Summary of Contents for GL Technologies GL-AR750
- Page 1 Package Contents GL-AR750 AC router Ethernet cable and USB power cable 5V/2A power adpater User guide AC TRAVEL ROUTER ver. 20171106.1...
- Page 2 HARDWARE Repair / Reset If you cannot access the web-based setup page or cannot connect to the router, you can press the Reset button: Press and hold for 3 seconds, and then release to repair your network. Press and hold for 10 seconds, and then release to reset the router to factory settings.
- Page 3 Insert TF Card & Power On or Connect via LAN Set up Router Connect via Wi-Fi When powered up, your GL-AR750 router will broadcast two Wi-Fi Connect to the 2GHz Wi-Fi called Visit http://192.168.8.1 in your browser to signals with the SSID: GL-AR750-xxx and GL-AR750-xxx-5G.
-
Page 4: Internet Setting
INTERNET SETTING After you have set up your router, you will see the main web interface. Find the Internet Settings SETTINGS icon, then click the New Connection button. The Internet Settings window will pop up showing four types of connection methods: Cable, Repeater, 3G/4G modem and Tethering. 192.168.x.x DHCP Cable (WAN) -
Page 5: Saved Networks
SSIDs. Choose a SSID and input the Wi-Fi password. GL-AR750 Router is a dual-band router; when it works as a repeater, you need to make sure that it uses the same frequency as the existing router does. - Page 6 3G/4G Modem Plug your 3G/4G modem into the USB2.0 port of the router, and it can transfer the 3G/4G signal to Wi-Fi. Due to the high power consumption of 3G/4G modems, you need to use a 5V/2A or higher power supply. Internet Settings After you set your Region and Service Provider, your carrier settings should be filled Cable...
- Page 7 Tethering / Hostless Modem Using the USB cable to share network from your smartphone or hostless modem to the mini router is called Tethering. Plug your phone into the mini router and click Trust to continue when the message pops up in your smartphone. Then turn on your phone’s Personal Hotspot.
-
Page 8: Openvpn Client
OPENVPN CLIENT This router supports OpenVPN client. Using OpenVPN will slow down your Internet speed because of data encryption. Click the OpenVPN icon and go to the VPN setting page. The first time it will ask you to upload your OpenVPN client configuration (ovpn files). Usually, you can download it from your OpenVPN service provider’s website or console. - Page 9 Connect to OpenVPN Now you can choose from a list of configurations and apply your choice to connect as OpenVPN client. To protect against DNS leaks, you must customize your DNS servers. You can enable Force all clients to override the DNS server settings for your client devices.
- Page 10 Luci. tor folder contains Tor firmware for the device. DDWRT Firmware GL-AR750 does not have an official DDWRT firmware now and it might be avaiable in the future. For further information, please visit https://www.dd-wrt.com Tor Firmware GL-AR750 does not have a Tor firmware now and it might be avaiable in the future.
- Page 11 SPEC Atheros AR9531, @650MHz Memory DDR2 128MB / FLASH 16MB Interfaces 1 WAN, 2LANs, 1 USB2.0, 1 micro USB (power), MicroSD card slot Frequency 2.4GHz, 5GHz Transmission rate 300Mbps(2.4GHz) + 433Mbps(5GHz) Tx power (maximum) 20dBm Protocol 802.11 b/g/n/ac Power supply Power consumption <6W Dimension, Weight...
-
Page 12: Warranty
3. Ask in our forum www.gl-inet.com/forums 4. Ask in other forums e.g. OpenWrt, LEDE or other professional websites Hong Kong Office Shenzhen Office GL Technologies (Hong Kong) Limited 深圳市广联智通科技有限公司 210D Enterprise Place, 5W Science Park, Hong Kong 深圳市宝安区石岩街道松白路创维数码大厦305-306室 ( +86-0755-86606126 ) - Page 13 2.4GHz Operating Frequency is 2400~2483.5MHz; 5GHz Operating Frequency is 5150 ~ 5250MHz and 5725 ~ 5850MHz; RF Exposure: The highest measured 1g (simultaneous transmission) Manufacturer: GL Technologies (Hong Kong) Limited, Unit 210D, 2/F, Enterprise Place Hong Kong Science Park, Shatin, N.T,...
