Page 3: Introduction / Overview
Introduction / Overview The SW-SB is an active repeater which will allow the T24 range of modules to span around obstacles or increase range or coverage. The connectivity module provides a battery holder for a pair of alkaline ‘D’ cells and has regulator circuitry for an external power supply. -
Page 4: Combined Solutions
Many Providers Power Options The SW-SB can operate permanently powered or can operate from on-board batteries. Permanently Powered This is the simplest way to operate the repeater. With a permanent supply you do not need to worry about the repeater sleeping or waking. You can optionally choose whether the repeater always wakes sleeping modules and then you could utilise the powering up of the repeater to wakeup those modules outside the normal radio range. -
Page 5: Getting Started
But some modules only wake specific single target modules such as the T24-HS handheld module and the T24-AO1 analog output module. For these modules to wake the repeater they must be fitted with at least v2.1 version radio modules. This only affects repeaters with a SleepDelay set. Straightpoint SW-SB U ANUAL... -
Page 6: Configuration
If you have a USB version of the base station (SW-USBBSE) then you just need to plug this into a USB socket on your PC. If you are using an alternative base station then please refer to the appropriate manual. Straightpoint SW-SB U ANUAL... -
Page 7: T24 Toolkit
T24 Toolkit The T24 Toolkit provides a means of simple configuration of the SW-SB along with useful tools to aid integration. Run the T24 Toolkit software application. General Pages Setup Base Station Communications Select USB as the interface and select 1 as the Base Station Address. -
Page 8: Home
Remove power from the SW-SB module. Click the Pair button on the toolkit. You now have 10 seconds to re-apply power to the SW-SB module. If you connect successfully the toolkit will change to the Information page. If the pairing fails try again. -
Page 9: Analyser
The above charts show the traffic from a Wi-Fi network and it can be seen to be operating over channels 6 to 9 and it would be best (though not essential) to avoid using these channels. Straightpoint SW-SB U ANUAL... -
Page 10: Information
Information This page shows you information about the connected device. Items you can change: Name You can enter a short descriptive name (11 characters) which may help you recognise this device in the future. Straightpoint SW-SB U ANUAL... -
Page 11: Channel And Encryption
NOTE: Channel 16 is used to negotiate pairing so avoid this channel if possible. Encryption Key Only devices with identical encryption keys can communicate. You can isolate groups of devices on the same channel or just use the key to ensure the data cannot be read by somebody else. Straightpoint SW-SB U ANUAL... -
Page 12: Save And Restore
All configuration information including calibration data will be overwritten. The file extension is tcf. Advanced Settings Click this button to enter the Advanced Settings Page. Here are settings which do not normally require changing. Straightpoint SW-SB U ANUAL... -
Page 13: Battery And Radio Levels
Items you can change: Low Battery Level Click this item to set the battery low level. Clicking the Advanced button will give more detailed information on the RSSI and CV levels of the received radio packets. Straightpoint SW-SB U ANUAL... -
Page 14: Battery And Radio Levels Advanced Settings
This page could be used when performing a site survey to determine the signal levels at both the repeater and other T24 modules. Just use the toolkit on a laptop to enable the signal to be tested at different locations. Straightpoint SW-SB U ANUAL... -
Page 15: Settings
The battery level applies to the voltage seen after 3V regulation. The default is 2.2V and can be left at this when the repeater is powered externally. If the repeater is battery powered and you wish to disable this feature select 2.0V Straightpoint SW-SB U ANUAL... -
Page 16: Specifications
Usually using batteries, the SW-SB would be utilising the SleepDelay to return to sleep. Therefore the actual daily usage would allow for far greater than the stated battery life. For example: If the SW-SB was used for 1 hour per day then the battery life would be 6840 hours or 288 days or nearly 10 months.
