- Page 1 L DC 823A MODE L DIGITAL COUNTER INSTRUCTION MANUAL LEADER ELECTRONICS CORP.
- Page 5 ® SENSITIVITY Selector: Push button switch for 20mV, 200mV, respectively. IMPEDANCE Selector: son. Selector for input impedance of IMn and ® INPUT Connector: Put a signal in to measure. ® Handle/Stand combination: The lock of the handle can be released by pressing the mounted part of the handle on both sides with both hands.
- Page 6 , the danger of an electrical shock can be minimized. Take the same care in disconnecting the input cable. Use AC-power source of LDC-823A at 50 - 60Hz, within 10% of rating voltage. e of Caution: Excessively large or small AC voltages may induce erroneous operation.
- Page 9 Input sensitivity by duty ratio With LDC-S23A, trigger level of Schmidt circuit is set in such a way so that it will the maximum sensitivity against the signal of 50% duty ratio, such as sine wave, triangular wave and rectangular wave. When the duty ratio is reduced, the DC level of the signal added to Schmidt circuit will vary as shown in Fig.
- Page 12 823A to measure the frequency. A normally operating counter displays 10MHz. If you read other than 10MHz, adjust the trimmer capacitor with the screw driver through the hole for adjustment provided at the rear panel of the LDC-823A, in order to make exact accurate display.
- Page 13 (10 5 R 166 R168 IK(l 2.2K Q � 0-1073 SC HEMATI C Moae I DISPLAY COUNTER LEADER ELECTRONICS CORP.
- Page 15 X301 10MHZ 33PF C30S mloop, EXT 0--- -0 5 701 -12v Q40 3 250235-0 - sOV 47'� LDC-823S LDC-823 A 0-1075 SCHEMATIC Model STD.OSC. POWER DIvIDER...
- Page 16 LEADER ELECTRONICS CORP. 2-6-33 TSUNASHIMA-HIGASHI. KOHOKU-KU. YOKOHAMA. JAPAN. PHONE: (045) 541-2121 TELEX:J47780 JPLEADER LEADER INSTRUMENTS CORP. 3 800SER AVENUE. HAUPPAUGE. N.Y. 11788 U.S.A. PHONE: (516) 231 -6900 TELEX: 510-227-9669 LEADER HAUP 84031KM Printed in Japan.
