Summary of Contents for Case IH BC12000ER

  • Page 1 BC12000ER...

  • Page 2: Table Of Contents

    table of contents Introduction 4    Using the Operators Manual Product Identification 5    Generator 5    Engine Safety 6    Safety Rules 6    Hazard Symbols and Meanings 9     Ground Fault Circuit Interrupter Protection 11   Important Safety Instructions Glossary 13  Glossary Generator Components 14  12000ER Component Chart 15  Spare Parts List 17  Sockets Features 18  Features Operation 19  Unit Grounding Starting the Generator 19  Filling Oil 20 ...
  • Page 3 table of contents Stopping the Generator 23  Disconnect Load 23  Turn Off The Engine Switch 24  Close The Fuel Valve Lever Storage 24  Drain The Fuel 24  Protective Treatment Transporting 25  Transporting Accessories 26  Accessory Installation 26  Two-Wheel Short Axle Maintenance 27  Maintenance Chart 28  Replace Engine Oil 28  Clean Air Cleaner 29  Clean The Fuel Valve Lever Sediment Cup 29  Clean The Spark Plug 30  Valve Clearance Troubleshooting 31  Troubleshooting Chart 32 ...

  • Page 4: Introduction

    introduction Attention: Read through the complete manual prior to the initial use of your generator. Using the Operator’s manual The operating manual is an important part of your generator and should  be read thoroughly before initial use, and referred to often to make sure  adequate safety and service concerns are being addressed. Reading the owner’s manual thoroughly will help avoid any personal  injury or damage to your machine. By knowing how best to operate this  machine you will be better positioned to show others who may also  operate the unit. This manual contains information for the complete range of CASE  generators, and was written to take you from the safety requirements  to the operating functions of your machine.  You can refer back to the  manual at any time to help troubleshoot any specific operating functions,  so store it with the machine at all times.

  • Page 5: Product Identification

    product identification Record Identification Numbers Generator If you need to contact an Authorized Dealer or Customer Service line  (1-855-850-6668) for information on servicing, always provide the  product model and identification numbers. You will need to locate the model and serial number for the machine and  record the information in the places provided below.  Date of Purchase: Dealer Name: Dealer Phone: Product Identification Numbers Model Number: Serial Number:...

  • Page 6: Safety

    safety Save these Instructions SAFETy RUlES This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. The safety alert symbol (      ) is used with a signal word (DANGER,  CAUTION, WARNING), a pictorial and/or a safety message to alert you  to hazards.  DANGER indicates a hazard which, if not avoided, will result in death or ...
  • Page 7 safety WARNING Generator exhaust contains carbon monoxide, a  poisonous gas that can kill you.  You CANNOT smell or see this gas. • Use the generator outdoors, away from open windows, vents, or    doors that could allow the carbon monoxide gas to come indoors.    Keep the generator at least 1 meter (3 feet) away from any structure      or building during use.   • NEVER use a generator indoors, including in homes, garages,    basements, crawl spaces, and other enclosed or partially-enclosed   areas, even with ventilation. Opening doors and windows or using   fans will not prevent carbon monoxide build-up in the home. • NEVER use a generator in enclosed or partially-enclosed spaces.   Generators can produce high levels of carbon monoxide very quickly.       When you use a portable generator, remember that you cannot smell      or see carbon monoxide. Even if you can’t smell exhaust fumes, you       may still be exposed to carbon monoxide. • NEVER operate the generator in an explosive atmosphere, near   combustible materials or where ventilation is not sufficient to carry   away exhaust fumes. Exhaust fumes can cause serious injury or death. • If you start to feel sick, dizzy, or weak while using a generator, get   to fresh air RIGHT AWAY. DO NOT DELAY. The carbon monoxide   from generators can rapidly lead to full incapacitation and death. • If you experience serious symptoms, get medical attention    immediately. Inform medical staff that carbon monoxide poisoning   is suspected. If you experienced symptoms while indoors, have    someone call the fire department to determine when it is safe to   re-enter the building.
  • Page 8 safety WARNING Fuel and its vapors are extremely flammable and explosive. Fire or explosion can cause severe burns or death. When Adding or Draining Fuel • Observe all safety regulations for the safe handling of fuel. Handle   fuel in safety containers. If the container does not have a spout, use   a funnel. • Do not overfill the fuel tank, leave room for the fuel to expand. • Do not refill fuel tank while the engine is running. Before refueling the    generator, turn it off and let it cool down. Gasoline spilled on hot   engine parts could ignite. • Fill the tank only on an area of bare ground. While fueling the tank,   keep heat, sparks and open flame away. Carefully clean up any spilled    fuel before starting engine. • Always fill fuel tank in an area with plenty of ventilation to avoid    inhaling dangerous fumes. • NEVER store fuel for your generator in the home. Gasoline, propane,   kerosene, and other flammable liquids should be stored outside of    living areas in properly-labeled, non-glass safety containers. Do not      store them near a fuel-burning appliance, such as a natural gas water     heater in a garage. If the fuel is spilled or the container is not sealed     properly, invisible vapors from the fuel can travel along the ground and        can be  ignited by the appliance’s pilot light or by arcing from electric      switches in the appliance.

