CIMETRIX TCM-R1 User Manual

Leeb hardness tester
Hide thumbs
Table of Contents

Advertisement

Quick Links

TCM-R1
Leeb Hardness Tester
User Manual

Advertisement

Table of Contents
loading

Summary of Contents for CIMETRIX TCM-R1

  • Page 1 TCM-R1 Leeb Hardness Tester User Manual...
  • Page 2 Preface Dear users: Thank you for your purchase of our Leeb Hardness Tester of TCM-R1 Series (it is called Hardness Tester below), the Hardness Tester is portable device, and it is equipped with printer and software for data processing. It is small in size, light in weight and easy to catch with.

  • Page 3: Table Of Contents

    CONTENTS 1 Structure Feature......................... 3 2 Overview............................7 3 Preparation & Testing......................... 12 4 Operation in Details........................17 5 Servicing & Maintenance......................26 6 Malfunction analysis and maintenance..................28 7 List of components not warranty....................29 8 Instructions for Standard Leeb Hardness Test Specimen............30 Users Notice..........................
  • Page 4 1.2 Impact device of type D 1. Release button 2.Plug of the impact device 3.Connection cable 4.Loading tube 5.Guide tube 6.Coil unit 7. Impact body 8.Support ring 1.3 Some other types of impact device for purchasing 1.4 Technical Specifications Error and repeatability of displayed value see Table 1. Table 1 Type of impact device DC(D)/DL...
  • Page 5 Dia. Test tip: Material of test tip: Tungsten Tungsten Tungsten Tungsten synthetic carbide carbide carbide carbide diamond Impact device diameter: Impact device length: 20mm 20mm 20mm 30mm 20mm Impact device weight: 75mm 162mm 141mm 254mm 155mm 250g Max. hardness of sample 940HV 940HV 1000HV...
  • Page 6 surface hardening ≥0.8mm ≥0.8mm ≥0.2mm ≥1.2mm ≥0.8mm Size of tip indentation Hardness Indentation 0.54mm 0.54mm 0.38mm 1.03mm 0.54mm 300HV diameter Depth of 24μm 24μm 12μm 53μm 24μm indentation Hardness Indentation 0.54mm 0.54mm 0.32mm 0.90mm 0.54mm 600HV diameter Depth of 17μm 17μm 8μm 41μm...

  • Page 7: Overview

    hollow groove or small, light, large, thick, high cylindrical; reentrant thin parts heavy and hardness device DL: Test slender surface and surface rough material narrow groove of hardened surface or hole layer steel 2 Overview 2.1 Features Ultra-thin shell, more easily to hold ...
  • Page 8 Test Precision：HLD：±6 HRC：±1 HB：±4  Standard Impact Device: impact device of Type D  Upper / Lower Limits Setting：(170-960)HLD, (17.9-69.5)HRC, (19-683)HB, (80-  1042)HV, (30.6-102.6)HS, (13.5-101.7)HRB Optional Impact Device: D/ C /DC / D+15 / DL/ G  Number of Impact Devices Equipped With One Time: any ...
  • Page 9 tin alloy(bronze), fine copper Power Supply: 1.5V AAA battery ( 3 PCS)  Working time: about 150 hours  Shape Size: 155mm*68mm*27mm  Weight: 230g  2.3 Main function parameter  Choose Testing Materials, Hardness Scales, Measuring Direction and times of Tests By Button;　　...
  • Page 10  Ambient temperature：Operating temperature ℃  10～＋50 ; ℃  Storage temperature：-30℃～＋60 . 2.4 Testing and measurement range Table 2 Measurement range Impact device Material Method D/DC D+15 17.9～ 19.3～ 20.6～ 20.0～69.5 22.4～70.7 68.5 67.9 68.2 59.6～ 47.7～ 37.0～ 99.6 99.9 99.9 59.1～...
  • Page 11 Steel 143～650 20.4～ 19.8～ 20.7～68.2 22.6～70.2 67.1 68.2 CWT、ST 80～898 80～935 100～941 82～1009 46.5～ 101.7 Stainless steel 85～655 85～802 GC. IRON 93～334 92～326 NC、IRON 131～387 127～364 19～164 23～210 32～168 C．ALUM 23.8～ 23.8～ 22.7～85.0 84.6 85.5 40～173 BRASS 13.5～ 95.3 BRONZE 60～290...

  • Page 12: Preparation & Testing

    COPPER 45～315 2.5 Leeb Hardness Testing Principle The basic principle is: use an impact body of certain weight impacts against the testing surface under certain test force, then measure the impacting velocity and the rebounding velocity of the impact body respectively when the spherically test tip is located 1mm above the testing surface.
  • Page 13 (2)Too big roughness of the being measured surface could cause measure error. So the surface of the sample to be measured must appear metallic luster, smoothing and polish, without oil stain. (3)Support of test sample. Support is no necessary for heavy sample. Medium weight parts must be set on the smoothing and stable plane.
  • Page 14 though its weight and thickness is big enough, and accordingly, the test value may not be accurate. So the sample should be reinforced or supported at its back. (8)Magnetism of the sample itself should be avoided. Table 3 3.1.2 System Setting See 4.5 for details.
  • Page 15 3.2.1 Start-Up (1)Insert the plug of the impact device into the socket of impact device on the tester. (2)Press key，now power is connected. The instrument is in testing condition. Table 4: 3.2.2 Loading Pushing the loading-tube downwards until contact is felt. Then allow it to slowly return to the starting position or using other method locking the impact body.
  • Page 16 The action direction should pass the axis of the impact device. (2)Each measure area of the sample usually need 5 times of testing operation. The result data dispersion should not more than mean value±15HL. (3)The distance between any two impact points or from the center of any impact point to the edge of testing sample should conform to the regulation of Table 5.

