RF Tuner operation : ± 100 kHz Test equipment: Fluke 54200 TV Signal generator Tuning Principle: Test streams: PAL BG Philips Standard test pattern Automatic B, G, I, DK and L/L’ detection Manual selection in “STORE” mode 1.2.1 System Analog Inputs / Outputs PAL B/G, PAL D/K, SECAM L/L’, PAL I...
3139 785 32060 Test Disc & Repair Hints EN 5 Test Disc & Repair Hints Test Disc 1) 7104 099 96611 CD-RW printed Audio Disc 2) 9965 000 25728 DVD Player Test Pack 3) - Blank DVD+RW 4) - Blank DVD-RW Open the DVD Tray manually Note: This procedure needs to be performed on...
Press <Select > and the screen will display Firmware Information Build 5019V07 010 / Date:12 Apr 2006 Loader Version 43.03.10 Macrovision Version: MPEG Chip ID: Audio DAC: Region Num: 2 Developer: Philips PS3360H_31_R19.07 Press <OK> button and <Setup> to exit.
3139 785 32060 Service Flow Chart EN 7 Service Flow Chart Start Process Start Is the complaint documented ? Is it a known Is it a complaint ? Hardware problem ? (Verification Test) Is Firmware solution available ? Upgrade to latest Firmware Service W/S to contact the Trade / Customer to work out a action plan.
Page 8
EN 8 3139 785 32060 Service Flow Chart Verification Process (Verification Test) Connect up the Recorder to TV antenna, TV set and an External source Can the set Start-up ? Check the Firmware version on the set Is Firmware the last released version ? Upgrade to latest...
Page 9
3139 785 32060 Service Flow Chart EN 9 Recording Process DVDR3360H Eur verification process_final.xls Recording Test disc: Check Blank DVD+RW Manual Recording with TSB Blank DVD-RW Manual Recording Copy to DVD Recordable disc Timer Recording 1) Switch the Recorder to Tuner source...
Page 10
EN 10 3139 785 32060 Service Flow Chart Playback Process Test disc: DVD Player Test Pack (12NC: 9965 000 25728) Playback CD-RW Printed Audio disc (12NC: 7104 099 96611) Check Any Pre-recorded DVD+RW Edit Recordings on the HDD / Recordable DVD Play a Test disc From the HDD Content Menu check the 1) Playing the DVD video disc and...
Page 11
3139 785 32060 Service Flow Chart EN 11 System Menu Process Setup Menu Check Setup Menu - Setup and check the following features: - Menu Language - Country Selection - TV Shape - Auto Program - Manual Program - Sort Setup Menu - Date / Time and check the following features: - Date - Time Setting...
