organization 3DX 450 FSE V3 Instruction Manual

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

3DX 450 FSE V3

C O P Y R I G H T ©

Instruction Manual

Date: 09/30/2006

Version 1

CONTENTS

• 2...Safety Note's

• 3...Hardware Identification

• 4...Assembly Instructions

• 5...Maintenance

• 6 - 8...Main Rotor Assembly

Author: Per Backman

• 9 - 12...Main Frame Assembly

• 13 - 15...Tail Rotor Assembly

• 17...Linkage Setup

• 18 - 20...Radio Setup

• 21...Spare Parts

• 22...Specifications

Table of Contents

Need help?

Do you have a question about the 3DX 450 FSE V3 and is the answer not in the manual?

Questions and answers

Summary of Contents for organization 3DX 450 FSE V3

Page 1: Instruction Manual
3DX 450 FSE V3 C O P Y R I G H T © Instruction Manual Author: Per Backman Date: 09/30/2006 Version 1 CONTENTS • 9 - 12...Main Frame Assembly • 2…Safety Note’s • 13 - 15...Tail Rotor Assembly • 3...Hardware Identification •...
Page 2 Note’s Before Starting Page 2 WELCOME TO 3DX450 R/C MODEL PRODUCTS Thank you for buying this Product. The 3DX 450 FSE Helicopter is designed as easy to use, full featured Helicopter R/C model capable of all forms of rotary flight. Please read the manual carefully before assembling the model, and follow all precautions and recommendations located within the manual.
Page 3: Hardware Identification
Hardware Identification Page 3 WELCOME TO 3DX450 R/C MODEL PRODUCTS M2x7mm Philips Head Screw M2x7mm Self tapping Screw M3x3mm Set screw A = Diameter B = Length M2X4mm Socket Head Screw M2x6mm Socket Head Screw M2x8mm Socket Head Screw M2x16mm Socket Head Screw M2x18mm Socket Head Screw M3x22mm Socket Head Screw M2 Hex Nut...
Page 4: Assembly Instructions
Assembly instruction Page 4 Assembling the Head & Tail If the head and tail come 100 % pre-assembled. (Option) I do recommend you go over each screw to make sure they are secured with Thread Lock , if needed unassembled the part that is lose and use blue Thread Lock.
Page 5: Maintenance
Regular Maintenance instruction Page 5 Regular maintenance is required to keep the 3DX450 FSE helicopter in optimal and safe flying condition, The model requires precise configuration of the components and settings to be kept by the owner. Maintain regular maintenance on the model to avoid accidents or loss, and optimum performance. Main Rotor Check List 1.
Page 6 Main Head Installation Page 6 MAIN ROTOR INSTALLATION Each section of the manual has its associated parts bag. Each bag is labeled accordingly. Make sure to only open the bags as indicated in the instructed manual and place them into the provided parts cases. Do not open all the bags at once, or out of or- der to avoid confusion and difficulty assembling the model.
Page 7 Main Head Installation Page 7 Parts for Rotor head Parts No. Description Spec Parts No. Description Spec UGT08 FlangeBearing 2x5x2.mm UGT02B Housing Hat UGT08 SF Mixer Lever arm UGT01 Feathering Shaft M3x42mm UGT08 Linkage Ball 4.75MM UGT02 O-ring 3x6.5x4mm UGT08 Cross Screw M2x7mm UGT01...
Page 8 Main Head Installation Page 8 Parts for Rotor head Parts No. Description Spec Parts No. Description Spec UGT09 Linkage Ball 4.75mm UGT02 Washout Base UGT09 Cross Screw M2x7mm 38 UGT02 Washout Base bushing UGT09 Flybar Control Lever UGT05 CCPM Swashplate UGT09 Bearing 2x5x2.5...
