home
ELITE
Straight Rail Stairlift
Operator's Manual
Technical Service email: service@homeadapt.com
www.homeadapt.com
Keep this manual in a safe and readily accessible place
for future reference.
Unit 5, Millennium Court, Clayhill Industrial Park
Neston, Wirral CH64 3UZ
United Kingdom
Tel: 0151 559 0732
REV. 29 January 2015
Advertisement
Table of Contents
Related Manuals for Homeadapt ELITE
Summary of Contents for Homeadapt ELITE
- Page 1 ELITE Straight Rail Stairlift Operator’s Manual Technical Service email: service@homeadapt.com www.homeadapt.com Keep this manual in a safe and readily accessible place for future reference. Unit 5, Millennium Court, Clayhill Industrial Park Neston, Wirral CH64 3UZ United Kingdom Tel: 0151 559 0732...
- Page 2 Homeadapt fitter. Homeadapt reserves the right to use information indicated on this form in its online, video, audio and printed materials. Names will be abbreviated to ensure the privacy and anonymity of the individual. Rev. 01-14-2015 ©2015,2008 Homeadapt P/N PROD REG UK ©2015,2008 Homeadapt...
-
Page 3: Table Of Contents
Safety/Emergency Operation ....6-8 Parts of the Elite ....... 9 Circuit Breaker . -
Page 4: Specifications
Control: constant pressure (armrest and two remotes) Maximum Incline: 45 degrees Seat Swivel: 0, 60 and 90 degrees at the top; 45 degrees at the bottom Battery Charger: 24VDC battery charger powered by 240V outlet ©2015,2008 Homeadapt Elite Operator 29jan2015... - Page 6 • Be certain the seat swivel is locked in place before attempting to get on or off the stairlift. • Remove the key after turning off the Elite to prevent accidental operation due to someone or something coming in contact with the key.
- Page 7 Your Elite Stairlift is battery powered and will continue to operate for some time during a power failure. The length of operation will depend on the battery condition, the length of the stairs and the weight of the rider.
-
Page 8: Safety/Emergency Operation
• Have unit serviced by a qualified technician. Any change in the use of the stairlift should be discussed with Homeadapt to determine if alterations are necessary. Changes in use include, but are not limited to: • change of user disability;... - Page 9 ELITE armrest UP / DOWN rocker switch ON/OFF keyswitch swivel release folding seat in riding position folding footrest with safety edges ©2015,2008 Homeadapt Elite Operator 29jan2015...
-
Page 10: Circuit Breaker
CIRCUIT BREAKER The Elite includes an ON/OFF switch with a built-in circuit breaker located on the back side of the carriage. The circuit breaker protects the battery, controller and motor circuits in the stairlift carriage. It is unlikely that this circuit breaker will trip during normal use. -
Page 11: Seating
SEATING The seat assembly on the Elite is designed to swivel 90 degrees (with standard armrests), and to lock in one of the following positions: 0, 60, and 90 degrees at the top, and (optional) 45 degrees at the bottom*. -
Page 12: Operation
A safety switch prevents operation of the to begin the gentle acceleration of the Elite unless the seat is locked in keyswitch stairlift to operating position at right angles to the rail (the speed. - Page 13 Swivel the empty seat back to its locked position. Remote call / send transmitters are designed to call / send an empty seat only! The transmitters are NOT designed to move a seat with a person on board. ©2015,2008 Homeadapt Elite Operator 29jan2015...
- Page 14 (with your back to the stairway wall). A safety switch prevents operation of the Elite unless the seat is locked in position at right angles to the rail (the “riding” position). 3. Position both feet securely on the footrest and place your arms on the armrest cushions.
- Page 15 • If the unit stops unexpectedly while traveling, check for obstructions or excessive loading. You will only be able to run the unit in the opposite direction until the overload is cleared. ©2015,2008 Homeadapt Elite Operator 29jan2015...
