Interface, Inc. • 7401 E. Butherus Dr. • Scottsdale, AZ 85260 • 800-947-5598
Aufgrund laufender Weiterentwicklungen sind Änderungen der Spezifikationen vorbehalten. Alle Angaben vorbehaltlich Satz- und Druckfehler.
Vertrieb für Österreich :
www.nbn.at
9320
Load Cell Hand Held
Digital Indicator
TEDS Plug & Play Ready
IEEE 1451.4 Compliant
User Manual
13-69 Rev 2.4
www.interfaceforce.com
9320TEDSman2R2_4.doc
nbn Elektronik Handelsgesellschaft m. b. H.
Riesstraße 146, 8010 Graz | Tel. +43 316 40 28 05 | Fax +43 316 40 25 06
Advertisement
Table of Contents
Summary of Contents for NBN 9320
- Page 1 Aufgrund laufender Weiterentwicklungen sind Änderungen der Spezifikationen vorbehalten. Alle Angaben vorbehaltlich Satz- und Druckfehler. Vertrieb für Österreich : nbn Elektronik Handelsgesellschaft m. b. H. www.nbn.at Riesstraße 146, 8010 Graz | Tel. +43 316 40 28 05 | Fax +43 316 40 25 06...
-
Page 2: Table Of Contents
Menu Structure ....................7 Configuration Menu ..................8 Calibration Menu ..................... 10 Operation Features ..................11 Normal Display Operation .................. 11 Switching the 9320 On/Off ................. 11 RANGE Button....................11 HOLD Button ....................13 GROSS/NET Button................... 13 SHUNT CAL Button ................... 13 PEAK Button.................... -
Page 3: What Is Teds
And because all sensors produced according to the standard will carry the same basic identically formatted self-identification information, you will be able to mix and match sensors and applicable signal conditioners across manufacturers. Interface 9320 TEDS Ready Indicator Manual Issue 2.4... -
Page 4: Advantages
50mV/V. Bridge resistances from 85Ω upwards can be used with the 9320. Configuration and calibration of the 9320 is achieved using the front panel push buttons to navigate through a very simple menu structure. -
Page 5: Electrical Connection Information
+ve Charge Input or TEDS RS232 Port Connections If the 9320 has been ordered with the optional RS232 output, then this will be available via a 7 pin 723 series Binder connector. The wiring for this is as detailed below:... - Page 6 There are six push buttons on the front panel of the 9320, which are available for use in normal operation. Each of these is described below: Front Panel Button Function of Button in Normal Operation Mode To switch the 9320 ON or OFF press and hold the...
-
Page 7: Menu Structure
Menu Structure The 9320 has two menus, details of which are outlined below: A CONFIGURATION MENU, which enables the user to tailor the operation to meet a specific application requirement. The values selected in the CONFIGURATION MENU are completely independent for each range. -
Page 8: Configuration Menu
10Hz, 3Hz, 1Hz, 0.5Hz. to set the update rate for the value you want press Press To skip to next menu item OUEr Press To set overload alarm Interface 9320 TEDS Ready Indicator Manual Issue 2.4... - Page 9 The RS232 output is an option that has to be rS232 ordered with the 9320. To conserve battery life, it is suggested that the RS232 output is disabled, when it is not required.
-
Page 10: Calibration Menu
To select 50mV/V you need to power down the unit and access the internal circuit board. Move link LK1 and place it onto JP1. Power on the 9320 and return to this point of the calibration menu. You will notice that the menu parameter has changed to SEnS 50.0, press... -
Page 11: Operation Features
Normal Display Operation The 9320 has a full 7 digit display, which can be scaled using the calibration menu to suit the application it is to be used in. The display can display the instantaneous, peak or valley values. It is also possible to hold the display value (this only operates when not in peak or valley mode). -
Page 12: Hold Button
PEAK Button When pressed this button puts the 9320 into peak mode. This will display the highest display reading and hold it on the display until it is reset or a higher value is reached. To reset the peak display, press the peak and valley buttons simultaneously. -
Page 13: Configuration Menu Parameters
The benefit is that the battery life, based on a 350Ω sensor bridge being connected, increases from 45 hours to 450 hours. It is also important to remember that when the 9320 is re-calibrated with a sensor, the power save facility will be automatically turned off. The power save facility will therefore need to be re-activated after calibration has been completed. - Page 14 OFF). i.e. if this was set to 25, then if the 9320 detects no keyboard activity for a continuous 25 minute period, then the 9320 will power down, to conserve power. If keyboard activity is detected at any time during the 25 minute period, then the time period is restarted.
-
Page 15: Calibration Menu Parameters
If however, a higher sensitivity sensor is used with the 9320, it will be necessary to gain access to the internal PCB (you must turn the 9320 off) to move link LK1 to JP1 (see picture below) to allow the 9320 to accept sensitivities of up to 50mV/V. -
Page 16: Calibration Procedures
9320 automatically. If this is not possible, then the sensitivity figure (in mV/V) from the sensor calibration certificate can be used to scale the 9320, by using the tAbLE calibration. -
Page 17: Internal Calibration
9320 must therefore have an internal mV/V reference. This section describes a procedure for periodic calibration of the internal reference. 50.0 gAIn 1.00000 If the 9320 is not used in the TEDS mode and is scaled only by LiVE tAbLE method, not the method, internal calibration 50.0 OFFS... - Page 18 However, the simulator provides the most reliable and trouble-free method. 3. Take 9320 0 mV/V Reading and the 9320 4 mV/V Reading (using the preferred 4 mV/V as the example). Find the net reading by subtracting the former from the later.
-
Page 19: Specifications
EN 50 081 – 2 : 1992 (Heavy Industrial) pr EN 50 093 : 1991 EN 50 082 – 1 :1992 (Light Industrial) EMC Emissions EN 50 082 – 2 :1992 (Heavy Industrial) Mechanical Dimensions Interface 9320 TEDS Ready Indicator Manual Issue 2.4... -
Page 20: Warranty
Warranty The 9320 is warranted against defective material and workmanship for a period of (1) one year from the date of dispatch. If the Interface, Inc. product you purchase appears to have a defect in material or workmanship or fails during normal use within the period, please contact your Distributor, who will assist you in resolving the problem.
