Summary of Contents for Flexwatch FWR303-00N

  • Page 1 R3 Series FWR303-00N / FWR303-04P / FWR303-08P User Manual ver.1.1 / 2014.1...
  • Page 2 FCC Compliance Statement Model Name: FWR303-00N / FWR303-04P / FWR303-08P This device complies with Part 15 of the FCC Rules. Operation is Subject to the following two conductions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operations.
  • Page 3 【Warning and Caution are indicated as follows.】 Possible injury or product damage. Risk of minor injury or product damage. Cautions for the usage of the product. Information for the usage of the product.

  • Page 4: Table Of Contents

    Chapter １. Introduction ..............4 １-１ NVR Model Major Features ..............4 １-２ Components ..................5 Chapter ２. Installation & Device Connection ........6 ２-１ NVR series Front Panel ................6 ２-２ NVR series Rear..................6 ２-３ Configuration Switch Setup ..............7 ２-４...

  • Page 5: Chapter １. Introduction

    Chapter １. Introduction １-１ NVR Model Major Features Line Up FWR303-00N / FWR303-04P/ FWR303-08P Model Name Embedded Linux - Built in flash memory Access Mouse, Remote Controller, Network, Key controller System Hexaplex Live monitoring, Recording, Playback, Backup, Network, Setup Upgrade USB2.0 Memory stick, Network...

  • Page 6: Components

    Primary 2 HDD Storage External 1 e-SATA ★ 4Ch EOL Register(10K) Digital Zoom x1 ~ x16 Watermarking Detection / Search Motion, Sensor Fan Fail E-mail 5 User with still image Features Capture 1080p iSCS Recording DDNS, DHCP, UPNP CMS, VMS, RMS Windows Smart Phone (3G) Android, iPhone, iPad...

  • Page 7: Chapter ２. Installation & Device Connection

    Chapter ２. Installation & Device Connection ２-１ NVR series Front Panel Name Feature USB Port USB Mouse, USB Memory Stick Connection Port LABEL Brand Name and Model Name POWER LED RECORD LED LED indicating Power On/Off RECORD LED Blue LED turned on upon HDD operation. ２-２NVR series Rear Name Feature...

  • Page 8: Configuration Switch Setup

    Name Feature Type FWR303-04P: DC 48V 1A PoE Power DIN Jack FWR303-08P: DC 48V 2A PoE Port IP Camera Connection RJ-45 Audio In Audio input Audio Out Audio Output e-SATA External SATA USB Type A, e-SATA CCTV monitor displays the output images. HDMI HDMI Output HDMI type-C...

  • Page 9: Chapter ３. Operation, Setup Tools

    controller has the same connection as PTZ camera. ② Sensor / Relay / POS Connect Sensor / Relay / POS to the terminal block directly depending on the model. Sensor and Relay Type NC(Normal Close) : Normally closed; opens when a signal is received NO(Normal Open) : Normally open;...

  • Page 10: Mouse

    PLAY Play ３-２ Mouse The mouse pointer as shown below appears if a mouse is connected to the USB terminal at the front panel. Mouse Control functions are shown below. Monitoring Mode / Move from Play Mode to Monitoring Click on the right Menu / Pop up or remove Play Menu.

  • Page 11: Network Setup

    ４-２ Network Setup Connect the NVR Network Port (found in rear) to Ethernet hub. Connect IP cameras to Ethernet hub. Gigabit HUB are recommended for NVR (1) NVR with one Network Port (2) NVR with one Network Port...

  • Page 12: Ip Camera Registration & Poe Port Connection

    (3) NVR with PoE port ４-３ IP Camera Registration & PoE port connection 4-3-1 Non PoE model ① Check the adapter, and connect the power. ② Once Power cable is connected (found in Rear Side), booting will be enabled. ③ After booting is finished, the NVR can search for IP Cameras within the same ‘network’. ④...

  • Page 13: Nvr With Poe Port

    ID and Password are required for initial installation. Default ID and Password are [ admin : 00000 ] ○ For security purpose, user must log in first to use {Monitoring Menu}. After logging out, the user cannot use {Menu}. 4-3-2 NVR with PoE port NVR with PoE models support the up to FWR303-08P port.

