- Page 1 BLUEPED TUNING CHIP FOR YAMAHA E-BIKES MANUAL / VERSION 1 / JULY 2016...
- Page 2 IMPORTANT HINTS The use of the BLUEPED module is only allowed in private, gated areas, for example for sports or marketing purposes. It manipulates the maximum speed settings of your Pedelec or S-Pedelec, set by the manufacturer, which is prohibited by the road/streets’ laws. The BLUEPED module manip- ulates the speed sensor signal and therefore the total distance display your E-Bike.
-
Page 3: Table Of Contents
CONTENT 1. Mode of operation 2. BLUEPED module 3. BLUEPED App for Android Home screen Main screen - Speedometer Main screen - Settings 4. BLUEPED App for iPhone/iPad Home screen Info screen Speedometer screen 5. Tips and tricks 6. Appendix... -
Page 4: Mode Of Operation
(1) and generates a fake speed signal (2) for the motor controller. After launching the E-Bike the BLUEPED module, it cuts the communication between motor and E-Bike display (5) to send its own data to the display (4). -
Page 5: Blueped Module
2. BLUEPED module BLUEPED module After pluging all of the connectors, the module is placed inside the frame of the E-Bike. Technical specifications Connector connected with... Dimensions 4,5x2,5x0,8cm 1 the display Cable length 11cm 2 the motor display jack Power dissipation... -
Page 6: Blueped App For Android
3. BLUEPED APP FOR ANDROID The application requires Android version 5.1 or higher. 3.1 Home screen - SEARCH The app will search for BLUEPEDs right after its launch. If a module is found, name, unique ID and signal strength are shown on the display. Furthermore, the application shows, if module and smartphone are paired. - Page 7 BLUEPEDs that were already connected before. A tap on a BLUEPED opens the main screen, that shows the saved data. If the app starts the first time, a demo BLUEPED with the address „00:00:00:00:00:00“ is added to the database. With a...
-
Page 8: Main Screen - Speedometer
3.2 MAIN SCREEN - SPEEDOMETER As soon as the app is connected to the BLUEPED, the BLUEPED data is read by the app. After all the data is read, the controls are activated and settings can be changed. Important After installing the BLUEPED, the E-Bike total dis- The color of the the speed label changes tance has to be set to the module. -
Page 9: Main Screen - Settings
3.3 MAIN SCREEN - SETTINGS Visibility: Can be set to values between 0 and 240 seconds or „infinite“. If visibility is set to 0, the app will no longer be able to find the module after disconnecting or restarting the E-Bike. Wheel size: Speedometer calculation is based on this value. -
Page 10: Blueped App For Iphone/Ipad
If there is no signal over 3 seconds, the module is deleted from the list. A tap on the BLUEPED connects the app. If the device connects the first time the PIN has to be entered in a prompt. -
Page 11: Speedometer Screen
4.3 SPEEDOMETER - SCREEN As soon as app and BLUEPED are connected, the application will read out the data of the module. After all the data is read, the controls are being activated and you can change the settings. Important After installing the BLUEPED, the E-Bike total distance has to be set to the module. - Page 12 Visibility: Can be set to values between 0 and 240 seconds or „infinite“. If visibility is set to 0, the app will no longer be able to find the module after disconnecting or restarting the E-Bike. Wheel size: Speedometer calculation is based on this value.
-
Page 13: Tips And Tricks
If the connection fails, the app will automatically try o reconnect to the module. The screen will show „Reconnect...“ • The BLUEPED can be reset to factory settings by pressing the E-Bike light button 10 times with in 8 seconds. •... - Page 14 6. ANHANG M. Sc. Andreas Fischer Hagstr. 2 72762 Reutlingen Germany andreas.fischer@ble.expert +49 7121 1398012 VAT: DE299137823 WEEE-Nr.:DE29184648...
