Assembly
Instructions
1A
Parts in this box.
Chair Size
i
Back Deck
Seat Deck
Stretchers x 2
Pieces
Love seat Size
Back Deck
Seat Deck
Stretchers x 2
Pieces
1B
Hardware attached to Back Deck Side Rail.
Clevis Pins
x 2 Pieces
i
Instructions for the Arm assembly, are packed in the Arm box.
FUTON FRAME
BIFOLD BODY
Full Size
Back Deck
Seat Deck
Stretchers x 2
Queen Size
Back Deck
Seat Deck
Stretchers x 2
Washers
x 2 Pieces
Instructions apply to all sizes:
Full/Double
Chair
Love seat
Queen
2FA-0300-I
Pieces
Pieces
Locking Pins
x 2 Pieces
Page 1 of 3
Advertisement
Table of Contents
Summary of Contents for Futon On Line VIENNA
- Page 1 Assembly Instructions apply to all sizes: FUTON FRAME Full/Double Chair BIFOLD BODY Instructions Love seat Queen 2FA-0300-I Parts in this box. Chair Size Full Size Back Deck Back Deck Seat Deck Seat Deck Stretchers x 2 Stretchers x 2 Pieces Pieces Love seat Size Queen Size...
- Page 2 Chair Full/Double BIFOLD FUTON FRAME Assembly Instructions Love seat Queen FA-0300 Prepare Arms for Assembly. NOTE: The hardware for these steps is included with the Arms. Some Arms may not have these features, so just skip these steps. Fasten Stretcher Brackets to Arm. Fit Wooden Dowels.
- Page 3 Chair Full/Double BIFOLD FUTON FRAME Assembly Instructions Love seat Queen FA-0300-I Fit Back Deck into Position. Your arm style may vary Insert the Back Deck lying flat. Insert one This step can be tricky - it is best done with two people end first, then gently lower the other end into position.
- Page 4 Assembly See below for BIFOLD ARMS Preparation of arms VIENNA ARM Instructions for assembly. One pair of Bifold Arms Outside View Inside View Hardware in this box Wooden dowel x 4 Pieces Allen Key x 1 Piece 60mm bolts x 8 Pieces...
