User's Manual
Timelapse camera
for Biodiversity Inventory
®
Référence Document
Révision
Date
ADV_UM_9022_01
1.5
31/07/2015
ADV_UM - 1.3 - 20120608
Advertisement
Table of Contents
Summary of Contents for Advansee BEECAM ADV00100V
- Page 1 31/07/2015 ADV_UM - 1.3 - 20120608 ADVANSEE – 2 rue Alfred Kastler – CS30750 – 44307 Nantes cedex 3– France Tél. : 33 (0)2 4050 2173 – Email : contact@advansee.com – www.advansee.com SARL au capital de 40 200€ - 510 580 814 RCS Nantes - SIRET 510 580 814 00042- TVAI : FR 31 510 580 814...
-
Page 2: Table Of Contents
7 Getting the recorded material...................19 7.1 USB flash drive....................19 7.2 FTP access......................19 8 Maintenance......................21 8.1 System information....................21 8.2 Firmware upgrade....................21 8.3 Cleaning.......................22 8.4 Repair........................22 8.5 End of life......................22 9 Troubleshooting guide....................23 Document: ADV_UM_9022_01_v1.5 - © ADVANSEE SARL 2015, All rights reserved page 2... -
Page 3: Introduction
PC, …) or with a configuration file written in a USB flash drive. The video sequences and the still images are stored on a USB flash drive plugged in the camera. Document: ADV_UM_9022_01_v1.5 - © ADVANSEE SARL 2015, All rights reserved page 3... -
Page 4: Description
• 4 screws, • supply cable, • quick start guide • Additional mandatory accessories In order a get a functional system, the following accessories are needed: Document: ADV_UM_9022_01_v1.5 - © ADVANSEE SARL 2015, All rights reserved page 4... -
Page 5: Product Description
8: Power supply plug 4: POWER button 9: Internal supply connector 5: POWER Led 10: fixation nut diameter 6 mm (M6) Technical characteristics 5 Megapixel 1/4 " CMOS sensor • Document: ADV_UM_9022_01_v1.5 - © ADVANSEE SARL 2015, All rights reserved page 5... -
Page 6: Electrical Characteristics
Protection: IP65 • Electrical characteristics The camera is supplied with different type of batteries, depending on purchase options. Dual supply voltage: 7.4 Volts or 12 Volts (internal automatic switch) Document: ADV_UM_9022_01_v1.5 - © ADVANSEE SARL 2015, All rights reserved page 6... -
Page 7: Installing The Camera
Attention: Never use a battery not strictly equivalent to the one provided at purchase time. In case you need to replace the battery, we strongly recommend to buy from ADVANSEE. Document: ADV_UM_9022_01_v1.5 - © ADVANSEE SARL 2015, All rights reserved... -
Page 8: Setting The Image Frame
5. Once the WIFI connection is established, open an internet browser (such as Mozilla Firefox, Google Chrome, Microsoft Internet Explorer, Apple Safari, etc...) and type the following address in the address bar: http://192.168.42.1 Document: ADV_UM_9022_01_v1.5 - © ADVANSEE SARL 2015, All rights reserved page 8... - Page 9 When the remaining time is between 1 and 2 minutes, the progress bar is orange. When the remaining time is less than 1 minute, the progress bar is red. Document: ADV_UM_9022_01_v1.5 - © ADVANSEE SARL 2015, All rights reserved page 9...
-
Page 10: Configuring The Camera
([Ctrl] + [F5] for Mozilla Firefox and Google Chrome, [Command] + [Option] + [E] for Apple Safari). 5. Click the icon to go back to the homepage Document: ADV_UM_9022_01_v1.5 - © ADVANSEE SARL 2015, All rights reserved page 10... - Page 11 (for video sequences) and the image settings (orientation, brightness, contrast, saturation and white balance). 1. From the web homepage, click the icon and then the icon. Document: ADV_UM_9022_01_v1.5 - © ADVANSEE SARL 2015, All rights reserved page 11...