  • Page 14: Monitoring

    Name Feature Type NVR Power DC 12V 5A, 60 Watts DC Jack FWR303-04P: Up to 30w for each channel, total Max. 40w (IEEE 802.3at) PoE Port RJ-45 FWR303-08P: Up to 30w for each channel, total Max. 80w (IEEE 802.3at) PoE Power DC 48V 1A( FWR303-04P), DC 48V 2A(FWR303-08P) DIN Jack (2) Connect the PoE camera to the PoE port and Registration Menu window pops up as below.
  • Page 15 ４-４-１ Real Time Monitoring Mode and Icon After booting is finished, Audio/Recording Status/Channel Title/Connection Status/Time/HDD Status are displayed as shown below. ※ Recording Event / Recording Mode Icon ※ Motion Detection Recording Recording Sensor Recording Event Text Recording Video Recording Recording Audio Recording Mode...
  • Page 16 ④ 16 Channel Screen ⑤ ZOOM function ⑥ Auto Sequence Mode ⑦ Date / Time ⑧ HDD Status ⑨ Playback ４-４-２ Screen Division and Auto Sequence After the system is booted, images will be displayed on a screen divided into 16 division. Except for the basic setting, the system follows user’s setting on the screen division from next booting.
  • Page 17 ※ Auto Sequence Auto Sequence is to rotate images at an interval of the certain time in 1 / 4 / 9 Basic Division. Auto Sequence is not available in the Basic 16 Division mode. ① Move to {Menu}  {Miscellaneous}  {Display Setup}. ②...
  • Page 18 ① Move to {Menu}  {Zoom} or press the zoom icon from the control bar in the real time monitoring mode. ② After selecting a channel, it becomes the 1 channel mode and the zoom control screen sho ws at bottom-right. [Figure 5-1.

  • Page 19: Playback

    Preset / Using horizontal / vertical / Zoom / Focus / Iris movement of PTZ Camera, zoom or focus or Iris a certain spot of the image by designating the coordinates and move to the designated coordinates quickly. Home Position Time - If there are no controlling signals to PTZ camera after a certain time, it goes automatically to the Preset No.1 position as Preset No.
  • Page 20 ４-５-２ Smart Search This function is used to search an image with the object movement at a specific zone quickly. Searching by each channel and a detail control are available. Type Content Sensitivity 5 levels; Lowest / Low / Middle / High / Highest Minimum Mosaic pixel control available between 1- 10 In the NTSC mode, search 30 frames once.

  • Page 21: Setup

    ⑤ It may take time during the searching. Start the playback after searching. ４-５-３ POS Search The Text Data recorded needs to be searched in order to Playback ４-５-４ Calendar Search Move to {Menu}  {Search}  {Calendar Search} and then a searching window pops up. ４-５-５...
  • Page 22 If synchronization with the NTP server fails, synchronization with RTC will be established. 2) Synchronization with the NVR Time Server The DTS server is executed in the NVR system and the time is synchronized every hour. DTS clients of NVR series referring to the DTS synchronize the time of the NVR system with DTS. When the DTS time or a zone is changed, the change is reflected on NVR series belonging to the network (the synchronization signals are broadcasted without passing through the router or gateway).
  • Page 23 By using the arrow keys and the Select button, move the focus onto the desired field; Year/Month/Day Hour/Minute/Second and press the Select button. Select a field you want to change by using the arrow buttons and press the Select button. ②...
  • Page 24 ② IP Camera Find By using the ‘Find’ Button, the NVR can search for IP Cameras within the same ‘network’. After an IP Camera is found, the IP Cameras “Port, ID, password, protocol” can be inputted. Please take careful note that if there is any mistake or ‘typo’ in any of the 4 Settings (Port, ID, PW, Protocol), then connection will not be possible (2) PTZ This enables the user the real-time monitoring by using PTZ camera.
  • Page 25 ※ The Protocol depends on the IP Camera Manufacturer’s protocol. ※ Duration can be selected at 5 / 10 / 15 / 20 / 5-60 (User setting) seconds. ※ Tour consists of Tour 1 / Tour 2 and each tour can be set with 8 Preset. (3) POS Setup the protocol and baud rate of the POS device.
  • Page 26 (1) Schedule Selection (Schedule1 ~ Schedule4) Each channel can be scheduled in 4 different schedules. This schedule can be set as the recording schedule and each time can be 4 different schedules. (2) Event This is to set the events On/Off of Motion / Sensor / Text Input / Text Search. Recording Description Type...
  • Page 27 ③ Bitrate The Recording Resolution ‘Bitrate’ can be changed in this setting. ④ Audio Used to set the recording of the external audio input linked to the system. ⑤ Text Used to set the recording of the external text input linked to the system. (4) Alarm ※...
  • Page 28 ① Select the day and time to be set by using the arrow keys. ② Select after moving the cursor onto Time(0-23) or Day(Sun. – Holiday) then the user can co nfigure the whole line at once. ③ Using the mouse can be easier. (2) Holiday Registration This feature is used to enable the user to set the holidays and schedule independently.
  • Page 29 (3) Local Storage Management ① Local Storage Management Function Local Storage refers to the internal hard disk and storages connected to the system via USB. Local Storage is classified and managed as {Recording}, {Backup}, {New}, {iSCSI} and functions are described below. ②...
  • Page 30 1. Fault State: The storage device is completely damaged, and none of the S/W operations can be performed. The fault state is not related to a NVR problem. The NVR has detected the fault and stopped the recording. 2. Warning State: The storage device has a physical error that can be corrected by the storage device or by the NVR.
  • Page 31 ４-６-６ Network (1) Ethernet This is to use a fixed IP in the Local Area Network environment. ① IP Address, Subnet Mask, Default Gateway, Primary DNS, and Secondary DNS will be set automatically when the {Ethernet Type} was selected to ‘DHCP’. ②...
  • Page 32 The default value is 50100; a randomly chosen value can be used depending on the network environment. The Web Server Port is used to connect the NVR remote monitoring. The Web Port Default is 80, but can be set between 2000 ~ 65527.
  • Page 33 ② Relay SMTP is set on ‘Gmail’ as default, but when ‘Default’ (in menu tab) is selected, this will changed to dvr@cctvuser.com. ③ Receiver Email can be set up to 5 users (emails). ④ Email Interval settings are as follows [5 sec / 1 min / 3 min / 5 min /10 min]. (5) Bandwidth Move to {Menu} ...
  • Page 34 (2) ID For Keyboard Controller ① Move to {Menu}  {Setup}  {System}  {2. ID for Key Controller}. ② In the selection window, enter ID by using the arrow keys and the Select button (number 1~255 is available for ID.) (3) User Registration ※...
  • Page 35 ① Firmware Upgrade ① Select {Firmware} and the upgrade file list stored in the selected device and simple version info of the selected file are then displayed. Select a file and Firmware Upgrade window appears. ※ Downgrading to a previous version is not supported. ※...
  • Page 36 [Buzzer/ E-mail/ Relay01/ System check]. Select each [Off/Buzzer/E-mail/Relay01/Popup Window] by ticking. ※ Popup Window Setup at {Menu}  {Setup}  {System}  {7. Alarm}. Popup Window is to pop up the system check window in the monitoring screen as shown. it indicates [Video Signal loss/ HDD full/ HDD Not Detect / FAN fail/ Storage Fail/ Storage Warning / Sensor Connection Tamper].

