- Page 1 HEDÜ Rotationslaser FRE201 Art.-Nr. R154 Ersatzteilliste & Serviceanleitung HEDÜ Rotary Laser FRE201 Art.-No. R154 Part List & Service Manual...
-
Page 2: Rechargeable Batteries
Koffer Case Art.-Nr. / Art.-No. R154-1 ..... 30,00 € 4 Akkus Typ C NiMH 1.2 V 3800 mAh 4 rechargeable batteries Art.-Nr. - Page 3 Gehäuse Oberschale Top cover set Art.-Nr. / Art.-No. R154-5 ..... 18,00 € Oberer Dichtungsring Upper gasket Art.-Nr. / Art.-No. R154-6 ..... . 2,30 € Gehäuse mit Griff, Tastatur und Kabel Housing unit with handle, panel and cable Art.-Nr.
-
Page 4: Remote Control
Gehäuse Unterschale Underpan Art.-Nr. / Art.-No. R154-8 ..... 28,00 € Unterer Dichtungsring Lower gasket Art.-Nr. / Art.-No. R154-9 ..... . 2,30 € Fernbedienung Remote control Art.-Nr. -
Page 5: Main Board
Steuerungsplatine Mainboard Art.-Nr. / Art.-No. R154-11 ....132,00 € Antriebsmotor mit Halteblech, Zahnrad und Kabel Driving motor with stabilizing board, gear and cable Art.-Nr. - Page 6 Nivelliermotor, links X-leveling motor Art.-Nr. / Art.-No. R154-14 ....46,00 € Nivelliermotor, rechts Y-leveling motor Code 25PM15-02-SZ Art.-Nr. / Art.-No. R154-15 ....46,00 € Nivelliermotor leveling motor Code 2510-02-SZ2...
- Page 7 Anschlussplan Hauptplatine Mainboard connection guide Anschluss Gehäuse Unterschale Anschluss Tastatur Connection underpan Connection panel main housing Anschluss Lichtschranke Connection light barrier Anschluss Tilt Selt-alarm PCB Vertikallibelle Z-sensor socket Antriebsmotor Driving motor X-Nivelliermotor X-leveling motor Y-Nivelliermotor Y-leveling motor Laser Anschluss Laser power plug Rechte Libelle X-sensor socket Linke Libelle...
- Page 8 Anschlussplan Pendel Pendulum connection guide Y-axis sensor plug driving motor plug Z-axis sensor plug laser power plug X-axis sensor plug...
- Page 9 Instrument Checking Place the instrument at the point of 50m in front of wall (or set a scaleplate at the point of 50m away from the instrument), and then adjust the level of the base approximately to aim the X1 to the wall (or scaleplate), as depicted below: After switching on the power, use the detector measuring the h1 of X1-beam on the wall or scaleplate.
- Page 10 Level adjusting (old model) If the D-value between h1 and h2 is more than 10mm, adjust the instrument as following steps: Press the key ON/OFF when power indicator lights, automatic leveling of instrument starts up. Press the key simultaneously for 3 seconds when undervoltage indicator winks, the instrument enters mode of adjusting.
- Page 11 Level adjusting (new model) If the D-value between h1 and h2 is more than 10mm, adjust the instrument as following steps: Y-axis adjustment If the instrument is set horizontally, Y-axis adjustment stands for Z-axis adjustment. Press the key ON/OFF when power indicator lights, automatic leveling of instrument starts up. Press the key simultaneously for 3 seconds when mode indicator winks, the instrument enters mode of adjusting.
- Page 12 Malfunctions & Eliminations (Rotary Laser) Failures in starting up Symptoms After pressing the Key ON/OFF, power indicator can’t light and also the instrument doesn’t start up. Causes a. Poor contact of keys on the panel or panel plug. b. Poor contact of batteries or power plug, and insufficient power， c.
- Page 13 Malfunctions & Eliminations (Laser Detector) No responses of detector Symptoms Press the Key ON/OFF, the LCD doesn’t display. Causes a. Install the batteries according to the wrong electrode. b. Panel plug drops out. Eliminations a. Take off the cover of battery case to install the batteries correctly. b.
- Page 14 Top Cover Set...
- Page 15 Housing Set...
- Page 16 Undperpan Set...
- Page 17 Pendulum Z-sensor Y-sensor X-sensor...
