OTC ScanPro Elite Quick Start Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ScanPro
LCD
Display
USER
Key
LEFT Arrow
Key
HELP Key
DOWN Arrow
Key
The Quick Start Guide was developed to help
you get started using the Scan Tool. If there are any
problems following these steps or extra information
is required refer to the User's Guide located on
the included CD. All Safety Information is contained
in the User's Guide. Read User's Guide completely
before operating Scan Tool.
Elite
TM
UP Arrow
Key
ENTER
Key
RIGHT Arrow
Key
BACK
Key
ON/OFF
Key

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ScanPro Elite and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for OTC ScanPro Elite

Summary of Contents for OTC ScanPro Elite

  • Page 1 ScanPro Elite UP Arrow Display ENTER USER RIGHT Arrow LEFT Arrow BACK HELP Key ON/OFF DOWN Arrow The Quick Start Guide was developed to help you get started using the Scan Tool. If there are any problems following these steps or extra information is required refer to the User’s Guide located on the included CD.
  • Page 2 General Scan Tool information User interface • The scan tool is designed for easy use. All menus and lists operate the same way. UP or DOWN arrow keys allow movement through lists and  menus. LEFT or RIGHT arrow keys moves between Answers and ...

  • Page 3: Global Function List

    locating data link Connector • The Data Link Connector (DLC) is usually located under the driver’s side dash for OBD II Vehicles and GM OBD I. • For Ford and Chrysler OBD I Vehicles the (DLC) is usually found in the engine compartment. •...

  • Page 4: Gm Function List

    GM Function list The GM Historic (OBD I) Function List is broken down into the following menus: datastream Special Tests View Data Field Service   Review data Record Data  Print data diagnostic Codes Code lookup Read Codes  Erase Codes acronyms ...

  • Page 5: Chrysler Function List

    The Ford Enhanced (OBD II) Function List is broken down into the following menus: Vehicle Information datastream  Modules Present View Data   on demand Tests Record Data  KOEO On Demand diagnostic Codes  KOEO Injector Buzz Read Codes ...
  • Page 6 Tool Functions Not all Tool Functions are available on all vehicles. The Scan Tool will only display functions that are applicable to selected vehicles. View data Views vehicle Parameter Identification Data (PIDs) in real time. PIDs are displayed in either a text format or graph format when available. Record data Records vehicle PIDs while vehicle is parked or being driven.
  • Page 7 Setup User Key Used to program certain Diagnostic Menu or sub menu functions for User Key. State oBd Check Used to display a basic status of the vehicles OBD system. Field Service Special diagnostic mode to monitor fuel system operation and read DTCs. Read KoEo Fast/Slow Codes Activates the KOEO (Key-On-Engine-Off) and Continuous Memory self-tests which retrieves KOEO and Continuous Memory DTCs from the PCM.
  • Page 8 Read Temporary Codes Used on vehicles equipped with Jeep and Truck Engine Controllers (JTEC) and SBEC version III modules. Controller info Provides additional specifications on the PCM and vehicle under test. actuator Test Used to check the operation of many of the computer-controlled relays and solenoids.