  • Page 9: Ground Fault Circuit Interrupter Protection

    safety GROUND FAUlT CIRCUIT INTERRUPTER PROTECTION These generators are equipped with a GFCI (Ground Fault Circuit Interrupters) 120V duplex receptacles for protection against the hazards of electrical shock from defective attachments such as, tools, cords, and cables. WARNING The GFCI may not function unless the generator is properly  grounded. Follow the correct procedure specified in the section  labeled GROUNDING INSTRUCTIONS. A GFCI is a device that interrupts electricity from either the utility or generator by means of a special type of circuit breaker that determines if  a current flow to the ground occurs. A GFCI can be used only with generators that have the neutral wire internally bonded to the frame, and the frame properly grounded to the earth. A GFCI will not work on generators that do not have the neutral wire bonded to the frame, or on generators which have not been properly grounded. All Case generators have internally bonded ground wires. ...
  • Page 10 safety This product has been designed with internal grounding or floating  bonded neutral. If it should malfunction or breakdown, grounding pro- vides a path of least resistance for electric current to reduce the risk of  electric shock. DANGER Improper grounding can result in a risk of electrocu- tion. Check with a qualified electrician for your local  requirements if you are in doubt as to whether the unit  is properly grounded.  This generator is equipped with a grounding terminal for added protection. Using the ground path from the generator to an external ground source as instructed in the section labeled “Grounding Instructions” in the Preparation section of this manual can be  necessary. Please consult a qualified electrician for local regulations. The generator is a potential source of electrical shock if not kept dry. Keep the generator dry and do not use in rain or wet conditions. To protect from moisture, operate it on a dry surface under an open, canopy-like structure. Dry your hands if wet before touching the generator. Plug appliances directly into the generator. Or, use a heavy duty, outdoor-rated extension cord that is rated (in watts or amps) at least equal to the sum of the connected appliance loads. Check that the entire cord is free of cuts or tears and that the plug has all three  prongs,especially a grounding pin. NEVER try to power the house wiring by plugging the generator into a wall outlet, a practice known as “back feeding”. This is an extremely dangerous practice that presents an electrocution risk to utility workers and neighbors served by the same utility transformer. It also bypasses some of the built-in household circuit protection devices. If you must connect the generator to the house wiring to power appliances, have a qualified electrician install the appropriate  equipment in accordance with local electrical codes. ...

