Automationdirect.com C-more EA-FLASH-128MB Installation Instructions

C F
OMPACT LASH
W : Take the necessary steps to prevent damage that may be caused by static electricity discharge. Disconnect input power to the touch panel before
ARNING
proceeding.
CF Card Installed in CF Slot #1:
1 1
1 1
Remove the protective dust cover from the CF Slot #1 at the top of the
touch panel by prying up on one edge. Sit the dust cover aside for
re-installing after the CF card is installed.
3 3
3 3
Orientate the compact flash memory card so that the front label is facing
the back of the panel and the CF card connector faces into the slot. There
are guides on each side of the slot that will match the guides on the CF
card. The CF card can only be inserted one way.
5 5
5 5
To remove the CF card from the CF Slot #1, press in on the eject button to
the right of the CF card. This will cause the CF card to be partially
ejected from the slot allowing removal.
M C
EMORY ARD
/ EA-FLASH-128MB
P N
Preparation: If the touch panel is not already installed into a control cabinet, then in a clean environment,
place the panel face down on a lint-free soft surface to prevent scratching the front of the panel.
Protective
dust cover
CF card
eject button
I
NSTALLATION
2 2
2 2
CF Slot #1 shown above with the protective dust cover removed.
4 4
4 4
Gently press the CF card into the slot until it stops. You should feel a slight
resistance as the CF card connector mates with the slot's connector. The
CF card should be flush with the slot's opening.
The dust cover can now be re-installed.
NOTE: CF
CARD INSTALLATION FOR
ON THE BACK OF THIS DATA SHEET
W : Do NOT use EZTouch RAM or Flash memory cards with
ARNING
the C-more touch panels.
H - 1
A S
D
- F L A R
H C
E Z
A S
F L
K B
d e
5 1 2
C o
t e
D a
8
0 2 3
:
I N G
h i s
h t
R N
w i t
W A
u l e
n .
o d
o w
l m
t a l e d
I n s s i d
3505 HUTCHINSON ROAD
CUMMING, GA 30040-5860, USA
I
NSTRUCTIONS
CF Slot
#1
CF S #2
LOT IS SHOWN
.
