GSM Mini
GSM Mini
SMS-operated 230V socket
User manual
Swiss edition
www.EcoStarter.com
CONTENTS:
OVERVIEW OF GSM MINI .............. 1
BEFORE USE .................................. 1
Preparation of SIM card ............. 2
Inserting the SIM card ................. 2
Start-up ....................................... 2
Signal strength ........................... 2
SMS CONTROL ............................... 3
Sending SMS messages ............ 3
CONTROL COMMANDS .................. 3
AND ADVICE ................................... 4
Troubleshooting .......................... 4
TECHNICAL SPECIFICATIONS ...... 4
WARRANTY .................................... 5
RECYCLING .................................... 5
Swiss Edition
PAGE:
R
Copyright © 2013, EcoStarter
OVERVIEW OF GSM MINI
•
Based on standard GSM networks.
Operates in the 900/1800 MHz bands.
•
Relay rating: 230V 10A, 2300W.
•
Personal access code. Factory set to
"1234".
•
1 LED for signal strength. A blinking green
light signals a faulty SIM card.
•
1 LED for relay status. A steady green
light signals that the relay is switched ON.
•
1 push-button to switch the relay on/off
locally.
Relay status
LED
SIM card slot
(both on bottom faceplate)
BEFORE USE
All remote communication with GSM Mini takes
place through the GSM network. In order to
receive SMS command messages (for controlling
e.g. a heating appliance), GSM Mini needs to
have a SIM card installed, just like any standard
mobile phone.
SIM cards from any mobile phone operator will
work, both pre-pay and subscription based, as
long as they enable SMS messaging.
Remember that pre-pay solutions will often have
a limited life span, and need to be recharged with
credit at least once a year.
Page 1
Signal
strength
LED
On/Off switch
www.EcoStarter.com
