Product Manual
S01-NN
www.shapertools.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Origin S01-NN and is the answer not in the manual?

Questions and answers

Summary of Contents for Shaper Origin S01-NN

  • Page 1 Product Manual S01-NN www.shapertools.com...
  • Page 3 Welcome Congratulations on your purchase of Shaper Origin! We know you’re excited to start cutting and carving, but please make sure to read all of the operating instructions, warnings, and safety notes detailed in this booklet before operating Origin. To get started with Origin navigate to the link below for a complete walk-through and some demos to get you acquainted.
  • Page 4 Shaper Hub. hub.shapertools.com When you’re ready to make your first project, check out Shaper Hub for an array of ready-to-cut projects with detailed instructions, material lists, and design files.
  • Page 5 Table of Contents What’s Included Overview Basics 8-10 Using ShaperTape™ 11-13 Safety & Care 14-24 Compliance shapertools.com...
  • Page 6 What’s Included Shaper Origin dust collection hose ShaperTape™...
  • Page 7 What’s Included 4mm T handle 19mm wrench hex wrench 1/4 in upcut 1/8 in upcut engraving router bit router bit finger guard shapertools.com...
  • Page 8 Overview spindle switch touchscreen spindle mount spindle handle dust port Touchscreen: Use Origin’s 5in multi-touch display to control Origin’s many features. SM1 Spindle: Origin is equipped with a powerful 720-Watt motor. It features variable speed control and on-board electronics to deliver soft start, thermal and overload protection, and constant speed under load.
  • Page 9 Overview speed control back handle z-axis camera collet lock usb port Speed Control: The SM1 Spindle has adjustable speed from 10,000 to 26,000 RPM, with the lowest speed mapped to 1 on the dial, and the highest speed mapped to 6. Use this dial to adjust the spindle rotation speed.
  • Page 10 Basics Removing the Transport Lock Remove the transport lock before operating Origin, and retain for future use. Reinstall the transport lock to keep the spindle stationary during transit. Removing and Installing the SM1 Spindle To enable unobstructed access to change the router bit, the SM1 Spindle must be removed from Origin.
  • Page 11 Basics To reinstall the spindle, slide it into the spindle mount with the ON/OFF switch facing towards you. A groove on the back of the spindle will only allow it to be inserted in the correct orientation, with the cable exiting on the left side. Gently re- insert the spindle as to not deform the alignment pin.
  • Page 12 Basics Safety First. When Operating Origin always use eye and ear protection. Always keep the finger guard installed when the spindle is plugged in. Keep fin- gers and body parts away from collet and router bit when it is installed to Origin. When setting up your workpiece use clamps, adhesives or other practical ways to secure and support the workpiece to a stable table.
  • Page 13 Using ShaperTape Using ShaperTape™ Origin uses ShaperTape to digitally augment your workpiece. When you’re ready to cut with Origin, lay down ShaperTape on the workpiece. For best results, place strips of ShaperTape every three inches or closer. Strips need not be parallel. All tape must be coplanar with the surface you are cutting to ensure the best tracking accuracy.
  • Page 14 Using ShaperTape Origin will operate correctly if there is ShaperTape placed in the cutting area, as well as the area in the field of view of its camera. Origin will also operate correctly if ShaperTape is only placed in the field of view of its camera.
  • Page 15 Using ShaperTape Origin will operate incorrectly there is not enough ShaperTape within the field of view of it’s camera. 3A86F7 Origin will operate incorrectly If there is only ShaperTape in the cutting area. ShaperTape must be within the field of view of Origin’s camera for it to operate correctly.

  • Page 16: General Power Tool Safety Warnings

    Safety & Care General Power Tool Safety Warnings Warning! Read all safety warnings and instructions. Failure to follow the warn- ings and instructions in this booklet may result in electric shock, fire, and/or serious injury. Save all warnings and instructions for future ref- erence.

  • Page 17: Personal Safety

    Safety & Care Do not expose power tools to rain or wet condi- tions. Water entering the power tool will increase the risk of electric shock. Do not abuse the cord. Never use the cord for car- rying, pulling or unplugging the power tool. Keep cord away from heat, oil, sharp edges or moving parts.
  • Page 18 Safety & Care dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate condi- tions will reduce personal injuries. Prevent unintentional starting. Ensure the switch is in the OFF position before connecting to power source, picking up or carrying the tool. Carrying power tools with your finger on the switch or ener- gizing power tools that have the switch on invites accidents.

  • Page 19: Power Tool Use And Care

    Safety & Care Power Tool Use and Care Do not force the power tool. Use the correct pow- er tool for your application. The correct power tool will do the job better and safer at the rate for which it was designed. Do not use the power tool if the switch does not turn the spindle on and off.
  • Page 20 This will ensure that the safety of the power tool is maintained. Origin is covered by a warranty. Call or email Shaper support (support.shapertools.com) if you believe Origin requires servicing beyond what is listed in the “Use and Care” section.

  • Page 21: Router Safety Warnings

    Always check your work area for potential obstacles immediately before routing. Only operate Origin with the SM1 Spindle provid- ed by Shaper. Use with any other router spindle will cause damage and may result in a risk of elec- tric shock.
  • Page 22 Safety & Care Do not forcibly move the Z-Axis carriage up and down. Doing so may cause damage to Origin’s electronics. Do not forcibly move the spindle mount from side to side. Doing so may cause damage to Origin’s electronics. Cut at an appropriate depth per pass.
  • Page 23 Safety & Care Use an appropriate spindle speed setting for your material. Different materials and router bits call for different spindle speeds. Faster is not always better. Visit support.shapertools.com for recom- mendations on spindle speed settings to use with various materials and router bits. Never operate Origin in a situation in which it could come in contact with its own cord.
  • Page 24 Safety & Care Origin is a Class II (double-insulated) product. Or- igin’s power cord grounding pin is not for protec- tive safety purposes, but rather for proper func- tioning of the device. This functional ground is identified by the symbol marked on the product. Save all warnings and instructions for future ref- erence.
  • Page 25 Safety & Care Symbol Name Explanation Safety Alert Indicates a potential personal injury hazard Read Operators To reduce the risk of Manual injury user must read and understand operator’s manual before using this product. Volts Voltage Amperes Electrical Current Hertz Frequency (cycles per second) Minutes Time...
  • Page 26 Safety & Care California Prop 65 WARNING: This product may contain chemicals known to the State of California to cause cancer, birth defects or other reproductive harm. Wash hands after handling. Health Hazard by Dust WARNING: Various dust created by power sand- ing, sawing, grinding, drilling and other construc- tion activities contains chemicals known to the State of California to cause cancer, birth defects...
  • Page 27 Compliance FCC Statement FCC ID: Z64-WL18SBMOD CONTAINS IC: 451I-WL18SBMOD This device complies with part 15 of the FCC Rules. Operation is subject to the following two condi- tions: (1) This device may not cause harmful inter- ference, and (2) this device must accept any inter- ference received, including interference that may cause undesired operation.
  • Page 28 © Shaper Tools, Inc. 274 Shotwell Street San Francisco, CA 94110 U.S.A.
  • Page 29 Thanks! PKG00009B shapertools.com...
  • Page 30 Notes...
  • Page 31 Notes shapertools.com...
