- Page 1 User manual GlobespanVirata model ISL38001U IEEE 802.11g USB WLAN Card User Manual Version 0.1 FCC ID: RGS38001U Page 1 of 10...
-
Page 2: Table Of Contents
User manual Table of Contents 0-INTRODUCTION....................3 1-INSTALLATION PROCEDURE................3 1.1 I ................3 NSTALLING THE CARD 1.2 I ..............3 NSTALLING THE SOFTWARE DRIVERS 1.3 W IRELESS INSTALLATION GUIDE LINES AND UTHORIZATION FOR USE 2-REGULATORY INFORMATION ................ 7 2.1 FCC I ................ -
Page 3: 0-Introduction
GlobespanVirata driver is located (for example floppy drive, cdrom , harddisk) to install. c-after drivers are installed, restart windows d-the GlobespanVirata WLAN icon will appear in system tray on the bottom right of the screen (see yellow arrow in fig. 01) - Page 4 User manual e-double click the GlobespanVirata WLAN icon to open the WLAN settings, the following window will appear (see fig.02) fig, 02: GlobespanVirata WLAN settings window f-click on configuration tab and select which type of network is required (access point or Peer-to-peer mode), see fig.
-
Page 5: H-Select What Encryption Type Is Required, 64 Or 128 Bit Wep (Default Setting Is Disabled) See Fig
User manual g-select what TX rate is required (default setting is fully automatic) see fig. 04. fig, 04: WLAN tx rate setting window h-select what encryption type is required, 64 or 128 bit WEP (default setting is disabled) see fig. 05. fig, 05: WLAN encryption rate setting window FCC ID: RGS38001U Page 5 of 10... -
Page 6: I-Click On The Status Tab To See The Connection Status (Fig
User manual i-click on the status tab to see the connection status (fig.06). fig, 06: WLAN network status j-click on the about tab to see the software drivers versions and MAC address (fig.07). fig, 07: WLAN driver and MAC addres information FCC ID: RGS38001U Page 6 of 10... -
Page 7: Wireless Lan Installation Guide Lines And Authorization For Use
Any changes or modifications made to this device that are not expressly approved by GlobespanVirata may void the user’s authority to operate the equipment. GlobespanVirata is not responsible for any radio or television interference caused by unauthorized modification of this device, or the substitution or attachment of connecting cables and equipment other than specified. -
Page 8: Fcc Radio Frequency Interference Statement
User manual 2.4 FCC Radio Frequency Interference statement This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 9: Europe - Eu Declaration Of Conformity
User manual 2.6 Europe - EU Declaration of Conformity This device complies with the essential requirements and other relevant provisions of the European R&TTE Directive 1999/5/EC. Compliance to essential test suites is met per standards: R&TTE Harmonized Standard Description LVD specification EN 60950,ed. -
Page 10: 3-Technical Specifications
User manual 3-Technical Specifications Radio Technology IEEE 802.11g Turbo (DSSS and OFDM) Operating Frequency 2400-2497MHz ISM band Modulation Schemes DQPSK, DBPSK, CCK, 16 QAM, 64 QAM 11 channels for United States (2412 MHz to 2462 MHz) RF Channel Availability 13 channels for Europe (2412 MHz to 2472 MHz) 13 channels for Japan (2412 MHz to 2472 MHz), channel 14 only available in DSSS mode (11 Mbps max) Data Rate...
