ValentFX Logi-Pi User Manual

Logi-Pi User Guide
From ValentFx Wiki
LOGi Pi - Bringing FPGA Technology to the Raspberry Pi
Contents

1 Overview

1.1 Features
1.2 Peripherals
2 Electrical
3 Interfacing
3.1 Top Level Block Diagram
3.2 RA2.1 Raspberry Pi Connector Interface
3.3 PMOD Expansion Port
3.4 Arduino Expansion Port
3.5 LVDS Expansion Port
3.6 LVDS signal usage
3.7 Push Button Usage
3.8 DIP Switch Usage
3.9 LED Usage
3.10 JTAG Interface
4 Programming the FPGA from the Raspberry Pi
5 Raspberry Pi SPI to FPGA Interface
5.1 Direct SPI Communication to FPGA
5.2 SPI to Wishbone Interface Bandwidth
6 Useful Links
6.1 LOGi - Repository - Projects, Libraries, Drivers
6.2 LOGi-Pi Schematics
6.3 LOGI-Pi User Guide -LOGi-Pi documentation
6.4 LOGi Projects wiki - LOGI and Users projects will be documented here
Overview
The LOGi-Pi is the first FPGA development platform that has been optimized for use with the Raspberry Pi. The
LOGi-Pi adds FPGA flexibility and capability that allows the Raspberry Pi to be easily morphed into endless digital
applications. The FPGA/CPU combination the LOGi-Pi creates an incredibly powerful and versatile digital canvas
for users to create their imaginative digital designs.
Features
