Summary of Contents for Heateflex SX-36-3V-P510
- Page 1 405 E. Santa Clara St., Arcadia, CA 91006-7218 O: (626) 599-8566 • F: (626) 599-9567 HEATEFLEX CORPORATION SX-36-3V-P510 STAINLESS STEEL HEATER INSTRUCTION MANUAL World Leader in Ultra-Pure Heating www.heateflex.com...
- Page 2 405 E. Santa Clara St., Arcadia, CA 91006-7218 O: (626) 599-8566 • F: (626) 599-9567...
- Page 3 405 E. Santa Clara St., Arcadia, CA 91006-7218 O: (626) 599-8566 • F: (626) 599-9567 MODEL: SX-36-3V-P510 SERIAL NO.: USA-SX0517-1 INDEX Section I – SX HEATER INSTRUCTION MANUAL • Table of Contents • Introduction • Description • Equipment Specifications • Environmental Specifications •...
-
Page 4: Table Of Contents
405 E. Santa Clara St., Arcadia, CA 91006-7218 O: (626) 599-8566 • F: (626) 599-9567 MODEL: SX-36-3V-P510 SERIAL NO.: USA-SX0517-1 TABLE OF CONTENTS ....................5 HIPPING NSTRUCTIONS ................5 ECEIVING NSPECTION ROCEDURE ....................... 6 NTRODUCTION ......................... 6 ESCRIPTION ..................7... -
Page 5: Shipping Instructions
405 E. Santa Clara St., Arcadia, CA 91006-7218 O: (626) 599-8566 • F: (626) 599-9567 Shipping Instructions The proper shipping procedure for the Stainless Steel D.I. Water Heater includes shipping the unit in a horizontal position as shown and described below. The Stainless Steel D.I. -
Page 6: Introduction
O: (626) 599-8566 • F: (626) 599-9567 NTRODUCTION Your Heateflex Corporation in-line point of use fluid heating system will accurately heat and maintain the temperature of your process fluid through the use of patented Power-To-Flow heating technologies. To obtain the best results from your unit, it is recommended that the user operating this system read completely through this manual and the accompanying component literature to become familiar with all the functions and features of the system. -
Page 7: Quipment Pecifications
405 E. Santa Clara St., Arcadia, CA 91006-7218 O: (626) 599-8566 • F: (626) 599-9567 QUIPMENT PECIFICATIONS Model No.: Serial No.: SX-36-3V-P510 USA-SX0517-1 Description: STAINLESS STEEL HEATER SYSTEM, 36KW, 480VAC, 3-PH Module Construction: 316 Stainless Steel Kilowatts: 36 kW Voltage:... -
Page 8: Environmental Specifications
405 E. Santa Clara St., Arcadia, CA 91006-7218 O: (626) 599-8566 • F: (626) 599-9567 NVIRONMENTAL PECIFICATIONS THIS EQUIPMENT MUST ONLY BE USED WITHIN THE RANGE OF ENVIRONMENTAL CONDITIONS LISTED BELOW. Operational usage: INDOOR USE ONLY Maximum operating pressure: 65PSI @ 95°C. Maximum fluid temperature: 95°C. -
Page 9: Basic Safety Precautions
405 E. Santa Clara St., Arcadia, CA 91006-7218 O: (626) 599-8566 • F: (626) 599-9567 ASIC AFETY RECAUTIONS Every effort has been made to insure that this unit will run with a minimum of user input or maintenance. However there are still precautions to be taken whenever operating, performing maintenance, or servicing this unit. - Page 10 405 E. Santa Clara St., Arcadia, CA 91006-7218 O: (626) 599-8566 • F: (626) 599-9567 • Do not use metal tools around the connectors when there is power to the unit, as they may cause arcing. • Turn off power before connecting alligator clips to any circuit. •...
-
Page 11: Installation Procedures
405 E. Santa Clara St., Arcadia, CA 91006-7218 O: (626) 599-8566 • F: (626) 599-9567 NSTALLATION ROCEDURES Installation of this unit consists of first verifying that the minimum facility requirements for normal operation can be met. Once the mounting requirements are completely understood and it has been verified that they can be met, the next step would be locating where the unit will be used. -
Page 12: Operating Instructions
405 E. Santa Clara St., Arcadia, CA 91006-7218 O: (626) 599-8566 • F: (626) 599-9567 TAINLESS TEEL EATING YSTEM PERATING NSTRUCTIONS Prior to any operation of this unit, it is highly recommended that the operator read completely through and understands the Basic Safety Precautions on pages 7-8 of this manual. After understanding these items, the procedure below details the basic operation of the unit. - Page 13 405 E. Santa Clara St., Arcadia, CA 91006-7218 O: (626) 599-8566 • F: (626) 599-9567 • Once you have completed the above mentioned procedures, the unit is ready to heat fluid to the required temperature. No further calibration or set up is necessary for the controls in order to process the fluid at the correct temperature.
-
Page 14: Arameters
405 E. Santa Clara St., Arcadia, CA 91006-7218 O: (626) 599-8566 • F: (626) 599-9567 ASIC ONTROLLER ARAMETERS Temperature Controller (PN: 306551) Engineering Parameters Function Symbol Setting SPCH Function Symbol Setting 46. F43 Deut 47. F43 Eho3 dSoP 48. F43 E1L3 49. - Page 15 405 E. Santa Clara St., Arcadia, CA 91006-7218 O: (626) 599-8566 • F: (626) 599-9567 ASIC ONTROLLER ARAMETERS ONTINUED Temperature Controller (PN: 306551) Engineering Parameters (Continued) Function Symbol Setting Function Symbol Setting 91. F51 136. F70 STdP 92. F51 PFFS 1.00 137.
- Page 16 405 E. Santa Clara St., Arcadia, CA 91006-7218 O: (626) 599-8566 • F: (626) 599-9567 UGGESTED PARE ARTS SX-36-3V-P510 Item No. Qty. Part No. Description 840176A Htr. Assy., 316SS, 36kW, 480VAC, 3-PH. SX Vessel, 316SS, 4” Flange,2-1/2” TRC. F30101 Flange Gasket, Teflon, #150, 4” DIA.
-
Page 17: Heateflex Corporation
Items returned for warranty repair must be prepaid and insured for shipment. Warranty claims are processed on the condition that prompt notification of a defect is given within the warranty period. Heateflex Corporation shall have the sole right to determine whether, in fact, a warranty situation exists.
