Shinyei A01-16400 Instruction Manual

Shock&vibration data logger accstick
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Shock&Vibration data logger AccStick
SHINYEI TESTING MACHINERY CO.,LTD
(HEAD OFFICE)
(KOBE OFFICE)
(NAGOYA OFFICE)
URL: http://www.shinyei-tm.com
General warning
・ No part of this instruction manual can be transferred nor reproduced without permission.
・ Alterations to the contents of this instruction manual are reserved without notice for future
improvement.
・ This instruction manual has been given the twice over to be doubly assured. However, we cannot be
responsible for any mistakes which might have occurred within its contents. Please inform us if you
have found obscurities, or wrong descriptions, skipped descriptions, or the like.
Instruction Manual
Model：A01-16400
B47-11, Katoridai, Tsukuba, Ibaraki, Japan,300-2657
Tel: +81-29-848-3571
SHINYEI BLDG.5F,77-1,Kyomachi,Chuo-ku,Kobe,Hyogo,
650-0034,JAPAN
Tel: +81-78-392-6963
Nishiki emuai BLDG. 6F, 1-7-39, Nishiki,Nakaku, Nagoya,
Aichi, 460-0003, Japan
Tel: +81-52-218-5472
FAX: +81-29-848-3572
FAX:+81-78-332-1619
Fax: +81-52-218-6110
AccStick_004

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the A01-16400 and is the answer not in the manual?

Questions and answers

Summary of Contents for Shinyei A01-16400

  • Page 1 AccStick_004 Instruction Manual Shock&Vibration data logger AccStick Model：A01-16400 SHINYEI TESTING MACHINERY CO.,LTD (HEAD OFFICE) B47-11, Katoridai, Tsukuba, Ibaraki, Japan,300-2657 Tel: +81-29-848-3571 FAX: +81-29-848-3572 (KOBE OFFICE) SHINYEI BLDG.5F,77-1,Kyomachi,Chuo-ku,Kobe,Hyogo, 650-0034,JAPAN Tel: +81-78-392-6963 FAX:+81-78-332-1619 (NAGOYA OFFICE) Nishiki emuai BLDG. 6F, 1-7-39, Nishiki,Nakaku, Nagoya,...

  • Page 3: Table Of Contents

    Contents 1. Precautions for operating the AccStick ·········································· - 1 - 2. About AccStick ································································ - 2 - 3. Devices and Tools Required for Measurement and Analysis and Precautions during Handling and Operation ························································ - 3 - 3-1 Devices and tools required ··················································· - 3 - 3-1-1 Recorder ·······························································...

  • Page 5: Precautions For Operating The Accstick

    1. Precautions for operating the AccStick Precautions for operating the AccStick Please keep this notice Before using the AccStick, please read this notice and the AccStick’s instruction manual thoroughly. We will not hold responsibility of any problems in relation to this notice.

  • Page 6: About Accstick

    2. About AccStick Shock & vibration data logger, AccStick, consist of the Accstick unit and the customized software. 2 types of 3axis accelerometer, microcontroller, operational switch, and rechargeable battery, is packed into one unit with an outer aluminum casing. Continuous measurements up to 3 days are made possible.

  • Page 7: Devices And Tools Required For Measurement And Analysis And Precautions During Handling And Operation

    3-1 Devices and tools required 3-1-1 Recorder AccStick 3-1-2 Software package Specific Software ： the software can be downloaded on the website. URL： http://www.shinyei-tm.com/product_AccStick.html ※ Personal computer  ： Core 2 Duo processor 2GHz or equivalent.  Main memory ：1024MB minimum ...

  • Page 8: Data Capturing Software

     A place where static electricity, magnetism, and noises frequencies are produced k) Be careful when an accelerated characteristic change or thick concentrations may cause damage when exposed to.  Acetone, ammonia, ethanol, hydrogen dioxide, hydrogen sulfide, chlorine gas, sulfur oxides, nitrogen oxides, etc.

