UltraSensor Security System User Manual
Product Overview.......................................................................................................................................................... 2
Server-24 ....................................................................................................................................................................... 4
Server-8 ......................................................................................................................................................................... 5
USB connection ................................................................................................................................................... 6
Ethernet connection ............................................................................................................................................. 6
Installation Guide .......................................................................................................................................................... 7
Ethernet Cable Installation................................................................................................................................... 7
CMD Cable Assembly ....................................................................................................................................... 11
Wire Diagram .................................................................................................................................................... 12
Configuration Manager Software ................................................................................................................................ 14
Start-up .............................................................................................................................................................. 14
Create /Edit Users .............................................................................................................................................. 16
Change Password ............................................................................................................................................... 17
Delete User ........................................................................................................................................................ 17
Configure Sensors.............................................................................................................................................. 18
Delete a sensor ................................................................................................................................................... 19
Configure System .............................................................................................................................................. 20
Set Map Scale .................................................................................................................................................... 21
Configure Sensor using Monitor Screen ............................................................................................................ 21
Configure Contacts ............................................................................................................................................ 22
Contact Closure Detail....................................................................................................................................... 23
Monitor Screen .................................................................................................................................................. 23
View Log File .................................................................................................................................................... 25
Configure Alarm Mass Threshold (Sensitivity) ................................................................................................. 26
Logout................................................................................................................................................................ 26
Software Updates ............................................................................................................................................... 26
Sensor Specifications................................................................................................................................................... 27
Integrating the CMD-Server 24 with your network..................................................................................................... 28
Changing the CMD-Server IP address............................................................................................................... 28
Accessing the CMD-Server over a WAN .......................................................................................................... 29
Integrating the CMD-Server 8 with your network....................................................................................................... 30
Changing the CMD Server-8 IP address............................................................................................................ 30
Accessing the CMD-Server over a WAN .......................................................................................................... 30
Remote Switch Device ................................................................................................................................................ 32
Installation ......................................................................................................................................................... 32
Running the Application .................................................................................................................................... 33
Removing the Application ................................................................................................................................. 35
Dry contact switch specifications for Server-8............................................................................................................ 36
Dry contact switch specifications for Server-24.......................................................................................................... 37
Problem Solving .......................................................................................................................................................... 38
Install MS .NET framework and Java ......................................................................................................................... 39
Allow a remote PC to fully communicate with a Server-8.......................................................................................... 40
Release 10.9 Notes ...................................................................................................................................................... 41
Upgrade Process ................................................................................................................................................ 41
Graphical User Interface (GUI) Changes........................................................................................................... 41
Server Changes .................................................................................................................................................. 42
Technical Support........................................................................................................................................................ 44
Contact information..................................................................................................................................................... 44
UltraVision Security, Inc. • Salem, New Hampshire 03079 USA • Tel 866.374.9732 • 603.685.0303 • Fax 603.898.1840
Rev 031109
®
Table of Contents
www.UltraVisionSecurity.com • info@UltravisionSecurity.com
1
Advertisement
Table of Contents
Summary of Contents for UltraVision UltraSensor CMD-2
-
Page 1: Table Of Contents
Upgrade Process ..............................41 Graphical User Interface (GUI) Changes......................41 Server Changes ..............................42 Technical Support................................ 44 Contact information..............................44 UltraVision Security, Inc. • Salem, New Hampshire 03079 USA • Tel 866.374.9732 • 603.685.0303 • Fax 603.898.1840 www.UltraVisionSecurity.com • info@UltravisionSecurity.com Rev 031109... -
Page 2: Product Overview
Three standard servers are available; they are designed to control, monitor and power up to 8, 24 and 48 CMD sensors. Custom systems can be designed as required. UltraVision Security, Inc. • Salem, New Hampshire 03079 USA • Tel 866.374.9732 • 603.685.0303 • Fax 603.898.1840 www.UltraVisionSecurity.com • info@UltravisionSecurity.com... - Page 3 The resulting side view of the installation complete with detection field is shown (right).The detection hemisphere has a diameter of 50 feet (15m). UltraVision Security, Inc. • Salem, New Hampshire 03079 USA • Tel 866.374.9732 • 603.685.0303 • Fax 603.898.1840 www.UltraVisionSecurity.com • info@UltravisionSecurity.com Rev 031109...