  • Page 11: Important Safety Instructions

    safety IMPORTANT SAFETy INSTRUCTIONS WARNING To reduce the risk of injury, read this operator’s manual  completely before using.  When using this product, the following basic  precautions should always be followed. • Do not enclose the generator or cover it. The generator may become      overheated if it is enclosed. If generator has been covered to protect if    from the weather during non use, be sure to remove it and keep it well    away from the area during generator use. • Operate the generator on a level surface. It is not necessary to prepare      a special foundation for the generator. However, the generator will     vibrate on an irregular surface, so choose a level place.   If the generator is tilted or moved during operation, fuel may spill and/or      the generator may tip over, causing a hazardous situation.   Proper lubrication cannot be expected if the generator is operated on a      steep incline or slope. In such a case, piston seizure may occur even if     the oil is above the upper level. • Pay attention to the wiring or extension cords from the generator to the      connected device. If the wire is under the generator or in contact with      vibrating part, it may break and possibly cause a fire, generator burnout,     or electric shock hazard. Replace damaged or worn cords immediately. • Do not operate in rain, in wet or damp conditions, or with wet hands.    The operator may suffer severe electric shock if the generator is wet due      to rain or snow. If wet, wipe and dry it well before starting. Do not pour    water directly over the generator, nor wash it with water. • Be extremely careful that all necessary electrical grounding procedures      are followed during each and every use. Failure to do so can be fatal. • DO NOT smoke while charging a battery. The battery emits flammable    hydrogen gas, which can explode if exposed to electric arcing or open      flame. Keep the area well ventilated and keep open flames / sparks away        when charging a battery. • The engine becomes extremely hot during and for some time after    operation. Keep combustible materials well away from generator area.    Be very careful not to touch any parts of the hot engine especially the ...
  • Page 12 safety • Keep children and all bystanders at a safe distance from work area. • It is absolutely essential that you know the safe and proper use of the     power tool or appliance that you intend to use. All operators must read,    understand and follow the tool / appliance owners manual. Tool and    appliance applications and limitations must be understood. Follow all      directions given on labels and warnings. Keep all instruction manuals    and literature in a safe place for future reference. • Use only “LISTED” extension cords. When a tool or appliance is used      outdoors, use only extension cords marked “For Outdoor Use”.    Extension cords, when not in use should be stored in a dry and well     ventilated area. • Always switch off generator’s AC circuit breaker and disconnect tools    or appliances when not in use, before servicing, adjusting, or installing     accessories and attachments. • Make sure the engine is stopped before starting any maintenance,    servicing or repair. NOTE: Make sure maintenance and repair of the generator are performed  by properly trained personnel only. SAVE THESE INSTRUCTIONS...

  • Page 13: Glossary

    glossary Glossary Following symbols are quoted on the machine or in this manual. Please understand their meaning, which will make your operation easier and  safer. SYMBOL NAME MEANING Volt Voltage Ampere Current Hertz Frequency (1Hz=60 r/min) Watt Power Revolutions per Minute Engine Speed Power Factor Load transfer efficiency Generator output power perfor- Performance Rate mance rate meat ISO8528G1...

  • Page 14: Generator Components

    Read this operator’s manual and safety rules before operating your generator. bc12000er 12000 watt 1)   Fuel Gauge 2)   Chock Valve 3)   Fuel Valve Lever 4)   Air Cleaner 5)   Engine Switch 6)   Handrail Pipe 7)   Starter Grip 8)   Foot 9)   Oil Drain Bolt 10) Wheel 11) Oil Filler Cap 12) Ground Terminal 13) Battery 14) Timer 15) DC Output 16) AC Output 17) AC Circuit Breaker 18) Panel Seat 19) Voltmeter 20) Fuel Tank Cap 21) Fuel Tank 22) Cover, Generator End 23) Muffler 24) Cylinder Head 25) Carburetor...

