Coodmans GPS217PLLR Instruction Manual

Stereo cd/radio/cassette recorder
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
STEREO CD/RADIO/CASSETTE RECORDER
For improvement purposes, specification and design are subject to change without notice.
GPS217PLLR
Instruction Manual
MUTE
POWER
TIMER
SLEEP
1
2
3
4
5
6
7
8
9
0
INTRO/STEREO
PROGRAM
FUNCTION
RANDOM
REPEAT
EQ
M-DOWN
M-UP
BACK
NEXT
DBBS
STOP/BAND
PLAY/PAUSE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GPS217PLLR and is the answer not in the manual?

Questions and answers

Related Manuals for Coodmans GPS217PLLR

Summary of Contents for Coodmans GPS217PLLR

  • Page 1 STEREO CD/RADIO/CASSETTE RECORDER GPS217PLLR Instruction Manual MUTE POWER TIMER SLEEP INTRO/STEREO PROGRAM FUNCTION RANDOM REPEAT M-DOWN M-UP BACK NEXT DBBS STOP/BAND PLAY/PAUSE For improvement purposes, specification and design are subject to change without notice.
  • Page 2 IMPORTANT SAFEGUARDS PRE FITTED MAINS PLUGS For your convenience a mains plug has been fitted to this appliance. For your safety please observe the following information. 1. Should the fuse in the plug fail remove the plug from the wall socket and replace the fuse with a 3 Amp ASTA fuse approved to BS 1362.
  • Page 3 1. IMPORTANT NOTES Your hearing is very important to you and to us so please take care when operation this equipment. The following guidelines are provided for your information. ESTABLISH A SAFE SOUND LEVEL • Over time your hearing will adapt to continuous loud sounds and will give the impression that the volume has in fact been reduced.

  • Page 4: Table Of Contents

    TABLE OF CONTENTS SAFETY PRECAUTIONS POWER SOURCES..........4 1. As the laser beam used in this compact PLAYER MAINTENANCE......4 disc player is harmful to the eyes, do not DISC CLEANING..........5 attempt to disassemble the casing. 2. Stop operation immediately if any liquid or PLAYER OPERATION solid object should fall into the cabinet.

  • Page 5: Power Sources

    2. POWER SOURCES AC MAINS BATTERY OPERATION Insert the plug of AC power cord into wall Remove the Battery Compartment Cover and outlet and the connector into AC Socket Press insert 8 pcs UM-1 (Size D) batteries, replace the Power On/Off Button to turn on the unit. the cover.

  • Page 6: Disc Cleaning

    4. DISC CLEANING Cleaning the Disc 1. To handle a disc use only one of the two manners illustrated. Note Do not touch the rainbow - coloured Side. 2. To wipe a disc, use only a soft cloth. Do not use benzene or thinner which will damage the disc.

  • Page 7: Location Of Controls

    5. LOCATION OF CONTROLS LOCATION OF CONTROLS 1. Aerial 2. Handle 3. CD & Cassette Door 4. Record Key (Cassette) 5. Play Key (Cassette) 6. Rewind Key (Cassette) 7. Fast Forward Key (Cassette) 8. Stop Key (Cassette) 9. Pause Key (Cassette) 10.
  • Page 8 6. LOCATION OF CONTROLS 1. Mute Button 2. Timer Button MUTE POWER 3. Numeric Buttons TIMER SLEEP 4. Function Button 5. Random/Memory Down Button 6. Tuning Down/CD Skip Button 7. Tuning Up/CD Skip Button INTRO/STEREO PROGRAM 8. CD Stop/Band Button FUNCTION RANDOM REPEAT...

  • Page 9: Operating Instructions

    7. OPERATING INSTRUCTIONS rear will are at FUNCTION repeatedly until FM or MW appears in display the BAND button If there is a large amount of background noise(hiss) when listening to a station in FM STEREO press the INTRO/STEREO button to listen to the station in MONO. for approximatly 1 second.
  • Page 10 Preset Stations wareband. on the remote or MEMORY on the main unit or MEMORY key Only 10FM and 10AM presets can be stored. Press the Power button, the standby indicator will turn off. / Cassette / Cassette Door. Playback will begin automatically with track 1. will / Cassette pause the disc.

  • Page 11: Operating Instructions

    8.OPERATING INSTRUCTIONS Press Repeatedly subsequent Repeatedly previous Press and hold skip Up/Search Forward or Skip Down/Search Backward button to Search Forwards or backwards at high speed for a specific passage of a track. Normal playback will resume when the button is released. from flash appears steadly...
  • Page 12 will shown on the display. will resume. playback in random order. again and NORMAL play will resume. EQ OFF CLASSIC ROCK JAZZ to be programmed on remote or MEMORY on main unit. to be programmed or MEMORY button to store the track .
  • Page 13 CLOCK SETTING 1) Press the STANDBY/ON button to turn the unit to standby. 2) Press and hold the PROGRAM button on the remote or MEMORY button on the main unit, 24Hr will appear on the display. Press the skip/search button. To set 24 Hour or 12 hour time format.

  • Page 14: Cd Remote Control Operation

    9. CD REMOTE CONTROL OPERATION 3. INTRO/STEREO button IN CD MODE: again to resume In FM Radio Mode: Select Stereo/Mono reception when listen to an FM station. Mute ON/OFF. 7. DBBS button Press DBBS button to boost bass sound level or turn off bass boost.

  • Page 15: Cassette Tape Operations

    10. CASSETTE TAPE OPERATIONS Playing A Cassette Tape 1. Select the Tape function by pressing the FUNCTION button. 2. Open the Cassette Tape door. 3. Insert a cassette tape into the cassette deck with the full reel on the left side. Close the CD/Cassette Door.
  • Page 16 4. Press the Cassette Record button. The Cassette Play button will also engage and recording will begin. If you wish to stop the tape temporarily to avoid recording certain material, press the Cassette Pause button. Press again to resume recording. 5.
  • Page 17 Safeguard Against Accidental Erasure When a new recording is made, any program material previously recorded is automatically erased and only the new recording remains. To safeguard valuable recordings from being erased accidentally, the cassette and the deck are equipped with a tab. On the back of the cassette there is an erase prevention tab on each side.
  • Page 18 Cleaning The Unit • To prevent fire or shock hazard, disconnect your unit from the AC power source when cleaning. • If the cabinet becomes dusty wipe it with a soft dry dust cloth. Do not use any wax or polish sprays on the cabinet. •...

  • Page 19: Troubleshooting Guide

    11. TROUBLESHOOTING GUIDE Should this unit exhibit a problem, check the following before seeking service. Symptom Possible Cause Solution Radio Noise or sound distorted Station not tuned properly for Retune the AM or FM station. on AM or FM AM or FM. broadcasts.

  • Page 20: Technical Specification

    12. TECHNICAL SPECIFICATION Model : GPS217PLLR Specification Main Unit FM section Tuning range: 87.5 MHz – 108 MHz Usable sens.: 20db Antenna: telescopic MW section Tuning range: 522 kHz – 1620kHz Usable sens.: 61dB/M Antenna: Ferrite bar Amplifier Power output (at 10% THD): Max.
