T.30

ASSEMBLY

INSTRUCTIONS

WITH RADIO

Rev.2-04/17

MOTOR

SOFTWARE 5.14

Table of Contents

Need help?

Do you have a question about the T.30 and is the answer not in the manual?

Questions and answers

Summary of Contents for Fanani T.30

Page 1 T.30 ASSEMBLY INSTRUCTIONS WITH RADIO MOTOR SOFTWARE 5.14 Rev.2-04/17...
Page 3: Table Of Contents
T.30 ASSEMBLY INSTRUCTIONS Checking material p. 2 Before starting p. 3 T.30 components detail p. 4 Fixing p. 5 Ropes p. 8 Electrical connections p. 10 Squaring p. 12 Wind-break profile p. 13 Wall gasket p. 14 Draughtproof profile p. 15 Limit switches re-programming p.
Page 4: Assembly Instructions
It is installer’s responsability to check walls, floor or whatever else fastening support tho whom the roller blind is settled. The mounting is at installer charge qualified to release the document of THE CORRECT INSTALLATION DECLARATION. The electrical connections are at electrician’s charge qualified to release the document of THE CONFORMITY DECLARATION. FANANI / ASSEMBLY INSTRUCTIONS...
Page 5: Checking Material
T.30 Checking material myShell T.30 is packed in strapped, reinforced cartons. The following labels are applied to all cartons: SUMMARY LABEL customer (Name-Surname or Company) order number model dimensions IMPORTANT: before unpacking check that the data on the summary label is correct CONTENTS LABEL roller blind set (box, bottom rail, fabric, etc.)
Page 6: Components Detail
- myShell hooking unit nylon pulley - tube with fabric nylon cap + holder plate + cap mounting pin T.30 guide tracks bottom rail slider set guide end cap + myShell hook and release device rope transfer unit bottom rail (base+cover)
Page 7 - hole less than Ø6.5 for screws IMPORTANT: WHERE THERE IS A DRAUGHTPROOF PROFILE LEAVE AT LEAST A 1 cm SPACE BETWEEN THE GUIDE TRACK AND THE EXISTING STRUCTURE IMPORTANT: AT THIS STAGE SET THE GUIDES ONLY INTO THE FANANI / ASSEMBLY INSTRUCTIONS...
Page 8: Fixing
5) fix the holding plates inserted into the guide to the guide spacer 6) check the squaring ATTENTION : in presence of led stripes, insert them before placing the guides. IMPORTANT: BEFORE FIXING THE GUIDE SPACER CHECK THE SQUARING FANANI / ASSEMBLY INSTRUCTIONS...
Page 9 8) remove the stainless steel holding plate from the guide adjustable spacer, fix the guides to the spacers ; IMPORTANT: Flap PLACE THE BOX facing GROUP AS PER upwards ILLUSTRATION. TURN LATER) Flap facing downwards ceiling counter-bracket version FANANI / ASSEMBLY INSTRUCTIONS...
Page 10 5) remove the screws from the guide end cap (a) 6) place the lock (b) inside the guide 7) insert the guide end cap (c) with cable into the guide 8) place the screws back in the guide end cap (a) FANANI / ASSEMBLY INSTRUCTIONS...
Page 11 (in order to stretch the springs); 3) get the maximal tension by reaching the 4) close the bottom rail cover and secure it with its screws 5) fit the box cover to the guide with its screws as well FANANI / ASSEMBLY INSTRUCTIONS...
Page 12 “STOC” press the button and check that the fabric UNHOOKS properly i IMPORTANT: if in that phase the fabric doesn’t result lightly loose, reset the limit switches FANANI / ASSEMBLY INSTRUCTIONS...
Page 13 “STOC” press the button and check that the fabric UNHOOKS properly i IMPORTANT: if in that phase the fabric doesn’t result lightly loose, reset the limit switches FANANI / ASSEMBLY INSTRUCTIONS...
Page 14 ATTENTION : a wrong alignment of the side guides or a their unstable settings cause the malfunction of the myShell blocking system Ideal condition Condition to be corrected Condition to be corrected FANANI / ASSEMBLY INSTRUCTIONS...
Page 15: Windbreak Profile .7
1) insert the stainless steel holding plate into the guide ; 2) set the wind-break profile supports in the holding plates at the desired position; 3) link the wind-break profile to the holding plate with screws. FANANI / ASSEMBLY INSTRUCTIONS...
Page 16: Wall Gasket
8. Wall gasket 1) drill the slotted profile and set it to the wall. 2) apply silicone on the wall side and gasket side. IMPORTANT: IN THE VERSIONS WITH MORE THAN ONE MODULE DO NOT CUT THE GASKET. FANANI / ASSEMBLY INSTRUCTIONS...
Page 17: Draughtproof Profile .9
T.30 Draughtproof profile .9 IMPORTANT : THE RUBBER FLAP IS ALREADY INSERTED IN THE PROFILE 1) hook the bottom rail with the guide and bring it to top 2) once exceeded the bottom rail with the druaughtproof profile, turn the flap inward for its correct positioning.
Page 18: Limit Switches Re-Programming
(bottom rail stops against the box). WARNING: KEEP PRESSED THE UP BUTTON WITHOUT RELEASING IT TILL THE BOTTOM RAIL STOPS AGAINST THE BOX AND THE MOTOR PERCEIVES THE OBSTACLE AND MEMORIZES THE LIMIT SWITCH FANANI / ASSEMBLY INSTRUCTIONS...
Page 19 Then press the PROGRAM button until the motor confirms the operation with a CLICK END OF SETTING At the end of the procedure check that the fabric hooks and unhooks automatically by using the push-button panel buttons. FANANI / FITTING INSTRUCTIONS...
Page 20 (bottom rail stops against the box). WARNING: KEEP PRESSED THE UP BUTTON WITHOUT RELEASING IT TILL THE BOTTOM RAIL STOPS AGAINST THE BOX AND THE MOTOR PERCEIVES THE OBSTACLE AND MEMORIZES THE LIMIT SWITCH FANANI / ASSEMBLY INSTRUCTIONS...
Page 21 (in this order) until the motor confirms the operation with a CLICK END OF SETTING At the end of the procedure check that the fabric hooks and unhooks automatically by using the remote control buttons. FANANI / ASSEMBLY INSTRUCTIONS...
Page 22: Additional Remote Control
The company Fanani S.r.l. has pre-programmed the wind or sun/wind sensor. Warning: if the awning is powered and the sensor is not yet powered, the remote control might operate in “dead man” mode. Once the sensor is powered, the remote control works properly.
Page 23: Troubleshooting .13
Salt air/saltiness exposition Fanani structure are made with aluminium extruded profile, fusion of light metallic alloys thermo vanished, stainless steel 304 accessories assembled with stainless steel screws. Althoug the salt air/saltness exposure might cause aesthetic and functioning problems to the product.
