Summary of Contents for CAROL DWR-882

  • Page 1 Bodypack Digital Wireless Transmitter DWM-881 User Manual...
  • Page 2 Digital Wireless Microphone User Manual Thank you very much for selecting DWR-882 Digital Wireless System. It is recommended to read this manual carefully before using to make optimum use of your equipment. DWR-882 Digital Wireless System, based on the concept of designing for modern lifestyle, is suitable for all kinds of indoor activities, such as school, company, organization and so on.
  • Page 3 Digital Wireless Microphone User Manual Figure 2.1 DWM-880 Digital Wireless Handle Microphones (as shown in figure 2.2) (1)BALL GRILLE: Protects the capsule, and the enclosed windscreen can reduces pop noises effectively. (2)POWER SWITCH: Switches on/off the microphone (with status LED). (3)HOUSING: For easy handling the microphone and protects the wireless transmitting PCB inside.
  • Page 4 Digital Wireless Microphone User Manual (8)RESET BUTTON: Resets the Transmitter signal (FOR TECHNICIANS USE ONLY). Figure 2.2 DWM-881 Bodypack Digital Wireless Transmitter(as shown in figure 2.3 and 2.4) (1)ø 3.5mm EARPHONE JACK: Connects head-worn or lapel condenser microphone. (2) TRANSMITTER CASING: Protects the wireless transmission PCB inside. (3)VOLUME CONTROLLER: Controls the output volume to avoid feedback/howling.
  • Page 5 Digital Wireless Microphone User Manual Figure 2.3 Figure 2.4 MUD-806 Headset Microphone.(as shown in figure 2.5) (1) ø 3.5mm STEREO PLUG: Connects Bodypack digital wireless transmitter. (2) CONDENSER MICROPHONE: Uni-directional microphone capsule.
  • Page 6 Digital Wireless Microphone User Manual Figure 2.5 MDM-863 Tie-clip Microphone.(as shown in figure 2.6) (1) CONDENSER MICROPHONE: Omni-directional microphone capsule. (2) ø 3.5mm STEREO PLUG: Connects Bodypack digital wireless transmitter. 圖 2.6 3. Receiver Operating Instruction Plug the supplied DC adapter to a wall outlet, and then connect the DC adapter to the power receptacle on Receiver.
  • Page 7 Digital Wireless Microphone User Manual Press the Receiver’s power switch to turn the power on, and the status LED will light up green, it indicates the Receiver is on. If a feedback noise appears when the volume is too high or the microphone is too close to the speaker, turn the volume down.
  • Page 8 Digital Wireless Microphone User Manual 4.3.4 Close the battery cover. Place the cover on top front of the battery compartment, then press on where circle 3 indicates and push the battery cover downward to the end (CAUTION: To avoid injury, DO NOT place your fingers at where circle 4 indicates when pushing the cover).
  • Page 9 Digital Wireless Microphone User Manual When selecting the channel, aim the arrow at the scale or in Fit the slotted between two scales. screwdriver into this slot. Figure 4.4 5. Bodypack Wireless Transmitter Operating Instruction Connect a head-worn or lapel condenser microphone to the ø3.5mm Earphone Jack on the Transmitter.
  • Page 10 Digital Wireless Microphone User Manual Figure 5.2 Push the Power Switch on the Transmitter to OFF as shown in figure 3.3, and the Power LED will go off, so as the red light on the Receiver’s microphone connection status LED. Power Switch, push to OFF Figure 5.3 Replacing Batteries...
  • Page 11 Digital Wireless Microphone User Manual 5.6.3 As shown in figure 5.5, press on where circle 3 indicates and push the Battery Cover downward to the end, then remove the cover. Figure 5.5 5.6.4 Insert two AA batteries in the Battery Compartment according to the polarity marks.
  • Page 12 Digital Wireless Microphone User Manual Figure 5.6 Change the Digital Wireless Transmitter Channel 5.7.1 When using Digital Wireless Transmitter, there might be interferences from other devices that are using neighbor frequencies or from other 2.4G wireless appliances nearby. These disturbances can be solved by selecting a different channel for the Transmitter.
  • Page 13 Digital Wireless Microphone User Manual 6. Pairing Instructions (Only conducted by installers and service technicians) Please plug in the power adapter to turn on the DWR-882 Receiver, and connect to an amplifier with the φ6.3 signal cable. Please install batteries on the DWM-880/DWM-881.
  • Page 14 Digital Wireless Microphone User Manual Weight : 1.5Kg±50g Digital Wireless Handle Microphone Model : DWM-880 Carrier Frequency : 2.4040~2.476 GHz Transmitting Power : 10dBm(±2dBm) Capsule : Dynamic Polar Pattern : Super-Cardioid Impedance : 600 Frequency Response : 80Hz~12000Hz Power Supply : Two AA batteries Battery Life : Approx.
  • Page 15 Digital Wireless Microphone User Manual Capsule:Condenser (ø 6) (with electronic filters) Frequency Response:100Hz ~ 10,000 Hz Output impedance:2.2K 30%(at 1,000 Hz) Sensitivity:-63±3dB ( 0dB=1V/μbar;at 1,000 Hz) Weight:39g± 5g Power Adapter Input : AC 120/230, 20W Output : DC 7.5V/1A 9. Precautions: To avoid damaging the circuit, do not exposure the product to rain, water, and heavy humidity environment, or immerse the product in solution.
  • Page 16 Digital Wireless Microphone User Manual 11. FCC Declarations 11.1 Changes or modifications made to this device not expressly approved by the manufacturer may void the FCC authorization to operate this device. 11.2 In order to comply with the regulations of FCC Radiated Emission Limits, do not place or operate this Transmitter and its antenna together with another antenna or transmitter.