-
Page 4: Server-24
The following diagram shows the primary connections that can be made to the Server. AC Power Internet Connection Daisy Chain Connections (2) Dry Switch Connections (24) Direct Connections (4) UltraVision Security, Inc. • Salem, New Hampshire 03079 USA • Tel 866.374.9732 • 603.685.0303 • Fax 603.898.1840 www.UltraVisionSecurity.com • info@UltravisionSecurity.com Rev 031109... -
Page 5: Server-8
CMD Server-8 includes a laptop with all the software needed to run the system. Front view Dry switch contacts- 8 sets Back view UltraVision Security, Inc. • Salem, New Hampshire 03079 USA • Tel 866.374.9732 • 603.685.0303 • Fax 603.898.1840 www.UltraVisionSecurity.com • info@UltravisionSecurity.com Rev 031109... -
Page 6: Usb Connection
USB connection Ethernet connection UltraVision Security, Inc. • Salem, New Hampshire 03079 USA • Tel 866.374.9732 • 603.685.0303 • Fax 603.898.1840 www.UltraVisionSecurity.com • info@UltravisionSecurity.com Rev 031109... -
Page 7: Installation Guide
Server and defined cable length limitations. Cable length limits are due to Ethernet transmission limits and power transmission limits. UltraVision Security, Inc. • Salem, New Hampshire 03079 USA • Tel 866.374.9732 • 603.685.0303 • Fax 603.898.1840 www.UltraVisionSecurity.com • info@UltravisionSecurity.com Rev 031109... - Page 8 Wireless and F/O may be used in place of Ethernet cable . Power is then supplied from an indirect source. UltraVision Security, Inc. • Salem, New Hampshire 03079 USA • Tel 866.374.9732 • 603.685.0303 • Fax 603.898.1840 www.UltraVisionSecurity.com • info@UltravisionSecurity.com...
- Page 9 A maximum of 4 CB-06 Boxes can be in a single daisy-chain from the SERVE . Maximum cumulative cable distance from the SERVER to any CMD sensor is 1,200 feet (390m). UltraVision Security, Inc. • Salem, New Hampshire 03079 USA • Tel 866.374.9732 • 603.685.0303 • Fax 603.898.1840 www.UltraVisionSecurity.com • info@UltravisionSecurity.com...
- Page 10 The dry switch outputs can also be used to sound alarms, turn on lighting and perform any other operation required in a standard security system. UltraVision Security, Inc. • Salem, New Hampshire 03079 USA • Tel 866.374.9732 • 603.685.0303 • Fax 603.898.1840 www.UltraVisionSecurity.com • info@UltravisionSecurity.com...
-
Page 11: Cmd Cable Assembly
8. The 2 pieces do not need to be fully separated, just the red part slightly extracted. 9. Insert pins noting the pin numbering/labeling on the red section UltraVision Security, Inc. • Salem, New Hampshire 03079 USA • Tel 866.374.9732 • 603.685.0303 • Fax 603.898.1840 www.UltraVisionSecurity.com • info@UltravisionSecurity.com... -
Page 12: Wire Diagram
If CB to CMD exceeds 110’/33m, crimp the pin 5 wire (wht/blu) with pin 7 (wht/brn), then crimp the pin 6 wire (blu) with pin 8 (brn) at both ends. Do not use pins 5 and 6. UltraVision Security, Inc. • Salem, New Hampshire 03079 USA • Tel 866.374.9732 • 603.685.0303 • Fax 603.898.1840 www.UltraVisionSecurity.com • info@UltravisionSecurity.com... - Page 13 UltraVision Security, Inc. • Salem, New Hampshire 03079 USA • Tel 866.374.9732 • 603.685.0303 • Fax 603.898.1840 www.UltraVisionSecurity.com • info@UltravisionSecurity.com Rev 031109...
-
Page 14: Configuration Manager Software
Desktop, select Digi Discovery. Verify all sensor IP’s are present. (Sensors take 30 seconds to appear after powered on) Check cables and connections if any are missing. Close Digi Discovery when finished. UltraVision Security, Inc. • Salem, New Hampshire 03079 USA • Tel 866.374.9732 • 603.685.0303 • Fax 603.898.1840 www.UltraVisionSecurity.com • info@UltravisionSecurity.com Rev 031109... - Page 15 1 twice and a period twice.) Additional users may be added and password changed after initial log-in. Left click Log-in. User name: admin Password: generic11.. UltraVision Security, Inc. • Salem, New Hampshire 03079 USA • Tel 866.374.9732 • 603.685.0303 • Fax 603.898.1840 www.UltraVisionSecurity.com • info@UltravisionSecurity.com Rev 031109...
