SmartSense
Micro Individual Sensor for
™
TEKDEK
LED
™
SSIS SERIES
INSTALLATION
Install luminaire (example below) per dedicated luminaire instructions, with Occupancy Sensor facing drive lane
or walkway.
Occupancy Sensor Lens
www. kenall.com
P: 800-4-Kenall
INSTALLATION INSTRUCTIONS
IMPORTANT SAFEGUARDS
When using electrical equipment, basic safety precautions
should always be followed, including the following:
THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE
APPLICABLE INSTALLATION CODE BY A PERSON FAMILIAR WITH
THE CONSTRUCTION AND OPERATION OF THE PRODUCT AND
THE HAZARDS INVOLVED. DISCONNECT POWER TO ALL CIRCUITS
BEFORE WIRING FIXTURE. INSTALL IN ACCORDANCE WITH
ALL NATIONAL, STATE, AND LOCAL CODES. DO NOT CONNECT
TO AN UNGROUNDED SUPPLY. READ ALL FIXTURE MARKINGS
AND LABELS TO ENSURE CORRECT INSTALLATION OF FIXTURE.
SUPPLEMENTAL INSTRUCTIONS MAY BE LOCATED ON THE
FIXTURE, IN ADDITION TO THIS INSTRUCTION SHEET, REGARDING
ORIENTATION, OR MOUNTING RESTRICTIONS.
SAVE THESE INSTRUCTIONS
F: 847-360-1781
1020 Lakeside Drive Gurnee, Illinois 60031
1
SSIS-F4515_110113
Advertisement
Table of Contents
Summary of Contents for kenall SSIS SERIES
-
Page 1: Installation Instructions
Micro Individual Sensor for ™ INSTALLATION INSTRUCTIONS TEKDEK ™ SSIS SERIES IMPORTANT SAFEGUARDS When using electrical equipment, basic safety precautions should always be followed, including the following: THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE APPLICABLE INSTALLATION CODE BY A PERSON FAMILIAR WITH THE CONSTRUCTION AND OPERATION OF THE PRODUCT AND THE HAZARDS INVOLVED. - Page 2 1) For dimming adjustment, remove the lens, counter clockwise for less dimming. Factory level then remove these screws and plate shown is set at Full Dimming which equals 15-20% above. light output. www. kenall.com P: 800-4-Kenall F: 847-360-1781 1020 Lakeside Drive Gurnee, Illinois 60031 SSIS-F4515_110113...
- Page 3 Connect the red (Interconnect +) and blue (Low Voltage Ground -) wires between luminaires as seen below: Occupancy detection will be communicated between interconnected luminaires (i.e. zonal occupancy) and therefore eliminate the “Cascade-ON” effect. *Note: Cap unused Interconnect and Low-voltage ground wires. www. kenall.com P: 800-4-Kenall F: 847-360-1781 1020 Lakeside Drive Gurnee, Illinois 60031...
- Page 4 BIRD GUARD INSTALLATION DIRECT TO SURFACE WITH SSIS OPTION 1: No tools required. Must install before fi xture is mounted. 2: Align slot and lay in bird guard. www. kenall.com P: 800-4-Kenall F: 847-360-1781 1020 Lakeside Drive Gurnee, Illinois 60031 F-4556_041013 www.
-
Page 5: Customer Service
Kenall’s entire liability on any claim of loss or damage resulting from a defective product is limited to the replacement price of the product.
