Introduction
Welcome to the Arc Audio family of performance signal processors. A blend of
Arc Audio's lengthy experience in performance car audio design combined with
our highly skilled engineering staff. You are now the proud owner of the KEQ7. A
unique combination of the highest quality components and precision
engineering. Whether you are a competitor or simply enjoy faithfully reproduced
music, you will definitely appreciate how these products make your system
sound. Before you begin read this manual cover to cover (does anyone ever
really do that?). Careful design and layout of your system and following the
instructions and suggestion in this manual will greatly simplify installation of
this product. If at any point you begin to feel overwhelmed, return to your local
Arc Audio dealer and let the trained professionals install or tune it for you.
Warning
We build all ARC Audio products to play at high volumes for extended periods
of time. Your ears however are not designed for high volume listening. This
product can easily generate volumes that can permanently damage your
hearing. We urge you to limit your exposure to very high volume sound.
You may also find your state has laws governing the volume of an audio
system in a car. Please be aware of all local and state laws in you area.
A properly tuned and operated audio system will deliver years of enjoyment
when used properly.
Running the Cables
Carefully run the power and signal cables through the passenger compartment
of the vehicle. Always use a rubber grommet to prevent the power wire from
shorting and to reduce the risk of fire.
Warning
Please check the suitability of the installation location before you begin. Do not cut
any of the car's structure. Pay close attention to what is behind the panels or carpet.
Often the manufacture will hide wires, computers or other electronic devices in the
exact areas you wish to install in.
If you do not have experience with automotive electrical and mechanical systems
contact a professional installer. Paying a qualified installer is almost always cheaper
then paying a dealership to repair your car.
1
Advertisement
Table of Contents
Related Manuals for ARC Audio KEQ7
Summary of Contents for ARC Audio KEQ7
- Page 1 Welcome to the Arc Audio family of performance signal processors. A blend of Arc Audio's lengthy experience in performance car audio design combined with our highly skilled engineering staff. You are now the proud owner of the KEQ7. A unique combination of the highest quality components and precision engineering.
-
Page 2: Connections And Controls
CONNECTIONS AND CONTROLS FEATURES ______________________________________ 8 10 Active gain preamplifiers with adjustable input sensitivity. Volume control with up to 7 VRMS of output. Seven band parametric equalizer with 12db Boost/Cut. Sub out with independent volume control. SUB OUT DVD INPUT MAIN IN REAR OUT FRONT OUT... - Page 3 Typical System Configuration (Your final configuration may very) Sub Output: Connect to your Subwoofer amp or amps. Sub Frequency Control: Be sure to make your final adjustments to the Sub crossover before you mount the unit into the dash of your car. You will need to complete your tuning first.
-
Page 4: Specifications
Boost/Cut 12dB from an authorized ARC AUDIO retailer. Upon inspection by ARC AUDIO should service be necessary under warranty for any reason due to manufacturer defects ARC AUDIO will, at its S/N Ratio 100dB discretion, repair or replace the defective product with new or similar condition product at no charge.
