ClimaCheck BGS2 Manual

Gprs modem / router
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
.
GSM Modem Manual
BGS2 GPRS Modem
ER75i Router
ETM450 Router
2016-05-04
ClimaCheck Sweden AB, Box 46, SE-131 06 Nacka, Sweden
Visiting/delivery address: Gamla Värmdövägen 6, SE-131 37 Nacka Sweden
Tel.: +46 (0)8-50 255 250, E-mail:
info@climacheck.com
Web:
www.climacheck.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BGS2 and is the answer not in the manual?

Questions and answers

Summary of Contents for ClimaCheck BGS2

  • Page 1 GSM Modem Manual BGS2 GPRS Modem ER75i Router ETM450 Router 2016-05-04 ClimaCheck Sweden AB, Box 46, SE-131 06 Nacka, Sweden Visiting/delivery address: Gamla Värmdövägen 6, SE-131 37 Nacka Sweden Tel.: +46 (0)8-50 255 250, E-mail: info@climacheck.com Web: www.climacheck.com...

  • Page 2: Table Of Contents

    Selection of Operator - SIM card for Data transfer ............3 Setting up M2M communication ................3 Choosing the best way to connect ..................4 Sending by GPRS to the ClimaCheck Server ............4 Temporary Connection by Modem Call-Up ............4 Sending Data by E-mail ..................5 Configuring the PA Pro for sending by GPRS ..............

  • Page 3: Selection Of Operator - Sim Card For Data Transfer

    (many networks has a firewall disabling access from the outside). A Public IP means that the ClimaCheck PA Pro can be contacted for configuration via Internet. The IP does not need to be a fixed IP as the ClimaCheck on-line server monitors incoming traffics IP number. The sending IP is displayed on the “Home page”...

  • Page 4: Choosing The Best Way To Connect

    PA Pro internal database. A dialled up connection is comparably slow and downloading the database takes a considerable time. Even when sending data to the ClimaCheck server it is useful to use the call-up function if you need to change a setting on the PA Pro.

  • Page 5: Sending Data By E-Mail

    2.3 Sending Data by E-mail This method is listed when accessing the web interface of the ClimaCheck unit, but is currently not supported. 3 Configuring the PA Pro for sending by GPRS This section explains how to configure your PA Pro unit to send data by GPRS connection to our server.

  • Page 6: Changing The Database Sample Interval

    Choose Settings -> Advanced -> Database UDP.  Set ID to the identifier for your account. It is provided to you by ClimaCheck or one of our partners and always contains six letters or digits. ClimaCheck GSM Modem Manual – 2015-02-26 6(22)

  • Page 7: Setting Gateway

    Figure 5 Important! If the PA Pro has been configured with a Gateway setting other than 0.0.0.0 on the LAN/DNS tab to communicate over a local network, the Modem connection will not work ClimaCheck GSM Modem Manual – 2015-02-26 7(22)

  • Page 8: Connecting And Starting The Modem

    The ClimaCheck PA Pro will initiate modem first time it has data to send - default 5 minutes if no compressor power is measured – 1 minute if power is measured - this time can be shortened by setting a shorter time in the settings (see 3.3 Changing the Database Sample Interval).

  • Page 9: Led Status On Cinterion Terminal

    Unless there is steady blink every three seconds after the modem has been connected ClimaCheck PA Pro will not be able to initiate data communication e.g. there is a general problem with the connection to the operators network this must be fixed before data communication over GPRS can be initiated.
  • Page 10 PA Pro has not initiated the data send mode. Many operators require activation of SIM-cards that are intended for data communication. 3. Check LED on the ClimaCheck PA Pro for communication with modem on RS232 flashing. If this is not flashing while modem is connected to a network.

  • Page 11: Router Modems

    5 Router Modems ClimaCheck work with several router modems and they present signal strength as -dBm 5.1 Signal Strength The signal strength is indicated by a LED on the front of the modem, as a dBm value on the Home page of the web interface or as a RSSI value (0-31) in the NETINFO SMS sent from the unit.

  • Page 12: Configure Dhcp And Ip Settings

    Store settings with the “Apply” button at the bottom of the page. Note! The router will now change IP number and you may have to deactivate and activate your network card to be able access it on the new IP, 192.168.33.1 ClimaCheck GSM Modem Manual – 2015-02-26 12(22)

  • Page 13: Configure Nat-Settings

    If more PA Pro units are connected each PA Pro needs a public port routed to its IP number in the same way as shown above. In the figure below 2 PA Pro units are connected to the ER75i LAN. ClimaCheck GSM Modem Manual – 2015-02-26 13(22)
  • Page 14 ER75i LAN according to the table below. For instructions on how to configure the PA Pro, see the Hardware Manual. IP Address Netmask Gateway DNS Server 3 PA Pro 1 192.168.33.2 255.255.255.0 192.168.33.1 192.168.33.1 PA Pro 2 192.168.33.3 255.255.255.0 192.168.33.1 192.168.33.1 ClimaCheck GSM Modem Manual – 2015-02-26 14(22)

  • Page 15: Etm 450 Router Modem

     In the Menu go to Network and WAN  Enter APN, ClimaCheck supplied SIM-card in example below.  If your SIM-card use a PIN-code choose enable and enter it. Figure 10 ClimaCheck GSM Modem Manual – 2015-02-26 15(22)

  • Page 16: Configure Lan Settings

    Press Apply Changes to save settings. Note! The router will now change IP number and you may have to deactivate and activate your network card to be able access it on the new IP, 192.168.33.1 ClimaCheck GSM Modem Manual – 2015-02-26 16(22)
  • Page 17 Figure 12 ClimaCheck GSM Modem Manual – 2015-02-26 17(22)

  • Page 18: Configure Port Forwarding

     Save settings by pressing Apply Changes Communication that is requested on port 81 on the public IP number will now be routed to the PA Pro with IP number 192.168.33.2. Figure 13 ClimaCheck GSM Modem Manual – 2015-02-26 18(22)

  • Page 19: Led Status On The Etm450

    PA Pro, see the PA Pro Manual. IP Address Netmask Gateway DNS Server 3 PA Pro 1 192.168.33.2 255.255.255.0 192.168.33.1 192.168.33.1 PA Pro 2 192.168.33.3 255.255.255.0 192.168.33.1 192.168.33.1 7.5 LED status on the ETM450 Figure 15 ClimaCheck GSM Modem Manual – 2015-02-26 19(22)

  • Page 20: Signal Strength

    7.7 SMS Commands The ETM450 modem can be controlled by different SMS commands. The modem will only respond to SMS from numbers that are in the units phonebook, Administrator -> System. ClimaCheck GSM Modem Manual – 2015-02-26 20(22)

  • Page 21: Connecting To The Pa Pro By Modem Call-Up

    IP you will need to change that setting before connecting to the PA Pro modem. You should not enter a user name or password. 8.2 Establishing connection in ClimaCheck  Start the ClimaCheck software.  Select the network interface named “WAN (PPP/SLIP) Interface” or similar. ClimaCheck GSM Modem Manual – 2015-02-26 21(22)

  • Page 22: Downloading The Database

    If you want to download the database choose Performance Analyser Pro -> Download and Save Logged Data and select how much data to save. Note that downloading the entire database by modem may take up to 30 minutes, not five minutes as stated by ClimaCheck. During this time ClimaCheck will be unresponsive.
