 15 [none] LV upper = ON | LV - lower hyst. = OFF LV lower = ON | Output activates with LV + lower hyst. = OFF [LV upper = ON | LV - lower hyst. = OFF] Continues VIMAR group...
- Page 16 KNX weather station ETS parameters and communication objects Note: If the threshold value is set by a communication object, Continued the threshold value must be specified during configuration Available values ETS text Comment [ Default value ] because this value remains valid until the 1st object is sent with the new threshold value.
- Page 17 [ off ] Logic 2 [ off ] Logic 3 [ off ] Logics Logic 4 [ off ] Logic 5 [ off ] Logic 6 [ off ] Logic 7 [ off ] Logic 8 [ off ] VIMAR group...
- Page 18 KNX weather station ETS parameters and communication objects Logic AND Continued Available values Available values ETS text Comment ETS text Comment [ Default value ] [ Default value ] Rain Yes Do not use Night = 1 Rain No Night = 0 Temperature error Limit value Temperature error...
- Page 19 Logic AND with Logic output transmits "two 8-bit objects" Logic OR The parameters with which the OR logic gates are configured are similar to those previously illustrated for the AND logic gates. Therefore please refer to the information on the previous pages. Logic OR VIMAR group...
- Page 20 KNX weather station ETS parameters and communication objects Hysteresis of the limit value. This section graphically illustrates the meaning of the Hysteresis parameter for the object with Limit Value 1,2,3 for Temperature, Wind, Brightness and Twilight. Value of the quantity (temperature, wind speed, brightness) Limit Value Hysteresis of...
- Page 21 Viale Vicenza, 14 - 36063 Marostica VI - Italy Tel. +39 0424 488 600 - Fax (Italy) +39 0424 488 188 Fax (Export) +39 0424 488 709 01546 EN 01 1507 www.vimar.com VIMAR - Marostica - Italy...
