CISCO
TFT-LCD Color Monitor
FS-S5501F
User Guide
General Specification

Advertisement

   Related Manuals for Cisco FS-S5501F

   Summary of Contents for Cisco FS-S5501F

  • Page 1

    CISCO TFT-LCD Color Monitor FS-S5501F User Guide General Specification...

  • Page 2

    INFORMATION TO USER : General Specification...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS 1. Product Drawing------- ------------------------------------------------------------------------------ 1 2. Column Specification- ----------------------------------------------------------------------------- 2 3. Standard Signal Table ------------------------------------------------------------------------------3 4. Signal Connector Pin Assignments------------------------------------------------------------4 5. Specification ------------------------------------------------------------------------------------------6 General Specification...

  • Page 4: Product Drawing

    1. Product Drawing Unit : mm General Specification...

  • Page 5: Column Specification

    2. Column Specification Power switch HDMI 1 HDMI 2 RS-232 Input Speaker Input General Specification...

  • Page 6: Standard Signal Table

    3. Standard signal Table PC Supported Mode Resolution Horizontal Vertical Clock Frequency(KHz) Frequency(Hz) Frequency(MHz) 15.6 13.5 NTSC 15.7 13.5 640x480 29.5 23.625 800x600 31.5 35.4375 800x600 35.5 800x600 48.875 1024x768 47.3 720p(1280x720) 37.5 74.25 720p(1280x720) 74.25 720p(1280x720) 148.5 720p(1280x720) 148.5 1280x1024 1280x768 47.7...

  • Page 7: Signal Connector Pin Assignments

    4. Signal Connector Pin Assignments 1. HDMI1, HDMI2 Pin No. Assignment Pin No. Assignment TMDS Data2+ Ground_Clock Shield Ground_Data2 TMDS Clock- Shield TMDS Data2- No Connection TMDS Data1+ No Connection Ground_Data1 TMDS SCL Shield TMDS Data1- TMDS SDA TMDS Data0+ Ground Ground_Data0 TMDS Power...

  • Page 8

    3. Speaker input(D-Sub 2Row 15Pin) Pin No. Assignment Pin No. Assignment CABINET_VERSION1 LEFT+ (Left speaker) CABINET_VERSION0 LEFT- (Left speaker) TW+ (Center tweeter) RIGHT+ (Right speaker) TW- (Center tweeter) RIGHT- (Right speaker) MID+ (Center LOWMOUNTED midrange) MID- (Center midrange) LOW+ (Center bass) CABINET_VERSION2 LOW- (Center bass) Notes...

  • Page 9: Specification

    5. Specification Model FS-S5501F Type A-si TFT Active matrix Screen size 138.8Cm (Diagonal) Maximum Resolution 1920X1080@60Hz Pixel pitch 0.63(H)mmX0.36(V)mm LCD PANEL Display colors 16.7M (RGB 8-bit data) Contrast Ratio(Typ.) 4000:1 Viewing Angle(Typ.) 89/89/89/89 Response Time(Typ.) 10ms Luminance(Typ.) 350cd/m2 Synchro Horizontal Frequency 76.5 KHz...
