1. Introduction

The Trigger-Output Module A-157-2 and the Control-
Input Module A-157-3 are both required to drive the
Trigger Sequenzer A-157-1:
The Trigger-Out Module A-157-2 is where the trigger
signals (+12V) for each sequencer track can be tapped
from.
The Control-Input Module A-157-3 is used to control the
sequencers run functions (start / stop / reset / clock). You
can either control them manually using the push buttons, or
by applying external signals of ≥ +3 Volts.
Please note: To run the sequencer, an external clock signal
has to be patched to the A-157-3 clock input socket. Please
refer to page 2.
IMPORTAND: Before installing the modules A-157-2
and
A-157-3
please
instructions on pages 3 and 4 !
System A-100
read
carefully
the
setup
Trigger-Sequenzer A-157-2/3

2. A-157-2 Trigger Output Module

The Trigger-Output Module A-157-2 is self explaining. The
eight sockets provide the trigger signals (+12V) for each
sequencer track.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the A-157-2 and is the answer not in the manual?

Questions and answers

Summary of Contents for DOEPEFER A-157-2

  • Page 1 1. Introduction 2. A-157-2 Trigger Output Module The Trigger-Output Module A-157-2 and the Control- The Trigger-Output Module A-157-2 is self explaining. The Input Module A-157-3 are both required to drive the eight sockets provide the trigger signals (+12V) for each Trigger Sequenzer A-157-1: sequencer track.
  • Page 2 Trigger-Sequenzer A-157-2/3 System A-100 DOEPFER 3. A-157-3 Control Input Module 3.1. Control keys / inputs The Control-Input Module A-157-3 is used to control the sequencers run functions (start / stop / reset / clock). You Start can either control them manually using the push buttons, or Hitting the key (or routing a positive pulse into the respective by applying external signals of ≥...
  • Page 3 A-157-3 control input module. Simply connect flat ribbon cables with the following sockets: • (1) the socket labelled „JP2“ of the A-157-2 trigger output module with the socket labelled „JP3“ on the A-157-1 trigger matrix PCB. •...
  • Page 4 Trigger-Sequenzer A-157-2/3 System A-100 DOEPFER...
