Page 1: Installation Guide
VX 600 Bluetooth Printer Installation Guide VeriFone Part Number DOC087-00x-EN-A, Revision A.1... - Page 2 VeriFone, Inc. The information contained in this document is subject to change without notice. Although VeriFone has attempted to ensure the accuracy of the contents of this document, this document may include errors or omissions. The examples and sample programs are for illustration only and may not be suited for your purpose.
-
Page 3: Table Of Contents
Device Does Not Start ..........23 Guidelines Device Does Not Print Correct/Readable Info ......23 VX 600 B LUETOOTH RINTER... - Page 4 VX 600 B LUETOOTH RINTER NSTALLATION UIDE...
-
Page 5: Preface
Troubleshooting Guidelines. Provides troubleshooting guidelines should you encounter a problem in terminal installation and configuration. Related To learn more about the VX 600 Bluetooth Printer, refer to the following set of Documentation documents: VX 600 Bluetooth Printer Certifications and VPN DOCxxx-xx1-EN-A... -
Page 6: Conventions And Acronyms
Table 2 presents acronyms and their definitions. Table 2 Acronym Definitions Acronym Definitions Alternating Current Light Emitting Diode Line Per Second Merchandise Return Authorization PIN Entry Device Universal Serial Bus VeriFone Part Number VX 600 B LUETOOTH RINTER NSTALLATION UIDE... -
Page 7: Overview
Overview This chapter provides a brief description of the VX 600 Bluetooth Printer. The VX 600 Bluetooth Printer is a small form factor thermal printer that can print out transaction receipts when connected to a supported PAYware mobile payment solution as well as Android and Blackberry mobile phones. -
Page 8: Features And Benefits
VERVIEW Features and Benefits Features and VX 600 Bluetooth Printer devices provide the right combination of portability and Benefits functionality including wireless connectivity, small form factor, long-lasting battery, and fast thermal printing for all supported PAYware mobile payment solutions, Android, and Blackberry mobile phones. -
Page 9: Setup Selecting A Location
Installing/Replacing the Paper Roll • Connecting Printer to Device Selecting a Use the following guidelines to select a location for the VX 600 Bluetooth Printer. Location Ease of Use • Select a flat support surface, such as a countertop or table. -
Page 10: Electrical Considerations
• Do not use the VX 600 Bluetooth Printer near water or in moist conditions. Due to risk of shock or damage, do not use the VX 600 Bluetooth Printer near WARNING water, including a bathtub, wash bowl, kitchen sink or laundry tub, in a wet basement, or near a swimming pool. -
Page 11: Examining Device Features
SERRATED METAL STRIP LED INDICATOR (POWER/CHARGE PAPER JAM) POWER ON/OFF BUTTON LED INDICATOR (BLUETOOTH CONCTION STATUS) MICRO-USB PORT Figure 2 VX 600 Bluetooth Printer Table 3 Printer Power Status LED Indicator Status Charging Battery Paper Printer Battery Sleep Timer Fault... -
Page 12: Inserting Battery Pack
Inserting Battery The battery fits in a slot on the back of the VX 600 Bluetooth Printer. The locking Pack tab clicks when the battery is in place. The slot is keyed, so that there is only one way to insert the battery. -
Page 13: Charging Using The Micro Usb Port
Micro USB Port 600 Bluetooth Printer. Connect the other end of the micro-USB cable into a USB wall mount charger and plug into a outlet or powered surge protector. Figure 5 Charging the battery VX 600 B LUETOOTH RINTER NSTALLATION UIDE... -
Page 14: Installing/Replacing The Paper Roll
Paper Roll The VX 600 Bluetooth Printer uses a roll of single-ply, thermal sensitive paper 47 mm (2.24 inches) wide by 25 meter long paper. A pink out-of-paper indicator line appears on the edge of the paper approximately 18 inches before the end of the roll. -
Page 15: Connecting Printer To Device
Tear the paper off against the serrated metal strip in the printer. Connecting Use the VX 600 Bluetooth Printer to print from a smart phone or a computer. You Printer to Device can connect these devices to the VX 600 Bluetooth Printer using a micro-USB cable or via Bluetooth. -
Page 16: Connecting Via Micro-Usb Cable
ETUP Connecting Printer to Device Connecting via Connect your VX 600 Bluetooth Printer to a host laptop or computer using a micro-USB Cable micro-USB cable. Figure 9 Connecting to a host computer using micro-USB Cable Disconnect power from the host computer. -
Page 17: Specifications
HAPTER Specifications This chapter discusses power requirements, dimensions, and other specifications of the VX 600 Bluetooth Printer device. Power Charging via Micro-USB to computer system or power adapter: 5V DC 0.5 A or 5V DC 1.0 A Temperature • Operating temperature: 0° to 40°C (32° to 104°F) •... - Page 18 PECIFICATIONS External Dimensions VX 600 B LUETOOTH RINTER NSTALLATION UIDE...
-
Page 19: Maintenance
Device Contacts Gently swab the contacts with alcohol or contact cleaner to remove the dirt. It is important that the exposed contacts of the VX 600 Bluetooth Printer battery stay clean and unbent. CAUTION Avoid touching the recessed area on the device. Finger oils tarnish contacts, causing bad connections. - Page 20 AINTENANCE Device Contacts VX 600 B LUETOOTH RINTER NSTALLATION UIDE...
-
Page 21: Verifone Service
Monday - Friday, 8 A.M. - 8 P.M., Eastern time • International – Contact your VeriFone representative Returning a Before returning a VX 600 Bluetooth Printer, you must obtain an MRA number. Device for The following procedure describes how to return one or more devices for repair or Service replacement (U.S. -
Page 22: And Support Accessories And Documentation
Reference the model and part number in the Note box. NOTE One MRA number must be issued for each VX 600 Bluetooth Printer you return to VeriFone, even if you are returning several of the same model. Describe the problem(s). -
Page 23: Hapter
600 Bluetooth Printer unit contains no user serviceable parts. Do not, under any circumstance, attempt to disassemble the device. Perform only those adjustments or repairs specified in this guide. For all other services, contact your local VeriFone service provider. Service conducted by parties other than authorized VeriFone representatives may void any warranty. -
Page 25: Vx 600 B Luetooth P Rinter I Nstallation G Uide
VeriFone, Inc. 2099 Gateway Place, Suite 600 San Jose, CA, 95110 USA Tel: (800) VeriFone (837-4366) www.verifone.com VX 600 Bluetooth Printer Installation Guide VeriFone Part Number DOC087-00x-EN-A, Revision A.1...
