Spectrum M3i.4830 Hardware Manual

M3i.48 series m3i.48-exp series high-speed 16 bit transient recorder, a/d converter board for pci-x, pci and pci express bus
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
M3i.48xx
M3i.48xx-exp
high-speed 16 bit transient recorder,
A/D converter board
for PCI-X, PCI and PCI Express bus
Hardware Manual
Software Driver Manual
English version
November 21, 2016
SPECTRUM SYSTEMENTWICKLUNG MICROELECTRONIC GMBH · AHRENSFELDER WEG 13-17 · 22927 GROSSHANSDORF · GERMANY
PHONE: +49 (0)4102-6956-0 · FAX: +49 (0)4102-6956-66 · E-MAIL: info@spec.de · INTERNET: http://www.spectrum-instrumentation.com