Page 9 Main Frame Installation Page 9 Parts for Frame installation Parts No. Description Spec Parts No. Description Spec UGTFF2 Anti Rotation Brace UGTFF1 Tail Boom Holder UGTFF1 UGTFF1 SocketHeadScrew M2x6mm UGTFF1 Main shaft mount/bearing 5X10X5 UGTFF1 eCCPM Servo Holder UGTGS Tail Drive Gear Assembly UGTCM Canopy Mount UGTFF1...
Page 10 Main Frame Installation Page 10 Parts for Frame installation Parts No. Description Spec Parts No. Description Spec UGTFF1 UGTFF1 SocketHeadScrew M2x6mm UGTFF1 ScrewLong/LockTailBoom M2x30mm UGTCM Canopy Mount UGTFF2 Inner Frame UGTFF1 Washer Note: The washers number 58 is 35Pcs, For Frame lock 2x6mm Socket Head Screw.
Page 11 Main Frame Installation Page 11 Parts for Frame installation Parts No. Description Spec Parts No. Description Spec UGTFF1 UGTFF2 Battery Tray UGTFF1 SocketHeadScrew M2x8mm UGTFF2 Side Frame Outer UGTFF1 SocketHeadScrew M2X4mm UGTFF1 Long Spacer UGTFF1 Washer UGTFF1 End Caps UGTFF1 Spacer Screw M2x18mm UGTFF1...
Page 12 Main frame & Main Gear Installation Page 12 Parts for Frame installation Parts No. Description Spec Parts No. Description Spec UGTGS Shaft Ring (short) UGTHS Collar UGTGS Main Drive Gear 150T UGTHS Lock screw 3x3mm UGTGS One Way Bearing UGT01 Socket Screw M3x18mm UGTGS...
Page 13 Tail Rotor & Boom Installation Page 13 Parts for Tail Rotor head Parts No. Description Spec Parts No. Description Spec UGT13 L-Arm Bell Crank UGT04 Tail Shaft 48mm long UGT13 Bearing 2X5X2.5mm UGT04 Tail Rotor hub UGT13 Flange Bearing 2X5X2.3mm UGT04 Set screw M3x3...
Page 14 Tail Rotor & Boom Installation Page 14 Parts for Tail Rotor head Parts No. Description Spec Parts No. Description Spec UGT06 Spacer 2X2.5X0.5mm 116 UGTTS Tail Blade Washer Option UGT06 SocketHeadScrew M2x18 UGT04 UGTTS Tail Pulley UGT04 SocketHeadScrew 2X12mm UGTTS SocketHeadScrew M2x6 UGT06...
Page 15 Tail Rotor & Boom Installation Page 15 Parts for Tail Rotor head Parts No. Description Spec Parts No. Description Spec UGTSP Support Rod Grips UGT10 Socket Head Screw M2x8 UGTSP Tail boom support rod UGTVH Tail Fin UGT10 ServoScrew M2x8 UGTVH Screw M2x7...
Page 16 Finished Installation Page 16 Parts for Frame installation Parts No. Description Spec Parts No. Description Spec Self tap Screw M2x8 Canopy Canopy Glass Canopy Rubber Nut...
Page 17: Linkage Setup
Linkage setup Page 17 Servo arm ball assembly Aileron, elevator and pitch servo - 12-14 mm from center of servo to ball. Tail servo - 6-8mm from center of servo to ball. Note: The ball links have a front and a back. Install links with the larger opening toward the ball.
Page 18: Radio Setup
Radio setup Page 18 Throttle (CH1) Aileron (CH1) Elevator (CH2) Aileron (CH2) Throttle (CH3) Elevator (CH3) Rudder (CH4) Rudder (CH4) Pitch (CH6) Pitch (AUX1) 6-channel receiver is required for the recommended setup of the 3DX 6-channel receiver is required for the recommended setup of the 3DX helicopter.
Page 19 Radio setup Page 19...
Page 20 Radio setup Page 20...
Page 21: Spare Parts
Spare Parts Page 21...
Page 22: Specifications
The contents of this document are subject to change without prior notice Every effort has been made to ensure that this manual is complete and correct. Should any mistake be discover by anyone please have the curtsy to inform us. Organization Specifications & Equipment: Length:...
