Summary of Contents for Eoss DVR720E
- Page 1 HD 720P DASH CAM MANUAL 2.4” 720P LOOP FILE VIEW ANGLE LCD SCREEN RECORDING PROTECTION...
-
Page 2: Introduction
Product overview The EOSS DVR720E Dash Cam has been designed to provide high definition recordings of your trips for security and evidence in the case of an accident. The Dash Cam simply mounts to the windscreen and records footage onto a Micro SD memory card. -
Page 3: Table Of Contents
Table of Contents Introduction Product overview Product features Table of contents Package components Product structure Installation of Dash Cam Instructions for video, photo & audio operation Video/Photo/Audio playback Dash Cam functions Menu setting features explained Product specifications Trouble shooting guide Safety information &... -
Page 4: Package Components
Package components DVR720E Dash Cam Suction Mounting Bracket Car Charger USB to Mini USB... -
Page 5: Product Structure
Product structure 1) Micro SD card slot 2) Screen display 3) Emergency lock key 4) Suction mount attach point 5) Speaker 6) LED lights 7) Camera Lens 8) Power On/Off button 9) Arrow button 10) Menu button 11) OK button 12) Mode button 13) Arrow button 14) Reset button... -
Page 6: Installation Of Dash Cam
Installation of Dash Cam 1. Ensure windscreen is clean and free of debris. Attach suction cup to the windscreen and lock into position with the lever. 2. Fix where the vision is not blocked (Place close to rear-view mirror is recommended). Don't install device on airbag or within its working range. -
Page 7: Instructions For Video, Photo & Audio Operation
Instructions for video, photo & audio operation Powering device on and off: To turn on the Dash Cam press the Power On/Off button once, the red indication lamp will be light up if it is connected to a power source. To turn it off, hold down the power button and the device will turn off. -
Page 8: Video/Photo/Audio Playback
Audio Mode Press the Mode button to switch to audio recording mode. There is a microphone icon on the left of the LCD to signify you are on audio recording mode. To record audio, press the OK button. A red circle will flash and clock timer will appear and start recording audio only. -
Page 9: Dash Cam Functions
DASH CAM functions Menu Settings Press the Menu button to get into the menu settings. You can navigate the settings menu by using the Up/Down buttons. To change or edit a selected setting, press the OK button. Press the menu button again to get out of the menu settings. - Page 10 Format: This feature allows you to format/delete all the files off your micro SD card and also reinstalls your DCIM directory and Dash Cam software on your SD card so the micro SD card can operate with your Dash Cam free of errors. It also reinstalls your EVENT (SOS locked files) and NORMAL (Video and jpegs) directories on your Micro SD card.
- Page 11 Resetting the Dash Cam: To hard reset the device in the case of a system jam or crash. Insert a fine point paper clip into reset hole on the bottom of the unit.. Maintaining the Battery: To prolong the battery life you must charged your Dash Cam on a 5 volt home charger at least once a week for 2-3 hours with the dash cam off, if you don't use the car daily, for cars that are used daily for more than 1 hour you can charge the Dash cam once every 3 weeks for 2-3 hours.
-
Page 12: Product Specifications
Product specifications Power interface 5V DC/1A Display 2.4-inch LCD screen Color Black Video 720P 1280*720 at 30fps VGA 640*480 at 30fps Picture 3M/2M/1.3M/VGA Picture format Viewing Angle 90 Degree view angle LED lights Functions Loop recording, SOS file lock OSD Language English, Russian, Chinese, etc Audio Built-in Microphone and speaker... -
Page 13: Troubleshooting Guide
Troubleshooting guide Under normal operating conditions, if there are problems with the device, please refer to the following methods to resolve. Cannot take pictures or record video? Please check whether there is enough space on the micro SD card or internal storage. Stopping automatically while recording? Due to the high amount of HD video data being recorded, please use a high-speed Micro SD card. -
Page 14: Safety Information & Warnings
Safety information & warnings Do not use the Dash Cam in damp working conditions; the Dash Cam is not waterproof Do not try opening the shell or trying to repair the Dash Cam by yourself. If the accessories for the Dash Cam have any problems, please take it to an authorised repair agent for repair. -
Page 15: Technical Assistance
Technical assistance If you need assistance setting up or using your EOSS product now or in the future, call EOSS Support. Australia TEL: 03 – 8587 8898 FAX: 03 – 8587 8866 Mon-Fri 9am – 5pm AEST This manual is considered correct at time of printing but is subject to change.
