________INSTRUCTION
LAYOUT
1. LCD display
2. SET Button
3. Metal Pin
4. Battery Case
5. Holes on Wristband
6. Loop Hole
FEATURES
PEDOMETER
3D Silent Pedometer Sensor
Step counter up to 99999 steps
Distance walked up to 999.99 KM/999.99 Miles
Calories burned up to 9999.9 Kcal
'Finger Tap' display to change mode
30 Step Count Active System
LOW BATTERY INDICATOR
Battery icon appears when battery power is low
P330A 3D Pedometer
VIDEO INSTRUCTIONS:
MANUAL_______
www.csxpro.com/p330a
CLOCK
Display format 12/24 hours
ACTIVITY TIME
Record your daily activity time
during walking
Advertisement
Table of Contents
Related Manuals for CSX P330A
Summary of Contents for CSX P330A
- Page 1 ________INSTRUCTION MANUAL_______ P330A 3D Pedometer VIDEO INSTRUCTIONS: www.csxpro.com/p330a LAYOUT 1. LCD display 2. SET Button 3. Metal Pin 4. Battery Case 5. Holes on Wristband 6. Loop Hole FEATURES PEDOMETER CLOCK 3D Silent Pedometer Sensor Display format 12/24 hours Step counter up to 99999 steps ACTIVITY TIME Distance walked up to 999.99 KM/999.99 Miles...
-
Page 2: Setting The Clock
QUICK START GUIDE The P330A pedometer can be setup using the default values, so for a quick setup all you need to do is set the clock. This will provide you with average estimates for your calories burnt and distance walked. - Page 3 4) With the display facing you, tilt the pedometer left or right to change the value 12Hr or 24Hr 5) Press SET button, hour will flash...
- Page 4 6) Tilt the pedometer left and hold in position to decrease the values, or tilt right and hold in position to increase the values. Note: If you selected 12Hr previously and the current time is in the afternoon (PM) make sure you increase the hour number until PM is displayed 7) Once the desired value is displayed tilt the pedometer back to the horizontal position.
-
Page 5: Full Setup
9) Press SET button, KG will flash. If you only want to set the time and use the default values for weight and stride length do not press any more buttons and after 20 seconds the pedometer will exit setup mode. FULL SETUP If you would like more accurate readings you will need to know in advance: a) Your Stride Length (centimeters or inches) ________________________... - Page 6 Example: Total Distance = 310”. Therefore, stride = 310” / 10 paces = 31” Total Distance = 800cm. Therefore, stride = 800cm / 10 paces = 80cm Once you know your stride length and weight, please follow the numbers 1 to 9 in the Quick Start Guide above and then continue with step 10 below: 10) Select Kg or Lb (metric or imperial measurements) –...
- Page 7 13) Once the desired value is displayed tilt the pedometer back to the horizontal position. Press SET button, stride length will flash. 14) Tilt the pedometer left and hold in position to decrease the values, or tilt right and hold in position to increase the values. 15) Once the desired value is displayed tilt the pedometer back to the horizontal position.
- Page 8 PLACING THE ACTIVITY TRACKER INTO THE WRISTBAND When placing the activity tracker into the wristband, make sure the button of the tracker is on the same side as the notch on the wristband. HOW TO WEAR YOUR WRISTBAND Center the activity tracker on top of your wrist, so that the SET button faces away from your hand i.e towards the elbow Snap the pin into one of the holes Tuck the end into the loop hole...
-
Page 9: Clock Function
CLOCK FUNCTION To view the clock, simply press the SET button. Alternatively, you can tap on the LCD display consecutively until the clock is shown. PEDOMETER FUNCTION Steps are recorded when you are wearing the pedometer and motion is detected. The ‘STEP’... -
Page 10: Auto Shut Off / Auto Resume
c) Calories Mode Tap on the display as many times as necessary until the top line of the display shows the word ‘KCAL’. This shows the total calories burned. d) Activity Time Tap on the display as many times as necessary until the top line of the display shows the stopwatch icon. -
Page 11: Performing A System Reset
Always Warm up - Cool down and stretch before and after exercising. This will help prevent straining muscles. CONTACT CSX To contact CSX – Competitive Sport Xtreme, please email or send a support ticket to: support@csxpro.com www.csxprosupport.com...
