- Page 1 Models: INTEGRATOR 4, 5, 6, 9, 9P F-2...
- Page 2 Thank you for purchasing these FLI coaxial speakers. They will provide you with years of trouble free usage providing you follow a few simple guidelines. Introduction This instruction manual is for your safety and must be adhered to at all times. Please read and ensure that you fully understand the installation and set up procedures as explained.
-
Page 3: Speaker Installation
Firstly, make sure that the speakers will fit in your chosen location. This may involve the removal of the standard vehicle speakers. Please use the mounting depth and hole cut dimensions as detailed in this manual for guidance. Speaker Installation If necessary cut any material away to allow the speaker to sit correctly. Cut out the mounting hole and pre-drill any other fixing holes. If the grill is to be fitted, screw through both gasket and speaker using the screw provided until the speaker is securely fastened. Grill removal The FLI integrator speakers feature a removable mesh grill. Please follow the instructions below to remove the grill. Peel the rubber gasket away from the basket Remove the mesh grill Refit the rubber gasket. -
Page 4: Wiring Connections
Wiring connections Connection to amplifier Connection to HEAD UNIT... -
Page 5: Serial Number
Parameters FI6-F2 FI9-F2 FI4 -F2 FI5-F2 FI9P-F2 Revc = 3.4 Ohm Revc = 3.4 Ohm Revc = 3.4 Ohm Revc = 3.4 Ohm Revc = 3.4 Ohm Fo = 69.782 Hz Fo = 65.102 Hz Fo = 88.976 Hz Fo = 83.008 Hz Fo = 65.102 Hz Sd = 13.070 M Sd = 21.253 M... -
Page 6: Limited Warranty
All content included in this manual such as text, graphics, logos, icons, images data, the selection and arrangement thereof, are the property of FLI Audio (herein referred to as "FLI", "us" or "we") and its affiliate or their content and technology providers, and are protected by United Kingdom and International copyright laws. - Page 7 FLI Line Level Convertor If your current head unit has no amplifier pre outputs this FLI Line Level Convertor can be connected directly to your rear speaker wires to provide a stereo set of RCA connectors which can be connected directly to an amplifier. FLI Loaded In dash remote control Allows 18db gain adjustment of the bass boost feature which is present on all...
- Page 8 Accessories can be ordered separately from the www.fliaudio.co.uk FLI website Only available in the UK If out side uk please contact your dealer or distributer from the FLI website Stores FLI Power Capacitor added power The FLI powercap, a 1 farad, high for when your specification power capacitor is another great system really...