-
Page 16: Create /Edit Users
2. This page is used to change password or add a new user. Select New User to add a user. UltraVision Security, Inc. • Salem, New Hampshire 03079 USA • Tel 866.374.9732 • 603.685.0303 • Fax 603.898.1840 www.UltraVisionSecurity.com • info@UltravisionSecurity.com... -
Page 17: Change Password
1. In the setup user screen, select the user in the pull down list to be deleted. 2. Click the Delete User button. 3. A confirmation page will open. UltraVision Security, Inc. • Salem, New Hampshire 03079 USA • Tel 866.374.9732 • 603.685.0303 • Fax 603.898.1840 www.UltraVisionSecurity.com • info@UltravisionSecurity.com Rev 031109... -
Page 18: Configure Sensors
Select Alternate schedule mode and Apply before edit schedule. iv. Use the Alternate settings table so turn sensors on and off to a schedule. UltraVision Security, Inc. • Salem, New Hampshire 03079 USA • Tel 866.374.9732 • 603.685.0303 • Fax 603.898.1840 www.UltraVisionSecurity.com • info@UltravisionSecurity.com... -
Page 19: Delete A Sensor
1. To delete a configured sensor, change the scanning status to Disabled. 2. Click Apply. 3. Delete Sensor button is now active. Click to delete selected sensor. UltraVision Security, Inc. • Salem, New Hampshire 03079 USA • Tel 866.374.9732 • 603.685.0303 • Fax 603.898.1840 www.UltraVisionSecurity.com • info@UltravisionSecurity.com Rev 031109... -
Page 20: Configure System
After Sensors and Contacts are Configured (see below) you can return to Configure System at any time to view System Summary or Contact Summary. UltraVision Security, Inc. • Salem, New Hampshire 03079 USA • Tel 866.374.9732 • 603.685.0303 • Fax 603.898.1840 www.UltraVisionSecurity.com • info@UltravisionSecurity.com... -
Page 21: Set Map Scale
Double-click on the sensor you wish to change. Enter new values. Save. For a more complete list of configuration settings, see the Configure Sensor section. UltraVision Security, Inc. • Salem, New Hampshire 03079 USA • Tel 866.374.9732 • 603.685.0303 • Fax 603.898.1840 www.UltraVisionSecurity.com • info@UltravisionSecurity.com... -
Page 22: Configure Contacts
9. To delete a device, select the device from the Select Dry contact Device pull down list. The Delete Device button is activated. Select and confirm. UltraVision Security, Inc. • Salem, New Hampshire 03079 USA • Tel 866.374.9732 • 603.685.0303 • Fax 603.898.1840 www.UltraVisionSecurity.com • info@UltravisionSecurity.com... -
Page 23: Contact Closure Detail
Power and Heartbeat would normally not call for camera activation and should be linked to other contacts to create operator or monitor awareness. Monitor Screen UltraVision Security, Inc. • Salem, New Hampshire 03079 USA • Tel 866.374.9732 • 603.685.0303 • Fax 603.898.1840 www.UltraVisionSecurity.com • info@UltravisionSecurity.com Rev 031109... - Page 24 Blue – Excessive environmental “noise” 3. As shown above, the Monitor Screen also shows a mini-log of current Sensor activity. UltraVision Security, Inc. • Salem, New Hampshire 03079 USA • Tel 866.374.9732 • 603.685.0303 • Fax 603.898.1840 www.UltraVisionSecurity.com • info@UltravisionSecurity.com...
-
Page 25: View Log File
Dismiss Checked. You will be asked to confirm when dismissing events. UltraVision Security, Inc. • Salem, New Hampshire 03079 USA • Tel 866.374.9732 • 603.685.0303 • Fax 603.898.1840 www.UltraVisionSecurity.com • info@UltravisionSecurity.com Rev 031109... -
Page 26: Configure Alarm Mass Threshold (Sensitivity)
3/11/09 Version 10.9 Server software released. See Release 10.9 Notes page 41 for more information. UltraVision Security, Inc. • Salem, New Hampshire 03079 USA • Tel 866.374.9732 • 603.685.0303 • Fax 603.898.1840 www.UltraVisionSecurity.com • info@UltravisionSecurity.com Rev 031109... -
Page 27: Sensor Specifications
12. The CMD2 is watertight to a depth of one meter. 13. All sensor software is upgradeable through the Internet. UltraVision Security, Inc. • Salem, New Hampshire 03079 USA • Tel 866.374.9732 • 603.685.0303 • Fax 603.898.1840 www.UltraVisionSecurity.com • info@UltravisionSecurity.com... -
Page 28: Integrating The Cmd-Server 24 With Your Network
Changing parameters other than those describe in this document can result in a non-functioning product that must be reset by UltraVision’s Support personnel. For this procedure you will need a router configured with a subnet of 10.10.0.0 and a subnet mask of 255.255.255.0 as well as a computer with either a compatible static IP address or a... -
Page 29: Accessing The Cmd-Server Over A Wan
Change the IP address, select Basic Settings from the left menu bar and enter the parameters in the main window that will make the CMD-Server compatible with your network: Accessing the CMD-Server over a WAN The CMD-Server can be accessed from anywhere in the world if the LAN to which it is connected is configured to allow in-coming traffic. -
Page 30: Integrating The Cmd-Server 8 With Your Network
Integrating the CMD-Server 8 with your network The CMD Server 8 communicates via a Netgear FVS114 router. Using a web browser like Microsoft’s Internet Explorer and entering an IP address will allow you to view and control the server 8 as though you were physically at its keyboard. The IP address of the Server-8 is preset to a value of 10.10.0.10 at manufacturing time. - Page 31 Rev 031109...