  • Page 15: Spare Parts List

    generator components SPARE PARTS lIST Fuel Tank It is used to hold fuel, gasoline is allowed only. Screw the fuel injection port in use and do not  Fuel Tank Cap open it in equipment operation. Fuel Gauge It is to indicate fuel level in the fuel tank. AC output socket provides the power supply.  Please refer to models parameter table for its  rated power. Load of each socket cannot exceed  its rated current and total power of electric device  AC Output cannot surpass rated power of the generator. Do  not start up several electric devices simultaneously,  but switch on another one after stable operation of  one electric device. AC Circuit  It will break to protect the electric device when  Breaker current is too heavy. It is to indicate power supply status. The indicate  Output Indicator will brighten up when the equipment operation. The output DC is 12V with maximum of 8.3A. It  is only used for automotive battery charging with  DC Output rated 12V. Pay attention to connecting the positive  and negative electrode correctly. It is to start up (applicable to electrical starting  only) and switch off the engine. Turn to the off  Engine Switch state in non use. Wheel (optional) It is for moving the generator in a short time. It is for starting up the generator. In case of non  Battery use for three months, charge it.
  • Page 16 generator components It is to make the generator realize safe grounding.  Grounding Ter- As to the grounding method, refer to the Page 19.  minal Make sure unobstructed grounding before use. After lifted up, the pipe, with self-locking structure,  Handrail Pipe can be used to move the generator. It is to start up the engine. For the method, refer to  Starter Grip Page 22. It is to filter air and remove impurities in the air  Air Cleaner entering cylinder. As to the maintenance method,  refer to Page 30. It is to control fuel’s entering into the engine via the  Fuel Switch fuel tank. During non use of the generator, leave  the switch off. It is to control air flow into the cylinder when  Chock Valve starting up the engine. As to the operating method,  refer to Page 22. It is to eliminate noise during equipment operation,  and discharge high temperature exhaust of  Muffler engine’s combustion. Do not touch it to avoid  burning. The Timer records the running time of the  generator. Press conversion key to convert  between cumulative timing and single timing. The  Timer Timer will prompt to change the engine oil at 20  hours for the first time and then prompt every 100  hours; and will prompt to clean the air cleaner  every 50 hours.

  • Page 17: Sockets

    generator components SOCkETS Sockets can be following patterns according to relevant regulations in  various areas: WARNING When the rated current from one socket output is more than the  socket’s nominal rated current, you should simultaneously use two or  more sockets for power output.

  • Page 18: Features

    Features MODEl bC12000ER AC OUTPUT Frequency 60Hz Voltage 120/240V Rated Power (W) 9500 Max. Power (W) 12000 ENGINE Single cylinder, forced air cooling,  Specification 4 strokes 3600r/min Fuel Gasoline Engine Oil Capacity 0.42 Gal /1.6L Spark Plug Type F7TC/F7RTC (N9YC/RN9YC) Spark Plug Clearance 0.7 mm Valve Clearance (inlet/outlet) 0.05/0.07 mm Igniting Mode T.C.I. Starting Mode Recoild start/Electric start Displacement 622cc WEIGHT (only for reference) Net Weight 315lb/143kg OVERAll DIMENSIONS (excluding packing box) L x W x H (mm)

  • Page 19: Operation

    operation Operation UNIT GROUNDING Shift the machine outdoors, use wire of no less than 2.5mm to make the  machine and grounding terminal connected to the ground. One end of  the wire is pressed below the butterfly nut of the unit, screwed up tightly,  and the other end is connected with the metal rod shape article (such as  the iron nail and the opener), and inserted into soil. Starting the Generator FIllING OIl Remove the oil filler cap fill oil of proper model As to dosage refer to  Page 18 Use the funnel for filling in case of careless spilling clean the  ground to avoid slipping.

  • Page 20: Filling Fuel

    operation OIl SPECIFICATION TAblE FIllING FUEl Open the fuel tank cap and fill gasoline, the fuel leveler’s position will  display gasoline mass in the fuel tank and take care the maximum fuel  position shall not exceed the inner strainer of the tank when filling. WARNING When the rated current from one socket output is more than the  socket’s nominal rated current, you should simultaneously use two or  more sockets for power output.

