Summary of Contents for Timeguard TLTXDCB
- Page 1 BATTERY POWERED DETECTOR/ TRANSMITTER Cat No. TLTXDCB...
- Page 2 Introduction The TLTXDCB Battery Powered Detector/Transmitter is part of the Timeguard range of PIR products which communicate by radio frequency (r.f.) signals. This enables substantial amounts of wiring to be eliminated which is particularly useful in long wiring runs and coverage of outbuildings.
-
Page 3: Parts Included
Parts included • PIR Sensor unit. • Instruction manual. Please keep safe for future reference. • Accessory Pack. Tools and parts needed • Electric/hand-held drill & bits. • Terminal or Electricians screwdriver • 1 x 9V alkaline PP3 Battery Unit can be used indoors or outdoors. Selecting a location For optimum performance, mount at 2.5m (8ft)high. - Page 4 When siting Rx units that will need to work with the TLTXDCB the signal reception range will be less than 100m if walls or chain link fences come between the Tx and Rx units - if there is any doubt whether communication will take place make temporary installations before programming.
-
Page 5: Installation
Installation Release screw on underside of unit and remove wall plate from main body of sensor, this screw is captive, do not remove. (Fig F) Mark position of the fixing holes. (Fig D) Drill the holes. Insert the wall plugs into the holes. Fit a 9V PP3 alkaline battery. - Page 6 Programming To be operated by the Timeguard Wireless Transmitters, the Timeguard Wireless Receivers must learn the Transmitters unique code. This is achieved automatically by the following procedure. 1. Press the Rx unit’s PROGRAM button for 1 to 2 seconds while Rx unit is powered. Be careful not to press for much longer than 2 seconds or you may erase all existing memorised codes.
-
Page 7: Troubleshooting Guide
The LED will flash on and off twice at every detection if the battery voltage is low. Replace the battery as soon as possible. Troubleshooting guide Problem Possible Cause/Solution • TLTXDCB LED will not 1. Isolation switch is turned activate when motion is off. detected. 2. Adjust sensor to cover desired area. - Page 8 Problem Possible Cause/Solution • Light flashes on and off This is the low battery twice when activated. signal. Replace transmitter battery. • Tone/Light activates for no Check area for false apparent reason activation from heat or reflective source. Re-aim sensor if necessary. •...
-
Page 9: Technical Specifications
Technical specifications Detection Range: Up to 12 metres 180º Detection Angle: 1 x 9V PP3 alkaline battery Power Supply: Day and night or night only Dusk Level Adjustment: operation Environmental Protection: IP44 (suitable for outdoor use) Up to 100m (varies with Transmission Range: surrounding structures) 89/336/EEC... -
Page 10: Year Guarantee
For years 2 to 5 or any difficulty in the first year telephone the helpline on 020 8450 0515. F I V E Y E A R GUARANTEE HELPLINE 020-8450-0515 For a product brochure please contact: Timeguard Ltd. Victory Park, 400 Edgware Road, London NW2 6ND 020-8452-1112 or email csc@timeguard.com...
