Version 1.0 / 201704
2 WIRE IP SYSTEM
4 inch Guard Station
COLOR TFT TOUCH SCREEN WITH HANDSET
OPERATION MANUAL
2
REC
• Please read this manual carefully before using the product you purchase,and keep it well for future
use.
• Please note that images and sketch maps in this manual may be different from the actual product.
Advertisement
Table of Contents
Summary of Contents for XtendLan DPM-D246-IP
- Page 1 Version 1.0 / 201704 2 WIRE IP SYSTEM 4 inch Guard Station COLOR TFT TOUCH SCREEN WITH HANDSET OPERATION MANUAL • Please read this manual carefully before using the product you purchase,and keep it well for future use. • Please note that images and sketch maps in this manual may be different from the actual product.
- Page 2 PRECAUTIONS • Slots or openings in the back of the monitor, are provided for ventilation and to ensure reliable operation of the video monitor or equipment and to protect if from overheating. These openings must not be blocked or covered. The monitor should never be placed near or over a radiator or heat register and should not be placed in a built-in installation such as a bookcase unless proper ventilation is provided. • All parts should be protected from violence vibration. And not allow be impacting, knocking and dropping. • For clean the LCD screen, using hands or wet cloth is forbidden. • Please do the cleanness with soft cotton cloth, please do not use the organic or chemical clean impregnate. If necessary, please use pure water or dilute soap water to clean the dust.
-
Page 3: Table Of Contents
CONTENTS PARTS AND FUNCTIONS ..................4 Part Names......................4 Mounting ......................... 5 Screen ........................6 BASIC OPERATIONS .................... 7 Answering a call ..................... 7 Basic operation based on Namelist ................ 8 Select a user or a Guard Station to be called ............ 8 Select a video door station to be monitored ............ -
Page 4: Parts And Functions
PARTS AND FUNCTIONS Part Names [13] [14] [10] [11] [12] Key functions Item Description • See the menu details Color LCD touch screen • Display videos and images Handset Pick up to answer the call Monitor button Monitor the video from the selected Door Station Manual record button Press to capture videos • Press to open/close the main menu page. -
Page 5: Mounting
PARTS AND FUNCTIONS Mounting Mounting box (size:86x86mm) The unit Mounting screw x 2(included) 2 wire cable Mounting bracket The installation height is suggested to 145~160cm. 1. Use screws to fasten the mounting bracket to the wall with mounting box. 2. Connect the power to the unit. 3. -
Page 6: Screen
PARTS AND FUNCTIONS Screen Main screen The Main menu is your starting point for using all the applications on your monitor. Press [Home] button or touch anywhere of the screen on monitor in standby mode, the Main menu will appear as follow: INPUT MODE Touch it to show the keypad. -
Page 7: Answering A Call
PARTS AND FUNCTIONS Communication screen Shows status of talking, Displays calling source. unlocking ect. Displays while recording. Displays talking time. 00:10 [9002]CDS2 If the calling source is a Video Door Station, video will be displayed. Touch it to end the talk- ing and close the screen. -
Page 8: Basic Operations
BASIC OPERATIONS Basic operation based on Namelist In default, the Namelist is not included.It should be configured by specific software.The following instructions is in the condiction of the namelist is created. 1.Select a User or a Guard Station to be called 2.Select a Name by touching it,calling is 1.On Main menu, touch [Intercom]... -
Page 9: Select A Video Door Station To Be Monitored
BASIC OPERATIONS 2.Select a Video Door Station Select a door station to be to be monitored released the lock [Monitor] icon [Unlock] 1.On Main menu, touch 1.On Main menu, touch to display Video resource list. icon to display Door Station list. 2.Select a Video Door Station by touching 2.Select a Door Station by touching it, it,minitoring is activated immediately.The... -
Page 10: Basic Operation By Input Code
BASIC OPERATIONS Basic operation by Input The another way to activate the functions of calling, monitoring, unlocking is by inputting code via the keypad on screen. There are two different types of code: Default code and Room code. Default code: logical device address,set by DIP switch. Room code: configured by software. -
Page 11: Release A Door Lock
BASIC OPERATIONS Search by name: 2.The inputting method is the same as the section of Calling User or Guard Maybe you just know the name of User Station. or Guard Station. For example,input the name “jim” on input box,then touch the 3.Select the Video Door Station you key “Search”, all Users or Guard Sta- want, then press... -
Page 12: Viewing Videos
BASIC OPERATIONS The recorded videos are stored in SD card directly. * Max. 32G Micro SD card is supported. Note: * Automatic recording function cannot be cancelled. * Automatic recording does not available while monitoring a door station. To save videos while monitoring, see manual recording below. Manual recording While be called,talking or monitoring,Touch button when an image is displayed. Note: * Manual recording is available at any time. * Manual recording cannot be performed during automatic recording. 1.The auto recording time limited is 10s. The videos will be saved on micro SD card directly. 2.The manual recording time is the time for ending manual recording.max.10s for each manual recording. -
Page 13: Viewing Calling Records
BASIC OPERATIONS Viewing calling records All calls of incoming,outgoing,missed will be recorded and can be reviewed afterwards. On main menu page, touch[Event] ->[Incoming call] icon, the most recent incoming call records are displayed. Current page Total page Be called in Calling source Exit Scroll to last page... -
Page 14: Setup Instructions
SETUP INSTRUCTIONS Setting date and time You can correct the current date at and time any time by following the procedure below. 1.On main menu page, touch icons [User Setup] ->[Date&Time] to enter Date&Time setting page. 2.Touch the setting target of year, month, date, hour,minute and second individually, then input the value by touching the digital keypad. -
Page 15: Setting Ring Tone&Ring Volume
SETUP INSTRUCTIONS Setting ring tone&ring volume The ring call tone can be set individually to distinguish different calling source. Total 20 tones can be selected. 1.On main menu page, touch icons [User Setup] ->[Call Tone] to enter Call Tone Select page. Ring Volume: setting the ring volume when receiving calls, the setting range is 1~9. -
Page 16: Specification
SETUP INSTRUCTIONS On main menu page,touch icons [User Setup] ->[More] ->[System Settings], a password will be asked. Input Code Num:[- - - -] Node ( 201-232 ):[- - -] Input the Code Num 8001,press Input the IP Adress by touching “ ” to save the setting and the digital keypad on input box, enter IP Address page. press “...
