- Page 1 PRODUCT MANUAL ISO 9001 ISO 14001 Registered Registered Quality Environmental Management Management...
-
Page 2: Table Of Contents
TABLE OF CONTENTS INTRODUCTION Product & technology Key features Product range Typical applications Product overview INSTALLATION Mounting height, angles, clearance Connecting power Power & wiring Power on test USER CONFIGURATION Setting switch parameters Rotary switch functions Dip switch functions Switch functions RS422 Version - connecting the radar to a computer RS422 Preparing the connection Terminal setup... -
Page 3: Introduction
INTRODUCTION PRODUCT & TECHNOLOGY The 307 is a compact Doppler vehicle radar which operates in the K-Band at 24GHz. It is designed to be robust, cost effective and highly versatile offering outstanding detection performance for multiple Intelligent Transport Systems (ITS) management applications. -
Page 4: Typical Applications
INTRODUCTION TYPICAL APPLICATIONS Intersection control Vehicle Actuated Sign driver Temporary applications *optional version available on request PRODUCT OVERVIEW Sighting guide Front (power on) detect LED Pan and tilt mounting foot 12/24V versions 230V versions Access port for configuration switches Power and opto /RS422 Rear Power... -
Page 5: Installation
INSTALLATION MOUNTING HEIGHT, ANGLES, CLEARANCE Mount the radar on a firm structure within a recommended height range of 2m-5m. For optimum performance the radar should be situated on a pole adjacent to the carriageway with an unobstructed view of advancing traffic. -
Page 6: Connecting Power
INSTALLATION CONNECTING POWER • Set your power supply to the correct voltage, which can be found on the label on the top of the unit. • Connect the unit to the supply. • Once powered, the front LED will flash five times whilst the radar performs its self check routines. -
Page 7: Power On Test
INSTALLATION POWER & WIRING (CONTINUED) 3+2 WAY 230Vac Wire Colour Function Power Off Power On No Detect Power On Detect Brown 230Vac live Blue 230Vac neutral Relay common Green Relay Blue Relay N/O = High Impedance switched output N/C = Low Impedance switched output Power Options 12Vdc 24Vdc... -
Page 8: User Configuration
USER CONFIGURATION SETTING SWITCH PARAMETERS ROTARY SWITCH FUNCTIONS Rotary switch (10-way) Rotary Low speed Rotary Low speed switch threshold switch threshold position position • Remove blanking plug using 8mm hex key to gain access to rotary and DIP switches. • Select settings required. •... -
Page 9: Dip Switch Functions
USER CONFIGURATION DIP SWITCH FUNCTIONS DIP Switch (4-way) DIP Switch number Parameter Switch off value Switch on value (bottom position) (top position) Detection direction Advance only Bi-directional Detect targets that are... Front detect LED Illuminate during detection? Sensitivity / range Medium High (Typically up to 100m... -
Page 10: Switch Functions
USER CONFIGURATION SWITCH FUNCTIONS RS422 Mode (switch override) When the rotary switch is set to <0>, all switches become inactive. RS422 commands configure the unit. Switch bank disabled When the rotary switch is set to a value other than <0>, switches control the unit. -
Page 11: Rs422 Version - Connecting The Radar To A Computer
Flow control (handshaking) None (see *BAUD command on page 19) The product will always respond to the “AGD” command via RS422. All outgoing commands should end with a carriage return <CR> character; this is typically the enter/return key of a keyboard, though may be an advanced option in some emulators. -
Page 12: Terminal Setup
USER CONFIGURATION TERMINAL SETUP The following Tera Term screenshots will show how to set up and configure the 307 radar detector. These screenshots were produced using the following terminal settings, in order that the commands sent to the 307 would be shown on the terminal screen along with the responses from the radar. - Page 13 USER CONFIGURATION TERMINAL SETUP 3: In the main window, select ‘Setup’ from the top menu and left click on ‘Terminal’ 4: In the Terminal setup window, ensure that Receive is set to CR+LF and that local echo is active...
- Page 14 USER CONFIGURATION TERMINAL SETUP 5: In the main window, select ‘Setup’ and ‘Serial port setup’. Ensure that the correct COM port is selected and that the options are configured as below; SERIAL PORT CONFIGURATION Parameter Setting Baud rate 9600 Data bits Parity None Stop bits...