  • Page 9: Operation

    4. Operation Battery AccStick has a rechargeable battery of lithium polymer that can be charged via a specific harness and micro USB cable connected to a PC. An Orange LED light appears when charging, and disappears when full charged (see Fig.1). The time it takes to full charge is around 60 min from empty.

  • Page 10: Body

    Fig.2 Direction of Harness connection Body AccStick has a LED, main power switch and connector to connect to the PC. a) Main power switch Turn on the power when you start measuring. Do not attempt to prematurely terminate the measurements during the measuring process by turning the power off.

  • Page 11: Data Capacity

    <LED operation> ・Red/ blue LED flashes when connecting to PC ・Orange LED appears when the battery is charging Data capacity AccStick has a 4MB flash memory can store acceleration data up to 500,000 points. Measuring will be continuous until the selected frame length is achieved when trigger mode is configured as “immediately”...

  • Page 12: Steps For Installation Of Accstick Software

    5. Steps for installation of AccStick software Download the software from the website below. URL：http://www.shinyei-tm.com/product_AccStick.html Execute setup.exe in the folder. Click “install” if a warning screen like the right screen appears. Your installation is complete when the screen below appears.

  • Page 13: Measuring Protocol

    6. Measuring protocol Configuring measuring conditions Connect AccStick to PC with the cable module like the picture on the right. Charge the battery if necessary. Click the “USB com” on the PC software after making sure the Baud (bps) is configured as 230400.

  • Page 14: From Measuring To Download

    From Measuring to Download ＜Starting Conditions＞ ①Select the start date when you select “Timer” or “Timer & Acc”. Then, click “START”. Measuring will start automatically at the selected time. ②When you select “Acc.” Or “immediately”, Click “START” directly. Measuring will be started at immediately after the click. Turn on the Power of the AccStick.

  • Page 15: How To Use The Application Software

    7. How to use the application software Screen This software consists of a waveform screen and a configuration commands. 7-1-1 Icon There are 8 kinds of icon on the screen. Communicate with the AccStick. Letters on the icon change to blue if communication successful.
  • Page 16 7-1-2 Viewing captured data Acceleration data captured by the AccStick can be viewed on the screen of the specific software. Click “download” to enable measured data to show on the PC. The yellow bar such as below picture will be appear with each frame you select if you selected “Acc”or ”Timer&Acc” trigger modes.
  • Page 17 7-1-4 Measuring conditions ＜Basic settings＞ Trig. Mode： Trigger mode that captures the shock & Vibration is selectable as below. Start to measure immediately after clicking “START”. Immediately Start to measure when the selected time is approaching after clicking Timer “START”. Start to measure when the acceleration is over the selected threshold Acc.
  • Page 18 ＜Starting Operation＞ Start Date：Configuration item for when Timer or Timer&Acc trigger mode is selected. Measuring will started at the time you selected. You do not need to configure this in Immediately or Acc. mode. START ： Measuring will begin after clicking, at the time as appeared on the PC. When “Timer” or “Timer&Acc.”...

  • Page 19: Troubleshooting

    8. Troubleshooting Trouble Reason Response Baud (bps) is configured at a different Baud(bps) should be configured value. at 230400. ・Confirm the cable connection USB cable or the specified harness is ・Remove the cable, and insert to not connected successfully with the AccStick can’t be AccStick.

  • Page 20: Accstick Specifications

    9. AccStick Specifications Specification sheet 9-1-1 Hardware Model A01-16400 3axis MEMS type ±16G (Vibration sensor) Accelerometer 3axis MEMS type ±400G (Shock sensor) Memory capacity Flash memory 4MB (Up to 500000 data recording) Power supply Lithium polymer rechargeable battery（85mA/h） Around 3 days ※When full battery, Acc.

  • Page 21: Dimensions

    Dimensions ２－φ２．２ （対角方向） (Diagonal direction) Ｚ ▲ Ｘ Ｙ ＡｃｃＳｔｉｃｋ ▼ ２５．４ １０．５ ３２．４ 10. Product Warranty 3D acceleration data logger AccStick is guaranteed as specified below. ① For problems under normal working conditions, we will repair the unit without any charge for one year from the date of delivery.
