PL-1 Thermostat User's Guide
Version 2.0
Firmware Version 2.0

Table of Contents

Introduction................................................ 1
Conventions................................................ 2
Front Panel Layout........................................ 3
Thermostat Modes........................................ 4
Thermostat Mode Programming...................... 5
Set Point (SET 1)......................................... 6
Set Point 2 (SET 2).................................................. 7
Temperature Units........................................ 8
Probe Display............................................... 9
Probe Alarms (P1A and P2A).......................... 10
-
)......................................... 11
)........................................... 12
_
Brix Entry (Br) ............................................ 13
Pump-over Entry (Po)................................... 14
Pump-over Duration (PoD)............................ 15
Thermostat Configuration Menu (CC).............. 16
Unit Lock (UL)................................... 18
Cooling Probe (CP)..................................... 19
Heating Probe (HP)........................... 20
Heat Relay (Hr)................................ 21
Heat Mode Disable (Hd)..................... 22
Data Entry Disable (ddE).................... 23
Power-up Delay (Pud)........................ 24
Show "OFF" (SoF)....................................... 25
Wiring - Power, Solenoids & Probe....................... 27
Fuses and Service........................................ 29
- 2 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PL-1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for TankNet PL-1

  • Page 1: Table Of Contents

    Table of Contents Introduction..........1 Conventions..........2 PL-1 Thermostat User’s Guide Front Panel Layout........3 Thermostat Modes........4 Thermostat Mode Programming...... 5 Version 2.0 Set Point (SET 1)......... 6 Set Point 2 (SET 2)………………………………………….. 7 Temperature Units........8 Probe Display..........9 Probe Alarms (P1A and P2A)......

  • Page 2: Introduction

    ® Whether used stand-alone or networked to a TankNET time. Web Server, the PL-1 thermostat is designed to provide years of reliable and accurate service. Button Hold: To hold a button means to depress the button and to hold it down for a certain period of time.

  • Page 3: Front Panel Layout

    Front Layout Modes Panel Thermostat The PL-1 Thermostat supports the following thermostat modes: COOL Mode - In this mode the thermostat will engage the cooling solenoid via RELAY 1 whenever the cool probe temperature rises above the set point value.

  • Page 4: Thermostat Mode Programming

    Thermostat Mode Programming: Set Point (SET 1) 1. Press and release the SET button as needed to The Set Point (SET 1) parameter is used by the PL-1 advance to mode selection. This is indicated by the thermostat modes as follows: flashing of the currently selected mode annunciator.

  • Page 5: Set Point 2 (Set 2)

    Set Point 2 (SET 2) Temperature Units The Set Point 2 (SET 2) parameter, which is only available in The PL-1 thermostat can be configured to display AUTO mode, determines the temperature below which the temperature values in either Celsius or Fahrenheit.

  • Page 6: Probe Display

    Probe Alarms (“P1A” and P2A”) The PL-1 thermostat supports up to two X-Bus™ The PL-1 includes two probe alarm enables, one for each temperature probes and allows the operator to toggle probe that can be attached to the thermostat. A value of between the two probe temperature readings.

  • Page 7: High Alarm (Al - )

    High Alarm Threshold (“AL ”) Low Alarm Threshold (“AL_”) This parameter determines the probe temperature above This parameter determines the probe temperature below which an alarm will be triggered. which an alarm will be triggered. Programming: Programming: To adjust the high alarm temperature threshold for the To adjust the low temperature threshold for the selected selected probe alarm: probe alarm:...

  • Page 8: Brix Entry (Br)

    The Pump-over event entry screen allows cellar crews to The Brix entry screen allows Brix measurements taken at the ® enter pump-over events at the thermostat. In TankNET tank to be entered directly into the thermostat. In server environments, pump-overs are viewable on both the ®...

  • Page 9: Pump-Over Duration (Pod)

    Pump-over Duration (“Pod”) Control Configuration (“CC”) This parameter is used to determine how long (in minutes) This parameter is used to grant access to the advanced the thermostat will wait before resetting the Pump-over state thermostat configuration parameters. from “On” to “OFF”. Programming: The unit of measure for this parameter is minutes.

  • Page 10: Thermostat Differential (Dif)

    Thermostat Differential (“diF”) Units Lock (“UL”) This parameter determines the thermostat switching This parameter can be used to prevent inadvertent changes differential (or hysteresis), which applies to all thermostat to the local temperature display units setting. When this modes. parameter is set to “On” the thermostat’s temperature units can not be changed locally.
  • Page 11 Cool Probe (“CP”) Heat Probe (“HP”) The PL-1 thermostat supports two temperature probes. The The PL-1 thermostat supports up to eight temperature Cool Probe (“CP”) parameter tells the thermostat which probes. The Heat Probe (“HP”) parameter tells the probe to use for cooling. Only those probes which are thermostat which probe (or sensor in the case of a ®...

  • Page 12: Heat Relay (Hr)

    Heat Relay (“Hr”) Heat-Modes Disable (“Hd”) This parameter determines which of the two internal relays This parameter can be used to prevent the thermostat from will be engaged for heating. This setting only applies to being set to any of the heating modes. When this parameter HEAT mode and has no effect in COOL and AUTO modes.

  • Page 13: Data Entry Disable (Dde)

    Data Entry Disable (“dEd”) Power Up Delay (“Pud”) This parameter is used to disable brix and pump-over data This parameter is used to delay thermostatic operation for a entry at the thermostat. Setting the value of this parameter pseudo-random period of time immediately following power equal to “1”...

  • Page 14: Show "Off" (Sof)

    1. Press and release the SET button until the “SoF” parameter is displayed. ® To remove the thermostat from an existing TankNET network, hold down both the SET and UP ARROW buttons 2. Press the UP or DOWN button once to display the current simultaneously for approximately 10 seconds.

  • Page 15: Wiring - Internal Cable Connections

    External Wiring Internal Cable Connections Notes: A) Maximum wire gauge per contact = 16 AWG. A standard PL-1 thermostat has two internal ribbon cables B) Jumper required (as shown) for switched leg that must be connected during installation. These cable connections are shown below.

  • Page 16: Fuses And Service

    Fuses and Service The PL-1 thermostat has been designed to provide years of reliable service in harsh cellar environments. In the unlikely event that you do experience a problem with your thermostat, please contact Acrolon technical support for assistance via 707-938-1300 or support@acrolon.com.