-
Page 32: Remote Switch Device
Measurement Computing, with the UltraVision Sensor Servers. This allows users to control a wide array of hardware components, such as alert lights, audible alarms and security cameras, automatically when one or more UltraSensors detects a change in an area being monitored. -
Page 33: Running The Application
When prompted to enter the Configuration Details, enter the Server IP or Hostname associated with the UltraVision Sensor Server running on your network. The Location and Access Code fields must correspond to those assigned to one of the Remote Contact Devices configured on the UltraVision Sensor Server using the Configure Contacts page. - Page 34 Windows Start Menu: Programs => UltraVision => UltraVision Remote Switch Device Upon successful execution, the UltraVision icon will be visible in the Windows system tray (the set of icons in the lower-right corner of the Windows Desktop): Whenever that icon is present, the Remote Switch Device is active and, if configured properly, will be automatically updating any Measurement Computing switches as directed by the UltraVision Sensor Server.
-
Page 35: Removing The Application
Diagnostics tab to view the log and determine the cause of the problem. Removing the Application The UltraVision Remote Switch Device application is easily removed from the system using the following procedure: If the application is currently running, double-click on the icon in the system tray to open the application GUI and press Exit Application to stop the application Select Settings =>... -
Page 36: Dry Contact Switch Specifications For Server-8
Dry contact switch specifications for Server-8 Rev 031109... -
Page 37: Dry Contact Switch Specifications For Server-24
Dry contact switch specifications for Server-24 Rev 031109... -
Page 38: Problem Solving
Problem Solving If application’s monitor display shows sensors as an orange dot with an “X” AND Digi Discovery can detect the sensors; Stop and restart the II service by going to the Windows Start Menu (Press Window Pane Key on keyboard) then selecting stop IIS. -
Page 39: Install Ms .Net Framework And Java
Install MS .NET framework and Java Use these instructions to install MS .NET framework and Java on a Server 24 running UltraSensor 10.7 or higher. To use an UltraSensor Server laptop on the web you need to configure it for DHCP so it will find an IP address and then change it back to a specific IP to reuse as the UltraSensor Server. -
Page 40: Allow A Remote Pc To Fully Communicate With A Server-8
Allow a remote PC to fully communicate with a Server-8 This resolves 2 symptoms exhibited by the remote PC: 1) The site map area is all red 2) Remote switch bank will not work At the Server-8 PC: 1) Log out of the UltraSensor application 2) Stop the service by going to START and select ‘Stop UltraSensor’... -
Page 41: Release 10.9 Notes
• upgrade the server and database (retaining user configuration), or upgrade everything (losing all data and setting the server to factory default settings). Summary The following significant changes were made to the UltraVision Sensor Server: • Added the UltraSensor Switch API • Added the UltraSensor Monitor API •... -
Page 42: Server Changes
• Added the Archived Logs button to the View Audit Log page to allow administrators to view the list of Audit Log archive files currently stored on the server. The new Audit Log Archive page also allows administrators to export a CSV file containing all archived audit records for a given day. - Page 43 • Added support for the LogViewMaxRows LogExportMaxRows configuration properties in the c:\uvss\blogic.ini file to control the maximum number of events that can be displayed in the GUI event table and exported to CSV files, respectively. The properties can be optionally specified as part of the [GUI] category, as in the following example:...
-
Page 44: Technical Support
Thank you for purchasing our product. Technical Support Email: techsupport@ultravisionsecurity.com Contact information UltraVision Security Systems, Inc., 16 Northwestern Drive, Salem NH 03079 USA www.UltraVisionSecurity.com info@UltraVisionSecurity.com Tel: 866-374-9732 603-685-0303 Fax: 603-898-1840 Rev 031109...