  • Page 37: Search

    ４-７ Search ４-７-１ Search Mode Move to {Menu}  {Search} in the real-time monitoring mode. (1) Calendar Search Calendar Search allows the user search and playback by [Year / Month / Day / Hour / Minute], [Multi- Channel / Multi-Time / Multi-Day] and [Motion / Sensor]. ①...
  • Page 38 ④ Event Event is to search the data by the events. Select [All / Motion / Sensor]. ⑤ Multi-Channel Search The Multi-Channel Search is to play recorded images of the different channel over a certain designated time. ⑥ Multi-Time Search The user can playback the video contents of the certain channel recorded in the different time zone simultaneously.

  • Page 39: Backup

    (5) POS Search Text Data can be searched and used for playback [Year / Month / Day / Hour / Minute], [Text 1] ① POS Search Mode On the real-time monitoring screen, select {Menu}  {Search}  {POS Search} and then a searching window pops up as shown below.
  • Page 40 mode, and the end time, to the last minute/second of the data existing at the selected time. ④ All channels with existing data at the time of backup are backed up automatically. ⑤ For the remaining backup procedures, see [5-12-5 Common Backup Procedure]. (3) Backup in Log Mode ①...
  • Page 41 channel to be displayed and the size of the file to be backed up to be calculated. ⑤ The directory is named as same with the backup time. The first 12 digits are determined by the year/month/day/hour/minute/second for From, and the 12 digits in the middle, by the ye ar/month/day/hour/minute/second for To.
  • Page 42 ４-８-１ Capture The Capture function lets the user create a JPG file in the real-time monitoring, playback, search, or log mode and back up the image data. ① To back up the currently displayed image, select {Menu}  {Backup}  {Capture} in real- time monitoring, Playback and Log mode.

  • Page 43: Chapter ５. Miscellaneous

    ① For the Setup Backup, a device for backup must be connected. ② Move to {Menu}  {Backup}  {Setup Backup} and a window shown below appears. The setup is copied by the name shown below. Saved as the name below. ①Model ②...
  • Page 44 Log Type Logs related to power ON / OFF, file copy/backup failure, setup start/end, General playback, and other basic system operations. Logs related to the recording including motion detection and sensor Recording Event detection. Logs related to network operations including network login, network Network logout, and network live.
  • Page 45 Time Changed Log Data View The stored data folder is created each time the user changes the time. A blue triangular icon is displayed at a date in the calendar window that time changes are made. Otherwise, a red triangular icon is displayed at an unchanged date. To view the log details, select the desired date with a red icon.
  • Page 46 ５-１-４ Display Setting Camera Title On/Off, Control Bar On/Off, Button Sound On/Off, Border Line Draw/Width/Color, Screen Saver, Main Sequence. After selecting Display Setting, it becomes the 1 channel mode and a menu pops up as shown below. ① Screen Saver Monitor connected with NVR can be shut down to protect monitor.

  • Page 47: A/P/P/E/N/D/I/X

    A/P/P/E/N/D/I/X Recommended HDD Specification Recommended USB2.0 Devices USB2.0 Device Media File System Memory Stick Flash Type FAT32 2.5’’ Portable USB HDD HDD Type FAT32...