  • Page 21: Turn On The Fuel Valve Lever

    operation TURN ON THE FUEl VAlVE lEVER Turn the fuel valve lever to ON and let the fuel flow into the carburetor. ClOSE THE CHOkE VAlVE When the unit is in cold state move the choke valve to the full closed  position and half closed position in thermal state If the generator unit is  not started for two times in succession move the choke valve to the open  position and then to operate the switch or hand pull starter. START THE GENERATOR Press it to START if its electrical start state then generator can be started  In order to extend the service life of the storage battery,do not press on  the switch for more than 3 seconds and the interval between two press- ings should be longer than 10 seconds. ...

  • Page 22: Start The Generator Recoil Start

    operation START THE GENERATOR RECOIl START Start via the pull wire: Pull the wire gently to connect the disc to the  starting bowl inside the unit. Pull the wire out in an instant action and  the generator unit will be started after doing this twice. If it is not started  please conduct the above operation with the choke valve. WARNING It may be causing the dangers of injury by the sudden change of rota- tion direction of the engine during operating the recoil starter. OPEN THE CHOkE VAlVE After starting, let the unit run without load for 5 seconds and then turn on  the choke valve switch.

  • Page 23: Connect To Load

    operation CONNECT TO lOAD Access electric equipment and turn the circuit breaker to ON Please note  that when several loads are used at the same time do not access the  next one unless the former one is running normally The total power of the  loads should not exceed the rated power of the unit. Stopping the Generator DISCONNECT lOAD Disconnect the electric equipment from the control panel of the  generator. TURN OFF THE ENGINE SWITCH After 30 seconds of no load running turn off the engine switch and the  generator unit will be shut down immediately.

  • Page 24: Close The Fuel Valve Lever

    operation ClOSE THE FUEl VAlVE lEVER Turn off the fuel valve lever after the shutdown of the unit. Storage DRAIN THE FUEl Remove the oil draining bolt of the carburetor and drain the fuel from the  fuel tank and carburetor Then tighten the oil draining bolt again if the fuel  is not drained the fuel will evaporate and flow into the air and the residues  may block the carburetor. PROTECTIVE TREATMENT The unit should be stored in a clean and dry place and should be  protected from rain and high temperature. Shield the unit with paper box  or plastic bag to prevent dust from entering the unit.

  • Page 25: Transporting

    operation Transporting To prevent fuel spillage when transporting or during temporary storage,  the generator should be secured upright in its normal operating  position,with the engine switch OFF. The fuel valve lever should be turned  OFF. WARNING · Do not overfill the tank. · Do not operate the generator while it is on a vehicle. Take the  generator off the vehicle and use it in a well ventilated place. · Avoid a place exposed to direct sunlight when putting the generator  on a vehicle .If the generator is left in an enclosed vehicle for many  hours,high temperature inside the vehicle could cause fuel to vaporize  resulting in a possible explosion. · Do not drive on a rough road for an extended period with the  generator on board. If you must transport the generator on a rough  road,drain the fuel from the generator beforehand. NOTICE · To transport the generator, hold the holding part (shaded areas in  Fig.1). · Take care not to drop or strike the generator when transporting. · Do not place heavy objects on the generator. · When transporting the generator by loading it on to a vehicle, secure  to the generator frame as shown (see fig.2).

  • Page 26: Accessories

    accessories Accessories ACCESSORy INSTAllATION You can install the wheel assemblies for the convenience of moving the  unit You may need to prepare the following equipment before the installation. According to the different model configurations there are several kinds of  wheels Please install the handrail vibration reduction bracket and wheel  on the base plate and tighten the bolt as shown in the following picture. TWO-WHEEl SHORT AxlE...

