- Page 1 Buy Now at New England Laser & Transit Click to Purchase PRO SHOT PRO SHOT Slope Lasers Slope Lasers AS2 \ AS2 AS2 \ AS2 MAGNUM MAGNUM Operations Guide...
-
Page 2: Table Of Contents
You now have superior laser accuracy and productivity available for all your projects. Both Pro Shot AS2 laser models are rugged, reliable, high quality products, backed by the industry leading Guardian 36 month warranty. Warranty details are printed in the back of this manual. -
Page 3: Battery Installation
Getting Started Case contents (will vary - may be ordered with different accessories) Receiver Battery charger Manual package Laser transmitter C-cell batteries Always follow recycling Battery installation directives for electronic waste 1 Pull on tab at base Pull on tab at base Pull on tab at base of door to remove of door to remove... -
Page 4: Controls And Displays
Leveling Rotation Speed Indicators Indicators ( MAGNUM ) Slope Display Slope Adjustment Knob Charging Jack Note: Controls and displays are the same for both models except that the AS2 MAGNUM has a rotation speed selection button and speed indicator LEDs. - Page 5 Controls And Displays • Slope alignment sights These sights are used to align the slope axis of the laser for excavating and grading when there is a slope required. • Laser Power indicator The green L.E.D. indicates the laser beam is on. •...
-
Page 6: Safety
• Turn the laser off when it is not being used, such as during lunch hour, at the end of the day, or during other long breaks in the work. Safety label locations • AS2 CDRH / IEC warnings... - Page 7 Safety Safety label locations • AS2 MAGNUM CDRH / IEC warnings CAUTION CAUTION LASER LIGHT LASER LIGHT LASER LIGHT - DO NOT STARE INTO BEAM OR VIEW DIRECTLY DO NOT STARE INTO BEAM WITH OPTICAL INSTRUMENTS OR VIEW DIRECTLY WITH MAXIMUM POWER <...
-
Page 8: Initial Setup Guidelines
Work as close to the laser as possible. You can work up to 1000 feet (305M) from the AS2 with the R7 receiver and 1650 feet (500M) from the AS2 MAGNUM using the R8 receiver or most brands/models of machine control receivers. -
Page 9: Level Setup
In the event that a very long distance is required, the AS2 can be set-up in the middle of the site, covering a total diameter of 2000 feet (610 meters) using the R7 receiver. The AS2 MAGNUM can cover a 3300 foot (1000M) diameter using the R8 receiver, or most brands/models of machine control receivers. -
Page 10: Slope Setup
Note: When using either AS2 model at slope settings over 14%, you will need to tilt the tripod to allow the laser to reach the desired slope. By aligning the laser so that one tripod leg is to the rear (down slope side), you... - Page 11 Slope Setup The display reads in percent of grade (the number displayed is the units of rise or fall per 100 units of run). A 2-1/2% slope (projecting upward from the front of the laser) shows as 2.50 on the display. If a down slope is needed, the display is set to the required slope and the rear of the laser is aimed in the direction of slope.
-
Page 12: Compound Slope Setup
90 degrees apart, the optional model S2 Compound Slope Adapter Kit can be used to calculate and set the AS2 to the proper angle and resultant slope. NOTE: The S2 kit is standard with the AS2 MAGNUM system. - Page 13 Compound Slope Setup 2. Using the compound slope chart supplied with the S2 kit, find the two slopes for the site on the chart and follow their row and column until they intersect. Remember that the main slope is the steeper of the two slopes. The upper number in the box where the two slopes intersect is the angle to set into the S2 adapter.
-
Page 14: Checking & Adjusting Calibration
Checking and Adjusting Calibration Calibration is your responsibility, check it often. Although both AS2 models are calibrated at the factory and are exceptionally rugged lasers, it is well worth the effort to check calibration before you first use your laser (after shipping) and then from time to time to ensure that you are doing the highest quality work possible. - Page 15 Checking and Adjusting Calibration 5. Return to the laser and rotate it 180 degrees. Allow the laser to re-level. The opposite cross axis (X) direction is now aimed at the target. Find and mark the laser beam height (see step 4). 6.
-
Page 16: R7 • As2 System Receiver
R7 • AS2 System Receiver The R7 senses the plane of laser light Rear display projected by the AS2 and indicates a height position relative to the plane (high, Five channel front display low, or on grade). The R7 uses a five... -
Page 17: R8 • As2 Magnum System Receiver
MAGNUM The R8 senses the plane of laser light Power Rear display Rear display Rear display Volume projected by the AS2 MAGNUM Accuracy indicates a height position relative to Five channel the plane (high, low, or on grade). front display... -
Page 18: Maintenance And Troubleshooting
Maintenance And Troubleshooting Calibration • There is no set interval for calibrating either AS2 model, but calibration should be checked from time to time in order to ensure that the highest possible quality of work is being done. Calibration should always be checked if the laser has been handled roughly or shipped. -
Page 19: Guardian Warranty And Specifications
Warranty Guardian 36 month warranty coverage The AS2 and AS2 MAGNUM laser transmitters, along with the R7 receiver, are warranted for thirty-six (36) months from the date of new equipment purchase from an authorized dealer. The R8 receiver is warranted for twenty-four (24) months. During... - Page 20 C a l i f o r n i a C a l i f o r n i a • U S A • U S A Laser Reference, Inc. 151 Martinvale Lane San Jose, CA 95119 • Toll Free (USA) •...