-
Page 16: Optional Power Footrest
This will produce a sequence error. To restore normal footrest operation: ▫ Clear the jam. ▫ Move the seat up and down until the footrest moves again. ▫ If normal footrest operation is not restored, contact a Homeadapt Service Representative. ©2015,2008 Homeadapt Elite Operator 29jan2015... -
Page 17: Optional Folding Rail
To fold rail UP: 1. Raise the lever by pushing right-hand installation down on the “down” side of the shown here lever. 2. Lift up the folding rail section. lever lift up rail ©2015,2008 Homeadapt Elite Operator 29jan2015... - Page 18 OPERATION OPTIONAL Folding Rail To fold rail down: 1. Push the folding rail section right-hand installation down. shown here 2. Push down on the top of the lever to lock the rail in position. lever ©2015,2008 Homeadapt Elite Operator 29jan2015...
-
Page 19: Optional Power Folding Rail
Failure to observe this warning could result in injury or Riding the stairlift: damage to equipment. If you are at the top of the staircase, ride down as previously instructed until you contact the mid-stop. (continued on next page) ©2015,2008 Homeadapt Elite Operator 29jan2015... - Page 20 When the rail is in its fully up position, press the UP armrest switch again to travel the rest of the way up the staircase. (continued on next page) ©2015,2008 Homeadapt Elite Operator 29jan2015...
- Page 21 Then press the transmitter UP button again to raise the rail. Be sure to stand clear of the rail while it folds up! ©2015,2008 Homeadapt Elite Operator 29jan2015...
- Page 22 Be sure to press the switch AWAY from DISABLE to allow the rail to fold and unfold correctly under power! ©2015,2008 Homeadapt Elite Operator 29jan2015...
-
Page 23: Diagnostic Codes
Charging Off Charge (Running) Parked and Charger Not Detected Battery Voltage Critical (Charge Immediately) Battery Voltage Low Seat Safety Switch Open Up Limit Switch Open Down Limit Switch Open Mid-Rail Park Active Soft Stop Switch ©2015,2008 Homeadapt Elite Operator 29jan2015... -
Page 24: Charging
Failure to keep the batteries charged, or allowing them to fully discharge, will significantly shorten the life of the batteries. The green LED on the carriage (see left) confirms that the unit is charging. Green LED glows when unit is charging. ©2015,2008 Homeadapt Elite Operator 29jan2015... - Page 25 LED occasionally turns off BLINKS BLINKS low voltage indication ALTERNATELY ALTERNATELY BLINKS BLINKS battery defective or heavily ALTERNATELY ALTERNATELY sulfated FAST BLINK partially open circuit; bad contact or battery sulfation battery connector reversed ©2015,2008 Homeadapt Elite Operator 29jan2015...
- Page 26 2. Remove power cord from wall outlet. 3. Twist the fuseholder cap and pull out to charger power switch remove the fuse. 4. Replace with the same size and type fuse: (Bussmann GMD-2A or equivalent) 2A, Slo-Blow, 5 x 20mm. ©2015,2008 Homeadapt Elite Operator 29jan2015...
- Page 27 MAINTENANCE Your Elite Stairlift is designed to provide many years of reliable service with minimal maintenance. For best service life: • Keep the rail clean and free of debris. • Always park the carriage at one end of the rail so that the batteries charge when the stairlift is not in use.
- Page 28 TROUBLESHOOTING Your Elite Stairlift is not operating correctly. What should you do? Before calling your Homeadapt dealer, refer to the solutions listed below. This could save you an unnecessary service call! • Seat swivel. Is the seat locked in the riding position? •...
-
Page 29: Battery Charger
• Visual check. Do you notice anything about your stairlift that is different or out of place? If your Elite continues to function improperly or not at all after completing the preceding checklist, contact an authorized Homeadapt dealer to perform all required service, repair and maintenance operations. -
Page 30: Holiday And Long-Term Storage
HOLIDAY AND LONG-TERM STORAGE If the Elite will remain unused for an ex- tended period of time, turn off the circuit breaker (ON/OFF switch) located on the stairlift carriage (see left), then unplug the battery charger from the wall outlet. - Page 31 ◊ All MAJOR COMPONENTS are free of defects in material and workmanship for a period of fi ve years after the date of installation. ◊ All labor to address any product defect by a Homeadapt Authorized Dealer is covered for the fi rst 30 days after installation.
-
Page 32: Warranty
(including negligence, strict liability or product liability). ◊ Homeadapt reserves the right to replace, repair or, if not commercially practical and/or feasible, to elect to refund the purchase price at its sole discretion.