  • Page 27: Maintenance

    maintenance Maintenance MAINTENANCE CHART Every  Every  Every  Every  20hrs  50hrs  100hrs  300hrs  Regular Maintenance Sched- Per  or 1  or 3  or 6  or each  Month Months Months Year Engine Oil Inspect the oil  level Replace Air Cleaner Inspect Clean X (1) Fuel Switch  Clean Sediment cup Spark Plug Clean Replace Valve Clearance Readjust X (2) Cylinder Head Wash Every 300 Hours (2) Fuel Tank and ...

  • Page 28: Replace Engine Oil

    maintenance REPlACE ENGINE OIl Remove the oil draining bolt and drain the long time stored oil Tighten the  oil draining bolt and twist off the oil dipstick Fill in appropriate amount of  oil via the oil dipstick and keep the oil level between MIN and MAX. ClEAN AIR ClEANER 1) Remove the clip of the air cleaner cover and open it. 2) Inspect the air cleaner element and ensure that it is sound and clean. 3) If the foam cleaner element is dirty, spray some household cleaning  agent onto the cleaner element. Scrub it for several minutes and rinse  it with warm water. If the cleaner element is damaged, please replace  a new one.

  • Page 29: Clean The Fuel Valve Lever Sediment Cup

    maintenance ClEAN THE FUEl VAlVE lEVER SEDIMENT CUP ClEAN THE SPARk PlUG 1) Remove the spark plug cap. 2) Clean the spark plug base. 3) Remove the spark plug with the spark plug socket spanner. 4) Inspect the spark plug insulator visually for damage. If it is damaged  replace a new one. 5) Measure the spark plug gap with a gap gauge. Twist the side  electrode to adjust the gap. The gap should be kept between 0 70  and 0 80mm. 6) Inspect if the washer of the spark plug is in good condition. 7) Reinstall the spark plug and tighten it with the spark plug socket  spanner. Press down the washer of the spark plug and place the spark  plug cap. Recommended spark plug models: F7RTC and F7TC...

  • Page 30: Valve Clearance

    maintenance VAlVE ClEARANCE Remove the cylinder head cover and measure the valve clearance with  the feeler gauge. The clearances are 0.03~0.05mm for the inlet valve and  0.05~0.07mm for the outlet valve. (should be conducted by a professional person)

  • Page 31: Troubleshooting

    troubleshooting Troubleshooting TROUblESHOOTING CHART PROBLEM CAUSE CORRECTION No fuel Fill the oil tank with  gasoline The oil switch is not  Turn the oil switch to ON turned on The oil switch is blocked Clean the oil cup (refer to  page 27) The generator can not  start No engine oil or the  Add oil engine oil level is low The shutdown switch is  Turn the switch to the “on”  turned off position The spark plug fails Clean or replace the spark  plug (refer to page 27) The circuit breaker is not  Turn the circuit breaker to  connected the “on” position No power output The plug is poorly  Replace a socket contacted The choke position is  Move the choke to the  Vibration while operation incorrect “on” position The temperature of the ...

  • Page 32: Troubleshooting Analysis

    troubleshooting TROUblESHOOTING ANAlySIS · The environmental requirements of the generator: · Suitable temperature: -15°-40°. · Suitable humidity: lower than 95%. · Suitable altitude under 1,000 meters it should be used with lower power  in districts higher than 1,000 meters. . · The generator set can only be loaded to the rated power under the  specified environment conditions If the environment conditions are  inconsistent with the above standards or if the cooling conditions of  the engine and generator set are defective for example when running in  limited areas it is necessary to reduce the power It is also necessary to  reduce the power when the temperature altitude and relative humidity  exceed the standards. · If there is no problem with the conditions above please turn to the  nearby dealer or after sales service center for consulting.

  • Page 33: Diagrams

    diagrams Electrical Schematic Diagram ElECTRICAl SCHEMATIC DIAGRAM 1 50Hz 230V...
  • Page 34 diagrams ElECTRICAl SCHEMATIC DIAGRAM 2 60Hz 120V/240V...
  • Page 36 If you need assistance with the assembly or operation of your Generator please call 1-855-850-6668...
