QUICK START GUIDE

Charge Completely!

Immediately After
Purchase
CHARGING
INPUT
CHARGING
Charge Power Pack until the
Charge Light turns OFF.
Approximate AC Charge Time
Initial Charge: 48 hours
Recharge: 34 hours

Maintain The Battery!

Fully Recharge:
• When Voltage Drops To 12V
• After Each Jump-Start
• Once a Month
Failure to maintain the battery
will void the warranty.

Jump-Starting a Vehicle

WARNING
To prevent serious injury:
1. Do not touch positive and negative battery clamps together.
2. Do not connect to the negative terminal of the battery.
1
Turn OFF
Vehicle Ignition
& Clamp Power
OFF
OFF
2
Connect
Battery Clamps
Grounded
Metal
Battery
CONNECT RED POSITIVE CLAMP FIRST, THEN
CONNECT BLACK NEGATIVE CLAMP TO A
NON-MOVING METAL PART OF THE VEHICLE.
3
Turn ON
Clamp Power
ON
3
in
ITEM
62306
PORTABLE
POWER PACK
4
Wait 5 minutes!
AFTER TURNING
CLAMP POWER ON,
5 wait 5 minutes before
starting ignition.
MIN
THE VEHICLE WILL NOT
START IF YOU DON'T
WAIT 5 MINUTES!
5
Turn ON
Vehicle Ignition
START
After the vehicle is started:
1. Turn OFF the Clamp Power.
2. Remove the Black Negative Clamp.
3. Remove the Red Positive Clamp.
WARNING
This Quick Start Guide is not intended to replace the
Owner's Manual & Safety Instructions. Read all safety
warnings and instructions therein to ensure proper
usage and to avoid personal injury.
