- Page 1 ! "...
- Page 2 Antenna Use: The AU2-UHF antenna is included with the shipment of each Model TX-3 Transceiver. DO NOT use any other antenna with the Model TX-3 Transceiver or modify the antenna / coaxial cabling without first consulting with Everyday Wireless or an Everyday Wireless qualified service organization.
- Page 3 Everyday Wireless reserves the right to revise this user guide or withdraw it at any time without prior notice.
-
Page 4: Table Of Contents
CONTENTS Section 1 – Introduction ......................... 1 Product Description and Basic Operation................. 1 Technical Specifications ......................2 Section 2 – Receiving, Inspection, and Installation ................3 Packing Contents and Inspection....................3 Installation ..........................3 Section 3 – Maintenance......................... 5 3.1) Maintenance Concept ....................... -
Page 5: Section 1 - Introduction
Model TX-3 prepares its encrypted data packet, checks to make sure the channel is clear, and then bursts the data at its precise time slot time interval. Because data packets from the Model TX-3 burst (typically 25 msec.) in a proprietary time slot protocol, message collisions are avoided and higher throughputs are achieved. -
Page 6: Technical Specifications
1.2) Technical Specifications ! "# $ " % & ' ( ) * + " "" # " % .) * ! "# - 1 2 0 3 / %4 " 5 " 6 ' % 1 2 03 1 2 03 %8 9 : 1 %8 !"... -
Page 7: Section 2 - Receiving, Inspection, And Installation
WIRELESS AUTHORIZED REPRESENTATIVES TO DETERMINE IF THEY WILL PERFORM NORMALLY WHILE TRANSMITTING. Note: The following preparation instructions are for use by your EVERYDAY WIRELESS dealer, an authorized EVERYDAY WIRELESS service facility, or the factory. Note: The antenna and transceiver require certain mounting surfaces and environments as described below. If no suitable mounting surface is available, please contact EVERYDAY WIRELESS for alternative hardware and mounting solutions. - Page 8 • Step drill bit capable of drilling a ¾ inch hole • 1/8 to 1/4 inch drill bit • Test light and voltmeter Antenna and Transceiver Location Identify a location on the vehicle roof where the antenna will be installed. The antenna should be located on a flat metallic surface at a minimum of 6 inches from all roof edges.
- Page 9 Please consult Everyday Wireless for a list of accessories and for user manuals and installation instructions. 1. Each Model TX-3 has a DB25 connection on the transceiver, which is used to connect the TX-3 transceiver to Everyday Wireless vehicle sensor modules. Please consult the user manual of your specific sensor module for installation instructions.
-
Page 10: Section 3 - Maintenance
Section 3 – Maintenance In order to ensure that the Model TX-3 is always ready for operation, it should be checked periodically so that potential defects may be discovered and corrected before they develop into any serious damage. A minimal preventive maintenance program will significantly increase the transceiver’s lifespan. - Page 11 Cleaning Clean the outside surfaces and areas around the connectors once a year. Clean the surfaces with a clean, soft, lint-free cloth. Clean the areas around the connectors with a soft bristle brush. To remove grease, fungus, or corrosion, use a cloth dampened with an appropriate electronics cleaning fluid. The frequency of cleaning should be increased for units exposed to dusty or heavy particulate environments.