- Page 15 ‘Setup’ and ‘Font’ and set the font size to suit your needs. 8: Once you have configured TeraTerm correctly, and the 307 is connected to your computer and powered up, press the ENTER key and TeraTerm should display the READY message.
-
Page 16: Rs422 Test Connection
USER CONFIGURATION TEST CONNECTION Test the connection by typing AGD ■ and pressing the <Enter> key. The detector will respond with model AGD SYSTEMS LTD AGD 307 and version details. If not, check RADAR Version MI-122-X communication and power cables ■... -
Page 17: Rs422 Command Structure
USER CONFIGURATION RS422 COMMAND STRUCTURE • Most commands start with an asterisk <*> *<COMMAND SENT BY USER> • The radar responds using a hash <#> prefix #<VALIDATION OF COMMAND FROM RADAR> • Commands are sent to the radar using the <Enter>... -
Page 18: Rs422 Command List
USER CONFIGURATION RS422 COMMAND LIST Command Suffix Function Units, resolution value value or values 1 = 9600 Baud rate (bits per second) of RS422 2 = 19200 * BAUD ? = $ ^ connection 3 = 115200 4 = 230400 Report targets travelling 0 = advance only * BIDI... -
Page 19: Rs422 Command Details
An advancing target is one that travels towards the front-face of the detector. A receding target is one that travels away from the front-face. The 307 can be configured to report advancing targets only, or both advancing and receding targets. Note that this parameter is also accessible via the switch settings. - Page 20 USER CONFIGURATION RS422 COMMAND DETAILS *LED This command will determine whether the front LED is illuminated during a detect state. Note that this parameter is also accessible via the switch settings. Typical response – #LED?0 where 0 = off and 1 = on *LOWSPEED This command accesses the Low Speed threshold/cutoff in kph.
- Page 21 Typical response – #REBOOT!... *SAVE The 307 needs its settings to be saved after adjustments have been made. Changes not committed with the *SAVE! command will be forgotten on the next power-cycle or *REBOOT!. To maximise the detector’s flash memory, this command should only be used when changes have been made.
-
Page 22: Technical Specifications
EMC Specification EN301-489 and BSEN50293 Radio Specification ETS 300.440 Electrical Safety EN60950 Owing to the company’s policy of continuous improvement, AGD Systems Limited reserves the right to change their specification or design without notice. RoHS COMPLIANT Restriction on Hazardous Substances... -
Page 23: Help
RS422. For this reason most RS232 interfaces will not be suitable. 3. When the unit receives an AGD command it will always return a legible response. Send an AGD command to ensure the serial connection is setup correctly. Try sending at each baud rate to identify whether unit has changed from the default value. - Page 24 HELP TROUBLESHOOTING RS422 speed messages cause problems with connected equipment 1. The *MS command controls how often the radar sends a speed message. Sending fewer messages each second may help connected equipment. 2. The *MS command also controls the format of each message. Choosing a format with fewer characters will reduce message overhead.
-
Page 25: Trial And Evaluation
TRIAL AND EVALUATION SET UP TOOLS ALL VERSIONS FOR RS422 VERSIONS 307 Radar Product support 8mm Allen/hex key CA-250 adapter cable including D-type wireable socket INCLUDED TRIAL KIT ▼ 12/24V or 230V Power supply 932 Target simulator Computer or Laptop... -
Page 26: Manufacturing Test Process
AGD Systems dedicated to the within the Saturn test process. The test results in association testing of the 307 detector range. 100% of these with the product build revision are recorded on a product serial number basis. The full suite of test measurements is instantly... -
Page 27: Important Safety Information
Under no circumstances should a product suspected of damage be powered on. Internal damage may be suggested by unusual behaviour, an unusual odour or damage to the outer casing. Please contact AGD for further advice. -
Page 28: Low Power Non-Ionising Radio Transmission And Safety
Note 4 Comparison for product model 307 operating in the band typically 24.050GHz to 24.250GHz From the table it can be seen that it is extremely unlikely that a potentially hazardous situation could occur owing to the use of such low power devices. - Page 29 NOTES...
- Page 30 NOTES...
- Page 31 NOTES...
-
Page 32: Disclaimer
DISCLAIMER While we (AGD Systems) endeavour to keep the information in this manual correct at the time of print, we make no representations or warranties of any kind, express or implied, about the completeness, accuracy, reliability, suitability or availability with respect to the information, products, services, or related graphics contained herein for any purpose.
