SF-3040 Quick Start Guide
Follow this Quick Start Guide to enable the robust
functionality of the SF-3040.
By opening, assembling, and using this product, you
agree to the terms of the License Agreement contained
in the SF-3040 GNSS Product User Guide.

Consult your dealer to determine if the SF-3040
is fully configured. If it is, the SF-3040 is ready
to use. Refer only to these sections: Connect
Equipment and Factory Default User Profile.

If the SF-3040 is not dealer-configured, the
receiver is not operational until the steps in this
guide are performed.
The supplied SF-3040 Product Configuration USB Flash
Drive (PN 82-043000-0001) includes all the files needed to
set up the ordered configuration of the SF-3040. It also
includes guides with complete product information:

SF-3040 GNSS Product User Guide

StarUtil 3000 User Guide

Sapphire Technical Reference Manual
 NavCom Customer Support:
Telephone: +1 (310) 381-2000
Web:
http://www.navcomtech.com/Contact/ContactSupport.cfm
POWER USB – COM1
96-310035-3001, Rev. B
Connect Equipment
1. Use one of the two supplied data cables for
communications:
•
USB Device cable (PN 96-212238-01): Connect the 7-pin
LEMO connector end to the USB-COM1 port on the bottom of
the SF-3040. Plug the USB end into the PC.
Or
•
COM 2 serial cable (optional) (PN 96-212169-01): Connect the
6-pin LEMO connector end to COM2 port at the bottom of the
SF-3040. Connect the DB9S end to the PC.

An optional COM1 serial cable
(PN 96-212170-01) is also supported.

Bluetooth connectivity is also available. Refer to
the StarUtil 3000 User Guide for detailed
instructions on connecting a Bluetooth device.

An optional UHF radio modem is also available.
Refer to the SF-3040 GNSS Receiver Product
User Guide for complete instructions.
2. Locate the antenna in an area with a 360° clear view of
the sky.
3. Fully charge the battery packs in the supplied battery
charger.
4. Install the battery packs in the side battery slots.

Refer to the SF-3040 GNSS Receiver Product
User Guide for complete instructions on charging
and installing the battery packs.

Three optional power cables are also available.
5. Press the On/Off switch
to turn on the SF-3040. All front panel LEDs illuminate
for 3 to 5 seconds during power-up. The Indicator Panel
status LEDs change from
COM2
Save Folder/Files to PC

6. Plug the SF-3040 Product Configuration USB Flash
7. Browse to the USB Flash Drive.
8. Save the Software Options File,
Establish Communications
9. Browse to Navcom\Utilities\StarUtil-3000 on the PC.
10. Ensure that these files are in the StarUtil-3000 folder:

11. Double-click "Starutil-3k_v1_0_x.exe" to open the
on the front Indicator Panel
red to green.
12. Click the Connections button to establish communications
The SF-3040 Product Configuration USB Flash
Drive (PN 82-043000-0001) includes the
following:
•
Root Directory: Software Options File and StarFire License
(if purchased)
•
NavCom Folder: Includes these sub-folders: Firmware,
Marketing Materials, User Guides, User Profiles, Utilities
(The contents of the NavCom folder are subject to change.)
Drive into the PC.
StarFire License (if purchased),
and NavCom folder to the PC.
Create two folders in the NavCom
folder for the Options File and
StarFire License.
"Starutil-3k_v1_0_x.exe", "navcomx1c45x3040.inf" (USB
driver), and 96-312007-3001.pdf.
The USB driver must be in the same folder as
StarUtil-3000 for the USB port to auto-recognize
the SF-3040.
program.
Connections button
between the PC and the SF-3040. The Port Configuration
window opens.
