Summary of Contents for Global American 1404150
- Page 1 Quick Installation Guide 1404150 Version 1.0...
- Page 2 Intel is a registered trademark of Intel Corporation. Award is a registered trademark of Award Software, Inc. All other trademarks, products and or product's name mentioned herein are mentioned identification purposes only, trademarks and/or registered trademarks of their respective companies or owners. 1404150 QIG Page 2...
-
Page 3: Packing List
Form Factor: Standard 4U, 19” wide „ SBC Form Factor: Full-size, slot CPU cards „ Construction: Metal „ Slot Number: 14 slots for 1404150 7 slots for 1404150ATX Screw Label (refer „ Cooling: 2 x 8cm fans Peripherals/Parts to the picture „... -
Page 4: Dimension Drawing
DIMENSION DRAWING The dimensions of 1404150 are shown in the figure below. PO WER 481.8 Figure 1: Dimension Drawing (measurement units: millimeter) 1404150 QIG Page 4... -
Page 5: Installation Steps
Please refer to the relevant section. STEP 1: UNPACK Figure 4: Hold-Down Clamp Retention Screws The 1404150 is shipped in a plastic bag that is placed inside a cardboard box. When the chassis is unpacked, make sure STEP 3: INSTALL THE POWER SUPPLY UNIT (PSU) „... -
Page 6: Step 4: Backplane Installation
PSU frame retention screws. Step 0: Figure 6: PSU Internal Retention Screws The 1404150 chassis can also support a redundant PSU. To install a redundant PSU, follow the steps outlined below: Step 1: Remove the PSU frame by removing the four retention Figure 9: Redundant PSU Retention Screws screws from the rear of the chassis. -
Page 7: Step 5: Cpu Card Installation
Figure 16: Backplane-to-CPU Card ATX Cable STEP 6: PCI/ISA EXPANSION CARD INSTALLATION The 1404150 supports up to thirteen PCI/ISA expansion cards with backplane rear panel, seven with motherboard rear panel. If you wish to install a PCI expansion card or an ISA expansion card please follow the instructions below. -
Page 8: Step 7: Internal Hdd Installation
Step 0: STEP 7: INTERNAL HDD INSTALLATION The 1404150 chassis supports an internal HDD on the top of the fan bracket. To install an internal HDD, follow the steps below: Step 1: Remove the two internal HDD clamps by removing the four HDD clamp retention screws, two for each clamp. - Page 9 Figure 25: Left 3.5” Drive Bay Front Cover Retention Screws Step 3: Mount a 3.5” FDD onto the 3.5” drive bay. Make sure both 1404150 QIG Page 9...
-
Page 10: Step 11: Front Handle Installation
Reset Switch cable Please ensure that the power of the computer is switched off before fan replacement procedure. There are two 8 cm cooling fans inside the 1404150 chassis. To replace a fan, please follow the steps below. HDD LED cable Step 1: Open the front panel. - Page 11 „ 1404150 ATX Installation Global American, Inc also offers the 1404150 ATX chassis that is compatible with motherboards. Figure 32: Disconnect the Fan Connector The compatible Global American, Inc motherboards are listed in Table 4...
- Page 12 Step 7: Mount the motherboard onto the base of the chassis. Make sure the I/O connectors of the motherboard are installed in the corresponding holes in the I/O connector bracket. Figure 39: Plastic Pillar in the Motherboard 1404150 QIG Page 12...
- Page 13 I/O connector. Figure 42: I/O Connectors installed in the I/O Connector Bracket Step 9: Insert five retention screws to secure the motherboard to the base of the chassis. Step 10: Step 0: Figure 43: Motherboard Retention Screws 1404150 QIG Page 13...
- Page 14 Any advice or comments about our products and service, or anything we can help you with please don’t hesitate to contact with us. We will do our best to support you for your products, projects and business. Global American Inc. Address: 17 Hampshire Drive...
