Summary of Contents for SyncCam GS60
-
Page 1: Document Camera
Document Camera GS60 USER MANUAL Please read this manual carefully before operating the document camera and keep it for reference. - Page 2 NOTICES: PLEASE READ CAREFULLY BEFORE USE Use the document camera under the rated electric conditions. Do not place the document camera on any unstable surface. It may fall and cause injuries or damages. Do not place this device under direct sunlight or near heaters. ...
-
Page 3: Table Of Contents
CONTENTS PART NAME AND FUNCTIONS: ............1 Appearance: ........................... 1 Rear Panel ..........................2 Side Panel ..........................3 Control Panel: ........................4 REMOTE CONTROL ................6 ON BOARD ANNOTATION AND CONTROL ........8 MULTIMEDIA SYSTEM..............10 USB SOFTWARE ................. 12 CONNECTION: ........................ -
Page 4: Part Name And Functions
PART NAME AND FUNCTIONS: Appearance:... -
Page 5: Rear Panel
Rear Panel DC12V : power input VGA IN : VGA input AUDIO IN : audio input for VGA input HDMI IN : HDMI input HDMI OUT : HDMI output Audio OUT : audio output for VGA output VGA OUT : VGA output USB-PC : USB connector, used to connect with PC. -
Page 6: Side Panel
Side Panel SD-CARD : SD card connector : USB connector, used to connect USB mouse or USB memory sticker. ZOOM KNOB : Zoom in/zoom out knob : USB connector, used to connect USB mouse or USB memory sticker. POWER : Power button, power on or power off. KENSINTON : Kensington lock... -
Page 7: Control Panel
To switch to PC input. 4. SAVE: Capture and save the image to Memory stick, SD card, or built-in memory. GS60 can detect when there is an external storage media and automatically save the images to SD card or USB memory stick. If there is no external storage connected, all captured image will... - Page 8 5. RECORD: To start/stop recording a video. RECALL: Image recall mode enabled, display the saved images and video clips. PIP: To enable the picture in picture mode. TITLE: To freeze the title area. 9. MIRROR: To toggle horizontal mirror , vertical mirror and horizontal+vertical mirror. SPLIT: To get image split.
-
Page 9: Remote Control
REMOTE CONTROL... - Page 10 To start/stop recording a video. 14. SAVE: Capture and save the image to Memory stick, SD card, or built-in memory. GS60 can detect when there is an external storage media and automatically save the images to SD card or USB memory stick. If there is no external storage connected, all captured image will be saved in the built-in memory.
-
Page 11: On Board Annotation And Control
ON BOARD ANNOTATION AND CONTROL GS60 allows on board annotation and control by connecting a USB mouse to it. We will see the following icons by clicking the left button on a mouse: IMAGE : To freeze the current image, and annotation function activated. - Page 12 Then click IMAGE or ANNOTATION icon to active the annotation function: CAMERA : To go back to camera image. COLOR : To change the color of the annotation. THICKNESS : To change the thickness of the annotation ERASER : To erase the annotation in selected area. ERASE ALL : To delete all the annotation.
-
Page 13: Multimedia System
MULTIMEDIA SYSTEM GS60 embedded a multimedia system, which allows you surf the internet, open files that in USB memory stick or SD card without PC. Click the Home button by connect a USB mouse. CAMERA : To got to the camera image... - Page 14 DEVICE : choose Device, you can change the following setting: : To select NET to active wireless connection between GS60 and PCs, iPhnoes, Android phones or other tablets. : To select USB to active USB connection between GS60 and PCs.
-
Page 15: Usb Software
3) Connect the PC to the same wifi signal. SOFTWARE: Install the provide software to the PC follow the procedures. Double click “Synccam” to run the software, selecting the right models, then you can use the USB software. ：To place a beeline into the image. - Page 16 COLOR : To select the color of annotation. SAVE : To save the image to PC. RECORD : To record a video clip to PC. SETTINGS : To change the settings of the image. INFO : To check the version information of the software. AUTO : To adjust white balance and focus automatically.
-
Page 18: Mobile Software
MOBILE SOFTWARE: GS60 gets an optional configuration, wifi function. By carrying wifi function, GS60 could connect to laptops, Iphones, Android phones or other tablets wirelessly. You have to choose”NET” in “DEVICE” of system settings first. 1) Active the wifi function of GS60, select a nearby wifi signal and connect 2) Connect the mobile device to the same wifi signal. -
Page 19: Specifications
SPECIFICATIONS: Model GS60 Total pixel 8 Megapixel 1/2.7“ CMOS Sensor Zoom 12x optical, 10x michanic, 12x digital Shooting area Focus Auto/manual Output signal 720P/1080P ≥1000 TV lines Resolution(horizontal) Image capture Yes(image memory: 1000 pictures) Video recording One touch on board recroding... -
Page 20: Trouble-Shooting
TROUBLE-SHOOTING: Symptoms Possible causes/counter-measures No image 1. Power cord is not properly connected. 2. VGA/HDMI cables are not properly connected. 3. Power switch is not turned on. Upper light not on 1. The filament is broken. Change the bulb. 2. The lamp is not fully plugged in its holder: Image bending Camera not in right position, adjust the camera.
