DVD Micro Theater
CONTENTS
Technical specification ..................................................................1-2
Version variation... ........................................................................1-2
Service measurement setup..........................................................1-3
Service aids .................................................................................1-4
Instructions on CD playability ...............................................2-1.. 2-2
Disassembly diagram............ ........................................................3-1
Block diagram ................................................................................4-1
Wiring diagram ..............................................................................4-2
Main board
Circuit diagram ..................................................................5-1..5-2
Layout diagram ..................................................................5-3..5-4
Display board
Circuit diagram .........................................................................6-1
Layout diagram .........................................................................6-2
AMP board (in subwoofer box)
Circuit diagram .........................................................................7-1
Layout diagram .........................................................................7-2
Exploded view diagram .................................................................8-1
Mechanical parts list ......................................................................8-2
Electrical parts list...................................................................9-1..9-3
©
Copyright 2008 Philips Consumer Electronics B.V. Eindhoven, The Netherlands
All rights reserved. No part of this publication may be reproduced, stored in a retrieval
system or transmitted, in any form or by any means, electronic, mechanical, photocopying,
or otherwise without the prior permission of Philips.
Published by LX 0824 Service Audio
Version 1.1
Subject to modification
MCD179
-/12/58
3141 785 32551