  • Page 17: Operation In Details

    4 Operation in Details 1.LCD Backlight Standby time 3.Silent mode 4.Time display 5. Sign of HL Measure value by HL 7. Battery status 8. Hardness Scale 9.Times 10.Material Measure value 12. Impact direction Diagrams of the keyboard Function of the keys: ●Power on/off and LCD brightness on/off.
  • Page 18 ●Material. ●Scale. ●Upward/Save ●Downward/Delete ●Left/Right. 4.1 Power on Plug in the impact device, and press to power on the system. The screen shows as below: The system would automatically detect the type of the impact device during power up and would display this information on the screen as below. Following is the main display interface as below.
  • Page 19 keyorcould continuously glance downward or upward. Press to enter menu “Set parameter”. Press key or to move the cursor to the line you want to set, and press keyto enter submenu. 4.2.1 Hard/σ setting Press keyor to move the cursor to the line of “Measure H”，and then press key to switch H/TS continuously.
  • Page 20 submenu ”Set DIR ” , and then press keyor to choose one of the five kinds of impact direction such as downward, upward, downward 45°, upward 45° and level180° as below. After setting up correctly, press keyto to confirm it and return submenu “Set parameter”.
  • Page 21 material you want to preset. Press key to confirm it and return submenu“Set parameter” as below. Set material using shortcut key: Press key in main interface to change times quickly. 4.2.4 Average Times Setting Enter submenu”Set Times”, and then press key or to set the times you want to preset as below.
  • Page 22 2. Set LL is the same with UL. 4.2.6 Hardness Scale Setting Enter submenu ”Set Unit”, and then press keyor to move the cursor to the hardness scale you want to preset，as below. Press key to confirm it and return submenu” Set parameter “. Set hardness scale using shortcut key: Press key in main interface to change hardness scale quickly.
  • Page 23 to start a new setup is necessary. 4.3 Testing See chapter 3 for details 4.4 Save and Print the data 4.4.1 Save the data After finishing the test, press key to save the data, then press key to confirm it or press key to cancel it.
  • Page 24 Press the key to turn the page to check all of the information. 4.4.3 Delete the data Enter submenu” Check data”, and press key to delete the data, then press key to confirm it or press key to cancel it as below. 4.5 System set Press the keyto return to the main menu ”Leeb H Tester”.
  • Page 25 4.5.2 Auto power-off Press key or to move the cursor to the line of “Auto power-off”，and press key to enter submenu” Auto power-off” as below. Press key or to change the standby time. For example, the digital 1 indicates the standby time is 1 second and the maximum standby time is 10 seconds, while NO.0 indicates standby time is infinite.

  • Page 26: Servicing & Maintenance

    switch on/off the silent mode continuously as below. If the silent mode is off, the sign in the screen is or it is . 5 Servicing & Maintenance 5.1 Impact Device Servicing 1) After the impact device has been used for 1000--2000 times, please use the nylon brush provided to clean the guide tube and impact body.
  • Page 27 than 2 HRC, it may be the invalidation of impacted ball top caused by abrasion. Changing the spherical test tip or impact object should be considered. When the hardness tester appears some other abnormal phenomena, please do not dismantle or adjust any fixedly assembled parts. Fill in and present the warranty card to us.

  • Page 28: Malfunction Analysis And Maintenance

    6 Malfunction analysis and maintenance <1> When using standard Rockwell hardness block to testing, if all the error is bigger than 2HRC, it may be the invalidation of impacted ball top caused by abrasion. Changing the spherical test tip or impact object should be considered. <2>When the hardness tester appears some other abnormal phenomena, please do not dismantle or adjust any fixedly assembled parts.

  • Page 29: List Of Components Not Warranty

    7 List of components not warranty 1 the shell 2 the screen display 3 the panel 4 the impact body 5 the support ring 6 the probe cable 7 ink ribbon 8 the battery(the damage caused by faulty operation problem)

  • Page 30: Instructions For Standard Leeb Hardness Test Specimen

    8 Instructions for Standard Leeb Hardness Test Specimen The Standard Leeb Hardness Test Specimen is a new standard instrument of measurement for hardness measurement used for periodic calibration or daily calibration for the Leeb Tester and the standard have delivered the Leeb Hardness magnitude Since April 1, 2004.
  • Page 31 values, HLDmin represents for the minimum value of the five measurement values. The HLD in the two formulas above can also be HLDC,HL(D+15),HLC,HLG and HLE. Table7: Error and repeatability of displayed value Type of impact Hardness value of Leeb Error of Repeatability device standard hardness block...

  • Page 32: Users Notice

    Users Notice 1. Please fill out the warranty registration card seriously and seal your Company Chop after you get the instrument. Then mail the copies of the warranty registration card and the invoice to our user service center or you can relegate that to the seller when buying the instrument.
  • Page 33 System Calibration The tester and impact device must be calibrated using hardness block before use as the first time, or having not been used for a long time, or having reset the system. Press key【 】, meanwhile pressing【 】to power on the system. Then the software calibration screen shows 【Correcting】.
  • Page 34 Manufacturer By: CIMETRIX LTD Address: 1021 SW Klickitat Way, #102 Seattle WA, 98134. USA Telephone: 206-340-5995...