- Page 12 ([Ctrl] + [F5] for Mozilla Firefox and Google Chrome, [Command] + [Option] + [E] for Apple Safari). 5. Click the icon to go back to the homepage Document: ADV_UM_9022_01_v1.5 - © ADVANSEE SARL 2015, All rights reserved page 12...
- Page 13 • at least 1 minute greater than the video duration. when recording still images, the interval between two successive shots must be at least • 1 minute. Document: ADV_UM_9022_01_v1.5 - © ADVANSEE SARL 2015, All rights reserved page 13...
-
Page 14: Configuring Through The Usb Flash Drive
2. Once connected, the online configuration tool will allow you to set the different parameters (interface is very similar to the one embedded in BEECAM®, thus refer to §5.1 for details on the parameters). Document: ADV_UM_9022_01_v1.5 - © ADVANSEE SARL 2015, All rights reserved page 14... - Page 15 The configuration file system.conf is a human-readable text file. However, we strongly recommend to not edit the file manually, as any inappropriate content may lead to unpredictable camera's behavior. Document: ADV_UM_9022_01_v1.5 - © ADVANSEE SARL 2015, All rights reserved page 15...
-
Page 16: Operating A Timelapse Sequence
FAT32 formatted. ◦ 2 pulses/second: Battery voltage is low. Please change the battery. ◦ 3 pulses/second: Hardware fault detected. Please contact the ADVANSEE's hotline: support@advansee.com Document: ADV_UM_9022_01_v1.5 - © ADVANSEE SARL 2015, All rights reserved page 16... -
Page 17: In-Situ Reviewing Of Images Or Video Sequences
The files are compressed and packed in a file named archive.gz (GZIP format). The archive can then be unpacked on a computer (using Document: ADV_UM_9022_01_v1.5 - © ADVANSEE SARL 2015, All rights reserved page 17... - Page 18 (after 5 minutes of inactivity) is deactivated. The camera stops after 60 minutes, if not manually powered off before. 3. Click the icon to go back to the homepage. Document: ADV_UM_9022_01_v1.5 - © ADVANSEE SARL 2015, All rights reserved page 18...
-
Page 19: Getting The Recorded Material
MacOS® or Linux). 2. Using a FTP Client software (e.g. Filezilla), open a FTP connection with the camera: FTP host: 192.148.42.1 FTP port: FTP user: ftp password: tgv44air! Document: ADV_UM_9022_01_v1.5 - © ADVANSEE SARL 2015, All rights reserved page 19... - Page 20 3. Transfer the image files from BEECAM® to the computer. Tips: A command-line FTP transfer client can be used in order to retrieve all files at once. By exemple, with wget: wget ftp://”ftp:tgv44air!”@192.168.42.1/* Document: ADV_UM_9022_01_v1.5 - © ADVANSEE SARL 2015, All rights reserved page 20...
-
Page 21: Maintenance
The BEECAM® camera's firmware may be upgraded. To upgrade the firmware, follow these steps: 1. Get a BEECAM® firmware from ADVANSEE. This is a file named fw_upgrade_vX.x.x_to_vY.y.y.bin (where X.x.x must be the firmware version number currently installed in the camera and Y.y.y is the new firmware version number). -
Page 22: Cleaning
The exterior of the unit can be cleaned with a soft damp cloth. Repair There is no serviceable part inside. Repair of the device should only be made by an ADVANSEE's authorized agent. End of life The device must be recycled according to the local regulations related to electrical and electronic equipments. -
Page 23: Troubleshooting Guide
Save or OK button), there is no loaded by your internet browser. [Ctrl] + [F5] for Mozilla Firefox and Google confirmation popup displayed. Chrome, [Command] + [Option] + [E] for Apple Safari Document: ADV_UM_9022_01_v1.5 - © ADVANSEE SARL 2015, All rights reserved page 23...
